1.3 Technical Specifications
Specifications & Requirements
Weight
Overall Dimensions
Depth x Width x Height
Paddle System
Vessel Options*
Frame & Enclosure Metal
Servo Motor Drive
Electrical
Vessel Guard
Power
Compressed Air
Axis, 120V / 240V
Axis - 190 lbs, Control Stand - 90 lbs -> Total = 280 lbs
53.1" x 72.4" x 84.0"
Quick change paddle system for all 3 vessel sizes (30, 44, 65)
3 vessel sizes (65gal, 44gal, 30gal)
*Elevated dolly required
Stainless Steel housing
6061-Aluminum frame
Stainless Steel hardware
2-80 RPM
Food grade belt drive, tension to 28-29 Hz
Food grade sealed bearings
IP65 rated electrical components
UL508A rated control panel
Removable, PETG
100-120VAC, 7A, 50-60Hz
220-240VAC, 4A, 50-60Hz
120 psi, dry clean air
6
