- Page 1 1.0 cu.ft Microwave Oven Convection KOC-924T9N Instruction Manual and Cooking Guide Before operating this oven, please read these instructions completely.
-
Page 2: Table Of Contents
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. (b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. -
Page 3: Important Safety Instruction
IMPORTANT SAFETY INSTRUCTIONS When using electrical appliances, basic safety precautions should be followed, including the following: WARNING - To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive microwave energy: 11. Read all instructions before using the appliance. b) When separate cleaning instructions are provided, See door surface cleaning instructions on. -
Page 4: Federal Communications Commission Radio Frequency
FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT WARNING: This equipment generates and uses ISM frequency energy and if not installed and used properly, that is in strict accordance with the manufacturer's instructions, may cause interference to radio and television reception. It has been type-tested and found to comply with limits for an ISM Equipment pursuant to part 18 of FCC Rules, which are designed to provide reasonable protection against such interference in a residential installation. -
Page 5: Installation
INSTALLATION Examine the oven after unpacking. Check for damage such as a misaligned door, broken door or dent in the cavity. If any damage is visible, DO NOT INSTALL, and notify your dealer immediately. Level, flat location. Install the microwave oven on a level, flat surface and more than 3ft(914mm) above the floor. Ventilation. -
Page 6: Specifications
SPECIFICATIONS POWER SUPPLY 120V AC 60 Hz SINGLE PHASE WITH GROUNDING POWER CONSUMPTION 1500W MICROWAVE OUTPUT POWER 1000W FREQUENCY 2450 MHZ GRILL POWER CONSUMPTION 850W CONVECTION POWR CONSUMPTION 1450W COMBINATION HEATING POWER CONSUMPTION 1500W OUTSIDE DIMENSIONS (WXHXD) 542 x 329 x 515 mm ( 21.3 x 13.0 x 20.3 in. ) CAVITY DIMENSIONS (WXHXD) 350 x 230 x 355 mm ( 13.8 x 9.1 x 14.0 in. -
Page 7: Features Diagram
FEATURES DIAGRAM 1 DOOR HOOK - When the door is closed, it will automatically lock shut. If door is opened while oven is operating, the magnetron will immediately stop operating. 2 DOOR VIEWING SCREEN - Allows viewing of food. The screen is designed so that light can pass through, but not the microwave. - Page 8 FEATURES DIAGRAM (continued) 1 Display : Cooking time, power level, indicators and present time are displayed. MW : When blinking, the oven is operating in MICROWAVE COOK. Grill : When blinking, the oven is operating in GRILL. Combi : When blinking, the oven is operating in COMBI.
-
Page 9: Accessories
ACCESSORIES This oven comes equipped with several accessories. Turntable tray or turntable They can be used in various ways to facilitate cooking. This metal tray fits over the rotating base and locks into place. This is to be used in the oven for all cooking. It rotates Rotating base clockwise or counterclockwise during cooking. -
Page 10: Before Operation
BEFORE OPERATION SETTING THE CLOCK When your oven is plugged in, the display will flash “ :0” and a tone will sound. If the AC power ever goes off, the display shows “ :0” when the power comes back on. Your oven has multiple(12hr/24hr) clock system. -
Page 11: Child Lock And Power Save Mode
CHILD LOCK AND POWER SAVE MODE Child lock : The child lock prevents the oven from being used. For example because children could hurt themselves on hot liquids etc. Power save mode : This function is used for saving energy. To set child lock 1. -
Page 12: Operation
OPERATION Tips : Also remember to read this operating instruction for proper safety information and instruction before using the oven. Prior to setting the controls, place one cup of water in the oven, on a heat-proof glass measuring cup, for testing purposes. Note : When the cooking time has elapsed the oven beeps three times, "... -
Page 13: Grill Cooking - No Microwaves
GRILL COOKING - No Microwaves The grill enables you to heat and brown food quickly, without using microwaves. 1. Press Grill button once. GRILL(upper grill) indicator lights. 2. Turn the dial knob to set the grilling time. For a grilling time of 11 minutes, turn the dial knob to the right to set 11:00.( up to 60 minutes ) “11:00”... -
Page 14: Convection Cooking(With Pre-Heat) - No Microwaves
CONVECTION COOKING(with pre-heat) - No Microwaves For convection cooking, it is recommended that you preheat the oven to the appropriate temperature before placing the food in the oven. The maximum preheating time is 30 minutes. If the cooking is not started immediately after preheating, the convection indicator will continue to flash and the preheated oven temperature will be displayed. -
Page 15: Convection Cooking(Traditional Cooking)-No Microwaves
CONVECTION COOKING(traditional cooking)-No Microwaves The convection mode enables you to cook food in the same way as in a traditional oven. Microwaves are not used. Always use oven gloves when touching the recipients in the oven, as they will be very hot. 1. -
Page 16: Combination Cooking
COMBINATION COOKING ( Microwave + Convection + Upper Grill ) This function allows you to combine convection operation with microwave to produce traditional baked or roasted results in less time. Always use microwave-safe and oven-proof cookware. Glass or ceramic dishes are ideal as they allow the microwaves to penetrate the food evenly. -
Page 17: Weight Defrost - Microwave Usage
WEIGHT DEFROST - Microwave Usage Weight Defrost automatically sets the defrosting times and power levels to give even defrosting results for frozen food. During the defrosting process the oven will beep to remind you to check the food. The oven will beep, open the door, turn the frozen food over and close the door, press the START/SPEEDY COOK button. -
Page 18: Auto Cook - Microwave Usage
AUTO COOK - Microwave Usage This function allows you to simply and automatically cook a range of popular foods. Always use oven gloves when touching the recipients in the oven. 1. Press Auto Cook button once. Auto Cook indicator light. "AC-1 "... - Page 19 Auto Cook Menu Start Temp. Method Cookware 1. Tie the joint into a neat shape. 2. Place the pork directly on the metal rack on the ROAST PORK turntable. Place the pork 3. Brush with a little oil. or beef directly 4.
-
Page 20: Speedy Cook
SPEEDY COOK The speedy cook function allows the oven to being cooking immediately on full power. The speedy cook button has been pre-programmed to increase in increments of 30 seconds up to a maximum time of 5 minutes. 1. Press START/SPEEDY COOK button. The oven will be "... -
Page 21: General Guide Lines
GENERAL GUIDE LINES Since microwave cooking to some extent is different from Covering food helps: traditional cooking, the following general guidelines should be • To reduce spattering considered whenever you use your microwave oven • To shorten cooking times • To retain food moisture If the food is undercooked All covering, which will allow microwaves to pass through are Check if:... -
Page 22: Cooking Instruction
COOKING INSTRUCTIONS Utensils should be checked to ensure that they are suitable for use in microwave ovens. UTENSILS TEST Place the utensil in question next to a glass measure filled with water, in the microwave oven. Microwave at high power for 1-2 minutes. If the water heats up, but the utensil remains cool, the utensil is microwave-safe. However if the utensil becomes warm, microwaves are being absorbed by the utensil and it should not be in the microwave oven. -
Page 23: Microwave Principles
MICROWAVING PRINCIPLES Microwave energy has been used in this country to cook and reheat food since early experiments with RADAR in World War ll. Microwaves are present in the atmosphere all the time, both naturally and manmade sources. Manmade sources include radar, radio, television, telecommunication links and car phones. -
Page 24: Cooking Techniques
COOKING TECHNIQUES STANDING TIME STARTING TEMPERATURE Dense foods e.g. meat, jacket potatoes and cakes, The colder the food, the longer it takes to heat up. require standing time(inside or outside of the oven) Food from a fridge takes longer to reheat than food after cooking, to allow heat to finish conducting to at room temperature. -
Page 25: Defrosting Guide
DEFROSTING GUIDE GENERAL INFORMATION Put the food on a microwave rack (roasts, bone-in pieces) or in a microwave casserole (small pieces such as cubes or strips) or weigh at home on a kitchen scale. Round number to the nearest tenth of a pound and choose that number with each item pads. -
Page 26: Defrosting Chart
DEFROSTING CHART Item and Weight Defrosting Time Standing Time Special Techniques BEEF Break apart and remove thawed Mineed beef 5-7 min. 5-7 min. portions with fork. 454g (1 lb.) Stew Meat Separate and rearrange once. 6-8 min. 5-7 min. 681 (1 1 /2 lbs.) Turn over after half the time. -
Page 27: Cooking Chart
COOKING CHART Check time per 1lb. in chart below and multiply by the weight of the item. MEAT ITEM POWER LEVEL COOKING TIMER PER POUND Beef Standing/rolled Rib - Rare P-80 5-7 min. - Medium P-80 6-8 min. - well done P-80 7-9 min. - Page 28 VEGETABLE ITEM POWER LEVEL PREPARATION QUANTITY COOKING TIME STANDING TIME Artichokes, fresh P-HI Whole 4(8 oz. each) 5-7 min. 5 min. Artichokes, frozen P-HI Hearts 250g(9 oz. pkg) 6-8 min. 5 min. 1 1 /2-in.pieces Asparagus, fresh P-HI 500g(1 lb.) 3-5 min.
- Page 29 Grill / Combination Ingredients Method / Convection Beef Kabobs 2 /3 1. Pour dressing into microwaveable mudium cup ltalian salad dressing (Serve 4) casserole. Cook on 100% microwave power for 1 454(1 lb.) beef sirloin steak, boneless minute or until heated. Add beef and stir to coat. cut into 2.5cm(1”cubes) cubes 1 /2 Cover;...
- Page 30 Grill / Combination Ingredients Method / Convection Peanut butter 150g (6oz) butter 1. Mix the butter, peanut butter, sugar and egg cookies 75g (3oz) crunchy peanut butter together. Add the flour and chopped nuts and mix to (Serve 12-15) 100g (4oz) soft brown sugar a firm dough.
-
Page 31: Reheating Chart
REHEATING CHART ITEM QUANTITY POWER LEVEL COOKING TIME SPECIAL INSTRUCTION Heat 12 at time on paper towel lined paper Appetizers 2 servings P-HI 1-2 min. plate or microwave oven roasting rack (bite size) If containers is 3/4-inch deep, remove foil Breakfast entrée 110~140g(4-5 oz.) P-HI... -
Page 32: Care Of Your Microwave Oven
CARE OF YOUR MICROWAVE OVEN Turn the oven off before cleaning. Keep the inside of the oven clean. When food spatters or spilled liquids adhere to oven wetal, plate tray wipe with a damp cloth. Mild detergent may be used if the oven gets very dirty. The use of harsh detergent or abrasives is not recommended. -
Page 33: Use Your Microwave Oven Safely
USE YOUR MICROWAVE OVEN SAFELY General Use Do not attempt to defeat or tamper with safety interlocks. Do not place any object between the oven front frame and the door or allow residue to build up on sealing surfaces. Wipe with a mild detergent, rinse and dry. Never use abrasive powders or pads. Do not subject the oven door to strain or weight such as a child hanging on an open door. -
Page 34: Before You Call For Service
BEFORE YOU CALL FOR SERVICE Refer to following checklist, you may prevent an unnecessary service call. * The oven doesn't work; 1. Check that the power cord is securely plugged in. 2. Check that the door firmly closed. 3. Check that the cooking time is set. 4. -
Page 35: Questions And Answers
QUESTIONS AND ANSWERS (continued) Q : Why is standing time recommended after the cooking operation has been completed? A : Standing time is very important. With microwave cooking, the heat is in the food, not in the oven. Many foods build up enough internal heat to allow the cooking process to continue, even after the food is removed from the oven. - Page 36 Note: The warranty service center list is constantly changing with the addition of our current qualified service centers. If there is inadequate or no local service facility, subject individual customer will call DAEWOO on the toll free number 1-800- DAEWOO8(1-800-323-9668) to be provided with further informations.
