- Page 1 VMA323 CURRENT SENSOR ACS712 MODULE – 20 A (DC) USER MANUAL...
- Page 2 Nor Velleman nv nor its dealers can be held responsible for any damage (extraordinary, incidental or indirect) – of any nature (financial, physical…) arising from the possession, use or failure of this product.
- Page 3 VMA323 Overview VMA323 The Allegro ACS712 provides economical and precise solutions for AC or DC current sensing in industrial, ® commercial, and communications systems. The device package allows for easy implementation by the customer. Typical applications include motor control, load detection and management, switched-mode power supplies, and overcurrent fault protection.
- Page 4 VMA323 ******Code Begin****** Measuring Current Using ACS712 const int analogIn = A0; int mVperAmp = 100; // use 100 for 20A Module and 66 for 30A Module int RawValue= 0; int ACSoffset = 2500; double Voltage = 0; double Amps = 0;...
- Page 5 © COPYRIGHT NOTICE The copyright to this manual is owned by Velleman nv. All worldwide rights reserved. No part of this manual may be copied, reproduced, translated or reduced to any electronic medium or otherwise without the prior written consent of the copyright holder.
