D-Link DSL-G2452GR User Manual page 162

DSL-G2452GR MU-MIMO Wireless Dual Band VDSL2 Router with
ASDL2+/3G/LTE/Gigabit Ethernet WAN Support, 2 FXS Ports and USB Port
User Manual
To allow access only to a certain folder of the USB storage, click the ADD (
Directories section.
In the opened window, locate a folder containing files. To do this, click the Search icon (
the Path field. Then go to the needed folder and click the SELECT button.
In the Name field, specify a name of the selected folder which will be displayed for users of your
LAN. Use digits and/or Latin characters.
Click the SAVE button.
To remove a folder from the list in the Directories section, select the checkbox located to the left
of the relevant line in the table and click the DELETE button (
After specifying the needed parameters, click the APPLY button.
To disable the built-in Samba server of the router, move the Enable Samba server switch to the
left and click the APPLY button.
Figure 128. Specifying a folder.
Page 162 of 262
Configuring via Web-based Interface
) button in the
).
) in
