4.
What is Arduino
Arduino
®
is an open-source prototyping platform based in easy-to-use hardware and software. Arduino
are able to read inputs – light-on sensor, a finger on a button or a Twitter message – and turn it into an output
– activating of a motor, turning on an LED, publishing something online. You can tell your board what to do by
sending a set of instructions to the microcontroller on the board. To do so, you use the Arduino programming
language (based on Wiring) and the Arduino
Surf to
www.arduino.cc
5.
Overview
A reed contact switch is a normally open contact, which closes in the presence of a magnetic field. These
modules contain a 10K Ω pull-up resistor.
voltage ..................................................................................................................... 5 VDC
connection .................................................... 3 pins, + (middle pin), - (ground) and S (signal)
dimensions ...................................................................................................... 25 x 15 mm
weight .......................................................................................................................... 2 g
Use this device with original accessories only. Velleman nv cannot be held responsible in the event
of damage or injury resulting from (incorrect) use of this device. For more info concerning this
product and the latest version of this manual, please visit our website www.velleman.eu. The
information in this manual is subject to change without prior notice.
© COPYRIGHT NOTICE
The copyright to this manual is owned by Velleman nv. All worldwide rights reserved. No part of this
manual may be copied, reproduced, translated or reduced to any electronic medium or otherwise without the
prior written consent of the copyright holder.
V. 01 – 06/02/2017
®
®
software IDE (based on Processing).
and
www.arduino.org
for more information.
Arduino
®
A0
+5 V
GND
VMA308
3
®
boards
VMA308
S
+
-
©Velleman nv
