Electrolux Frigidaire GRFG2353AF Use & Care Manual
  1. Manuals
  2. Brands
  3. Electrolux Manuals
  4. Refrigerator
  5. Frigidaire GRFG2353AF
  6. Use & care manual

Electrolux Frigidaire GRFG2353AF Use & Care Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Introduction .......................................................2
Important Safety Information ....................3
Features ..............................................................7
Installation .........................................................9
Door Removal .................................................. 11
Door Handle Installation ............................. 16
Water Supply Connection .......................... 17
Controls And Settings ................................. 19
Frigidaire.com USA 1-800-374-4432
REFRIGERATOR
use
care
&
Ice Maker .........................................................30
Storage Features .......................................... 32
Normal Operating Sounds ........................ 39
Filter Replacement ......................................40
Care & Cleaning ............................................ 43
Troubleshooting .......................................... 45
Limited Warranty .........................................50
A17856402 (September 2021)
Frigidaire.ca Canada 1-800-265-8352

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Frigidaire GRFG2353AF and is the answer not in the manual?

Questions and answers

Related Manuals for Electrolux Frigidaire GRFG2353AF

Summary of Contents for Electrolux Frigidaire GRFG2353AF

  • Page 1: Table Of Contents

    REFRIGERATOR care & Introduction ............2 Ice Maker ............30 Important Safety Information ....3 Storage Features .......... 32 Features ..............7 Storing Food and Saving Energy ... 38 Installation ............9 Normal Operating Sounds ......39 Door Removal ..........11 Filter Replacement ........40 Door Handle Installation ......16 Care &...

  • Page 2: Introduction

    INTRODUCTION family  Installation Checklist Welcome to our Doors Thank you for bringing Frigidaire into ˆ Handles are secure and tight your home! We see your purchase as the ˆ Door seals completely to cabinet on beginning of a long relationship together. all sides This manual is your resource for the use Leveling...

  • Page 3: Important Safety Information

    IMPORTANT SAFETY INFORMATION CAUTION WARNING CAUTION Risk of fire or explosion. Please read all instructions before using Dispose of refrigerator properly this appliance. in accordance with the applicable federal or local regulations. Flammable refrigerant used. Safety Definitions CAUTION Risk of fire or explosion This is the safety alert symbol.
  • Page 4 IMPORTANT SAFETY INFORMATION Child Safety Destroy or recycle the carton, plastic bags, and any exterior wrapping material immediately after the refrigerator is unpacked. Children should NEVER use these items to play. Cartons covered with rugs, bedspreads, plastic sheets or stretch wrap may become airtight chambers, and can quickly cause suffocation.
  • Page 5 IMPORTANT SAFETY INFORMATION Electrical information IMPORTANT • The refrigerator must be plugged into its own dedicated 115 Volt, 60 To turn off power to your refrigerator Hz., 15 Amp, AC only electrical outlet. you must unplug the power cord from The power cord of the appliance the electrical outlet.
  • Page 6 FEATURES Internal Water Dispenser Model Water Filter Edge-to-edge Glass Shelving Condiment Bin Standard Bins L-Shaped Bin Crisper Drawers Dairy Bin Adjustable Temp Drawer (ATD) Flipper Mullion ATD Controls Internal Water Dispenser Upper Freezer Basket Standard Bin Lower Freezer Basket Flipper Guide Freezer Ice Maker Air Filter Dispenser Control Display...

  • Page 7: Features

    FEATURES External Water Dispenser Model ic k F re Water Filter Edge-to-edge Glass Shelving Condiment Bin Standard bin L-Shaped Bin Crisper Drawers Dairy Bin Adjustable Temp Drawer (ATD) Flipper Mullion ATD Controls Gallon Bin Upper Freezer Basket Slim Bin Lower Freezer Basket Fresh Food Ice Maker &...
  • Page 8 INSTALLATION Tools Necessary: (OR) Phillips Head ⅜" and ¼" Quadrex Head Socket ⅜" Fixed Adjustable Screwdriver Allen Wrench Wrench Wrench Wrench Components Provided: WARNING Top Hinge Top Hinge Cover Front Cover Rear This appliance is intended to be used Screw Screw in household and similar applications such as:...

  • Page 9: Installation

    INSTALLATION  NOTE If your refrigerator is placed with the door hinge side against a wall, you may have to allow additional space so the door can be opened wider. Door opening Door Door Your refrigerator should be positioned to allow easy access to a counter when removing food.
  • Page 10 INSTALLATION Flipper Mullion Mullion Guide Adjust Flipper Mullion for proper connection with the mullion guide by ensuring the flipper mullion is folded and Flipper perpendicular to the fresh food door. If Mullion the mullion guide is not in the correct position, it could prevent the door from closing completely.

  • Page 11: Door Removal

    DOOR REMOVAL Getting through narrow spaces If your refrigerator will not fit through an entrance area, you can remove the doors. Check first by measuring the entrance. To prepare for removing the doors: Make sure the electrical power cord is unplugged from the wall outlet. 2.
  • Page 12 DOOR REMOVAL 3. Trace lightly around the door’s top 5. Pull the water tube out of the hinges with a pencil. This makes re- conduit from the top of the cabinet. installation easier. 4. Remove bulkhead cover at rear  of unit to access water tubing.
  • Page 13 DOOR REMOVAL To reinstall the refrigerator Remove hex screws from top hinge plate, then remove the top hinge. doors: Replace three bottom hinge screws and hinges on both sides of the cabinet. Ensure screws are tightly snug to hinges on both sides of the cabinet before re-installing doors 2.
  • Page 14 DOOR REMOVAL To reset door pin:  NOTE If doors are removed at less than a 40 degree angle, the pin returns to the home position. It can be reset by turning the Upon replacement, the tube needs to door upside down and using a 5/32” Allen be fully inserted up to the marking line.
  • Page 15 DOOR REMOVAL Removing Freezer Drawer Replacing Freezer Drawer Extend the Freezer slides from the unit. CAUTION 2. Carefully align support pin with hooks on end of freezer slides and Drawer is heavy. Use caution when lifting. then lower freezer door onto slides. 3.

  • Page 16: Door Handle Installation

    DOOR HANDLE INSTALLATION CAUTION Wear gloves and safety goggles. Use extreme CAUTION when installing these handles. Door Handle Mounting Mounting Refrigerator Handles Instructions Remove handles from carton and any other protective packaging. Position refrigerator handle end caps over upper and lower pre- installed shoulder bolts (A) that are fastened into door, ensuring the holes for the set screws are...

  • Page 17: Water Supply Connection

    WATER SUPPLY CONNECTION • A water supply line made of ¼ inch (6.4 mm) OD, copper or stainless WARNING steel tubing. To determine the length of tubing needed, measure To avoid electric shock, which can the distance from the water inlet cause death or severe personal injury, valve at the back of the refrigerator disconnect the refrigerator from to your cold water pipe.
  • Page 18 WATER SUPPLY CONNECTION 4. If you use copper tubing - Slide Steel brass compression nut, then Clamp ferrule (sleeve) onto water supply Brass line. Push water supply line into Compression water valve inlet as far as it will go (¼ inch/6.4 mm). Slide ferrule Ferrule (sleeve) into valve inlet and finger (Sleeve)

  • Page 19: Controls And Settings

    CONTROLS AND SETTINGS Internal Water Dispenser Control Display Mode Views Your display is equipped with a sleep and lock mode to prevent accidental changes to the unit settings during opening and closing of the doors. When both doors are closed, the display will be in sleep mode. When either door is first opened, the display will be in lock mode where all the current settings are visible but dimmed.
  • Page 20 CONTROLS AND SETTINGS Internal Water Dispenser Control Display Change Select Freezer or Refrigerator icon to Temperature change temperature. Select +/- buttons to set the temperature Freezer -6˚F/-21˚C – control range: +6˚F/-15˚C Refrigerator +34˚F/+1˚C – control range: +44˚F/+7˚C Clear Alerts Resets any alarms that are active and illuminated on the display (DOOR OPEN, HIGH TEMP, POWER OUTAGE).
  • Page 21 CONTROLS AND SETTINGS Internal Water Dispenser Sabbath Mode Clear Alerts Door Open The Sabbath Mode is a feature that disables portions of the refrigerator If the freezer or refrigerator doors have and its controls in accordance with been left open for five minutes or more, observance of the weekly Sabbath and an alarm will sound and the door open religious holidays within the Orthodox...
  • Page 22 CONTROLS AND SETTINGS External Water Dispenser Control Display Sleep Mode Display Sleep Mode As a default, the display will go to sleep after a short time. If any icon is pressed, the display will be awakened. After a short time, it will go back to sleep. When in sleep mode, wake up the display to confirm ice maker is On/Off.
  • Page 23 CONTROLS AND SETTINGS External Water Dispenser Control Display Freeze Boost (on/off) Ice Maker Prior to grocery shopping, we Press and hold for 3 seconds to turn recommend you activate Freeze ice maker on/off. When indicator is Boost to lower the temperature and lit, ice maker is on.
  • Page 24 CONTROLS AND SETTINGS External Water Dispenser Control Display Adjusting Temp Crush Illuminates when temperatures are Press the Crush key to select changed on the display and will crushed ice. An indicator light ill be remain illuminated until the desired illuminated above the active feature. temperatures are reached inside ˚F/˚C the refrigerator and freezer.
  • Page 25 CONTROLS AND SETTINGS External Water Dispenser Control Display Clear Alerts Sabbath Mode Door Open The Sabbath Mode is a feature that disables portions of the refrigerator If the freezer or refrigerator doors are and its controls in accordance with left open for five minutes or more, an observance of the weekly Sabbath and alarm sounds and the door open indicator religious holidays within the Orthodox...

  • Page 26: Automatic Ice & Water Dispenser

    AUTOMATIC ICE & WATER DISPENSER External Dispenser - Refrigerator Ice Maker Priming the water supply system  NOTE Using the dispenser after The water dispenser has a built-in de- installation vice that shuts off the water flow after Before making ice for the first time, be three minutes of continuous use.
  • Page 27 AUTOMATIC ICE & WATER DISPENSER External Dispenser - Refrigerator Ice Maker Turning the refrigerator ice Ice maker/dispenser tips maker on and off • If your refrigerator is not connected to a water supply or the water Ice production is controlled by the ice supply is turned off, turn off the ice maker’s On/Off feature on the control maker as described in the previous...
  • Page 28 AUTOMATIC ICE & WATER DISPENSER External Dispenser - Refrigerator Ice Maker Cleaning the ice maker CAUTION Clean the ice maker and ice bin at regular intervals, especially prior to vacation or moving. NEVER use an ice pick or similar sharp instrument to break up the ice.
  • Page 29 AUTOMATIC ICE & WATER DISPENSER Internal Water Dispenser (select models) Your refrigerator is equipped with an Before dispensing, please ensure internal water dispenser mounted inside Water Dispenser is enabled on the the cabinet, on the left hand fresh food display (LEDs above button are lit). door.

  • Page 30: Ice Maker

    ICE MAKER Freezer Ice Maker Freezer Ice Maker Ice Maker Operation & Care After the refrigerator is installed properly, the ice maker can produce ice within on off 24 hours. When using the ice maker for the first time, and in order for it to work properly, it is necessary to clear air from the water tubing and the filter.
  • Page 31 ICE MAKER Freezer Ice Maker Cleaning the ice maker bin Clean the ice maker and ice bin at regular intervals, especially prior to vacation or moving. Turn off the ice maker. 2. Remove the ice bin. 3. Empty and carefully clean the ice bin with mild detergent.

  • Page 32: Storage Features

    STORAGE FEATURES Shelves Reposition the Air Seal For glass shelves: CAUTION Remove air seal by pushing seal straight back. To avoid personal injury or property 2. Position the air seal towards the damage, handle tempered glass shelves outside edge of the shelf to avoid the carefully.
  • Page 33 STORAGE FEATURES Drawers To remove the auto humidity control membrane: Your refrigerator includes a variety of Remove any shelves placed above the storage drawers. crisper cover then lift up and remove Crispers the crisper cover from the unit. Crisper drawers are designed for storing 2.
  • Page 34 STORAGE FEATURES To remove the Crisper Drawer with Pure Air Produce Keeper™ for cleaning: Pull the drawer out until it stops. 2. Lift the front slightly and remove the drawer. Removing Crisper Drawer CAUTION 2. Push the crisper straight once the Remove the produce keeper prior to bottom rollers clear the front deli washing the crisper drawer.
  • Page 35 STORAGE FEATURES Adjustable Temp Drawer Ideal for storage of deli meats, cheese, Lock Control and beverages. The drawer automatically defaults to a locked state to prevent any unwanted use. To change the drawer’s settings, it first needs to be unlocked. To unlock, press and hold the UNLOCK icon for 3 seconds.
  • Page 36 STORAGE FEATURES Doors Freezer Accessories Storage bins (varies by model) Your freezer has baskets and dividers that can be adjusted to your needs. The doors to your refrigerator Remove Upper Freezer Basket compartment use a system of modular storage bins. All of these bins are Open freezer drawer fully.
  • Page 37 STORAGE FEATURES To Remove Lower Freezer Upper Freezer Basket Basket: Replacement Open Freezer drawer completely. Open freezer compartment completely. 2. Locate basket clips in the rear corners of the basket and pull them 2. Pull both upper slides out of the out to remove.

  • Page 38: Storing Food And Saving Energy

    STORING FOOD AND SAVING ENERGY Boost to freeze your food faster it Ideas for storing foods will remain active up to 24 hours. Refrigerator storage • Activating Freeze Boost will help your freezer more efficiently • Keep the refrigerator compartment maintain the selected temperature between 34°F and 40°F with an after placing new purchases with...

  • Page 39: Normal Operating Sounds

    NORMAL OPERATING SOUNDS G. Compressor Modern, high-  NOTE efficiency compressors run much faster than older models. The compressor may have a high- Energy efficient foam in your refrigera- pitched hum or pulsating sound. tor is not a sound insulator. H.

  • Page 40: Filter Replacement

    FILTER REPLACEMENT Air filter Ordering replacement filters The air filter is located at the top of the Order new filters by calling 877-808- air tower. 4195, online at www.frigidaire.com/ store, or through the dealer where you bought your refrigerator. You may want to consider ordering extra filters when you first install your refrigerator.
  • Page 41 FILTER REPLACEMENT Replacing the More about your Advanced Water Filter Water Filter The water filter The PurePour™ ice and is located at the water filter system is tested bottom left of and certified to NSF/ANSI the refrigerator Standards 42, 53, 401 and compartment next CSA B483.1 for the reduction to the Adjustable...
  • Page 42 FILTER REPLACEMENT 5. Push firmly until the cartridge snaps into place (you should hear a click as the cartridge engages the snap-in connector). 6. Press a drinking glass against the water dispenser while checking for any leaks at the filter housing. Any spurts and sputters that occur as the system purges air out of the dispenser system are normal.

  • Page 43: Care & Cleaning

    CARE & CLEANING Protecting your investment Keeping your refrigerator clean maintains its appearance and prevents odor build-up.  NOTE Do not use abrasive cleaners such as window sprays, scouring cleansers, flammable fluids, cleaning waxes, concentrated detergents, bleaches, or cleansers containing petroleum products on plastic parts, interior doors, gaskets, or cabinet liners.
  • Page 44 CARE & CLEANING Vacation and moving tips Occasion Tips Short • Leave refrigerator operating during vacations of three weeks or less. Vacations • Use all perishable items from refrigerator compartment. • Turn automatic ice maker off and empty ice bucket, even if you will only be gone a few days.

  • Page 45: Troubleshooting

    TROUBLESHOOTING Let us help you troubleshoot your concern! This section will help you with common issues. If you need us, visit our website, chat with an agent, or call us. We may be able to help you avoid a service visit. If you do need service, we can get that started for you! 1-800-265-8352 (Canada) 1-800-374-4432 (United States) Frigidaire.com...
  • Page 46 TROUBLESHOOTING Concern Potential Cause Common Solution Automatic Ice Maker (Cont’d) Ice maker is • Ice maker is producing • In a Standard Depth model, the not making less ice than you refrigerator ice maker should enough ice. expect. produce 3.0 to 3.4 pounds of ice per 24 hours.
  • Page 47 TROUBLESHOOTING Concern Potential Cause Common Solution Automatic Ice Maker (Cont’d) Ice cubes • Ice cubes are not being • Remove ice container and discard are freezing used frequently enough ice. The ice maker will produce together. or interruption of power fresh supply.
  • Page 48 TROUBLESHOOTING Concern Potential Cause Common Solution Water • The water dispensing • Add ice to cup or container before not cold system is not designed dispensing water. enough. to chill water. Water has • Water has not been • Draw and discard 10-12 glasses of an odd dispensed for an water to freshen the supply.
  • Page 49 At times it will run faster, such as after a defrost cycle. Digital Temperature Setting Display Digital • Electronic control • Call your Electrolux service temperature system has detected a representative, who can interpret displays an performance problem.

  • Page 50: Limited Warranty

    Your appliance is covered by a one year limited warranty. For one year from your original date of purchase, Electrolux will pay all costs for repairing or replacing any parts of this appliance that prove to be defective in materials or workmanship when such appliance is installed, used and maintained in accordance with the provided instructions.
  • Page 52 home welcome Our home is your home. Visit us if you need help with any of these things: owner support accessories service registration (See your registration card for more information.) Frigidaire.com 1-800-374-4432 Frigidaire.ca 1-800-265-8352...
