All about the
Use
of your
Important Safety Instructions ......................2
Features at a Glance ...................................4
Installation ................................................5
Door Removal Instructions ..........................9
Installing Door Handles .............................11
Connecting Water Supply ..........................14
Controls ...................................................16
Automatic Ice & Water Dispenser ..............22
www.frigidaire.com USA 1-800-944-9044
&
Care
Refrigerator
TA B L E O F C O N T E N T S
Automatic Ice Maker - Freezer ...................24
Storage Features ......................................25
Storing Food and Saving Energy ................29
Normal Operating Sounds and Sights .........30
Changing the Filter ...................................31
Care and Cleaning ....................................34
Before you Call .........................................38
Major Appliance Warranty .........................42
www.frigidaire.ca Canada 1-800-265-8352
Advertisement
Table of Contents
Related Manuals for Electrolux Frigidaire FPBS2777RF9
Summary of Contents for Electrolux Frigidaire FPBS2777RF9
-
Page 1: Table Of Contents
All about the & Care Refrigerator of your TA B L E O F C O N T E N T S Important Safety Instructions ......2 Automatic Ice Maker - Freezer ....24 Features at a Glance ........4 Storage Features ........25 Installation ..........5 Storing Food and Saving Energy ....29 Door Removal Instructions ......9... -
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Installation Checklist WARNING Doors Please read all instructions before using this refrigerator. Handles are secure and tight Door seals completely to cabinet on all For your Safety sides • DO NOT store or use gasoline, or other ... - Page 3 IMPORTANT SAFETY INSTRUCTIONS you are getting rid of your old refrigerator or • If the power cord is damaged, it should freezer, please follow the instructions below to be replaced by an authorized service help prevent accidents. technician to prevent any risk. Proper Disposal of Refrigerators/Freezers •...
-
Page 4: Features At A Glance
FEATURES AT A GLANCE *Features may vary according to model *Dairy *LED Compartment Cluster Lights *Air *Water *Fresh Food Filter Filter Ice Maker Flipper Guide Flipper *Can Rack Mullion Spillsafe ® Flip Shelf Shelves *LED Cluster Light Slide-Under *LED Cluster Shelf Light *LED Cluster... -
Page 5: Installation
INSTALLATION Tools Necessary: (OR) 3/8" (10mm) Phillips Fixed Adjustable Head or Wrench Wrench Socket #2 Square Wrench Set Drive Head Components Provided: CAUTION Top Hinge Top Hinge Cover Front Cover Rear Screw Screw o Not install the refrigerator where the temperature will drop below 55°F (13°C) or rise above 110°F (43°C). - Page 6 INSTALLATION 1 Slightly open freezer drawer. Lift the toe grille and gently pull forward (see CAUTION illustration). Toe grilles vary by model. 2 You can raise or lower each door. Use o Not loosen or remove these 3 hex a ⅜ inch socket wrench to turn the screws.
- Page 7 INSTALLATION To adjust the door stop: 4 Rotate door stop until it makes contact with the lower hinge. Door stop is adjustable between 85 to 145 degrees. 5 Re-tighten screw. NOTE View shown is looking up at the bottom of the refrigerator door.
- Page 8 INSTALLATION 3 Lift the door while adjusting the washer. 2 Adjust flipper mullion height. For proper To raise the door, rotate washer clockwise connection with the flipper mullion guide, (when viewed from the bottom). To lower there should be a separation about the door, rotate washer counter-clockwise thickness of a coin (0.060 inches, or (when viewed from the bottom).
-
Page 9: Door Removal Instructions
DOOR REMOVAL INSTRUCTIONS Getting through narrow spaces To remove the refrigerator doors: 1 Trace lightly around the door’s top hinges If your refrigerator will not fit through an with a pencil. This makes reinstallation entrance area, you can remove the doors. easier. - Page 10 DOOR REMOVAL INSTRUCTIONS Removing Freezer Drawer 1 Remove 4 hex head drawer screws. Press 2 Lift up drawer to remove. Press DO NOT Water Remove Other Line Screws Approximately 5 feet NOTE You will be pulling approximately five feet of Remove water tube from the back of the refrigerator.
-
Page 11: Installing Door Handles
INSTALLING DOOR HANDLES Door Handle Mounting Mounting Refrigerator Handles Instructions for Frigidaire 1 Remove handles from carton and any other protective packaging. 2 Position fresh food handle end caps over upper and lower pre-installed shoulder bolts (A) that are fastened into door, ensuring the holes for the set screws are facing towards the opposite door. - Page 12 INSTALLING DOOR HANDLES Door Handle Mounting Mounting Refrigerator Handles Instructions for Frigidaire Gallery ® 1 Remove handles from carton and any other protective packaging. 2 Position fresh food handle end over upper and lower pre-installed shoulder bolts (A) that are fastened into door, ensuring the holes for the set screws are facing towards the opposite door.
- Page 13 INSTALLING DOOR HANDLES Door Handle Mounting Mounting Refrigerator Handles Instructions for Frigidaire Professional ® 1 Remove handles from carton and any other protective packaging. 2 Position fresh food handle end over upper and lower pre- installed shoulder bolts (A) that are fastened into door, ensuring the holes for the set screws are facing towards the opposite door.
-
Page 14: Connecting Water Supply
CONNECTING THE WATER SUPPLY • A shutoff valve to connect the water supply line to your household water system. DO WARNING NOT use a self-piercing type shutoff valve. • Do not re-use compression fitting or use To avoid electric shock, which can cause thread seal tape. - Page 15 CONNECTING THE WATER SUPPLY To Connect Water Supply Line To Steel Plastic Water Clamp Ice Maker Inlet Valve Tubing to Ice Maker Fill Brass 1 Disconnect refrigerator from electric power Tube Compression source. Ferrule 2 Place end of water supply line into sink or (Sleeve) bucket.
-
Page 16: Controls
FRIGIDAIRE & CONTROLS FRIGIDAIRE GALLERY User Interface (options may vary) Enlarged view of user interface display menu (options may vary) - Page 17 FRIGIDAIRE & CONTROLS FRIGIDAIRE GALLERY Options May Vary water filter Displays the current status of the water filter (Good, Order, options Used to enter and exit the or Replace). To reset the (∧ or ∨) options menu and make filter status to “Good”, press selections.
- Page 18 FRIGIDAIRE & CONTROLS FRIGIDAIRE GALLERY Alarms Sabbath Mode Power Failure The Sabbath Mode is a feature that disables portions of the refrigerator and its controls In the event of a power failure, the power fail in accordance with observance of the weekly alert will be illuminated.
- Page 19 FRIGIDAIRE CONTROLS PROFESSIONAL User Interface In-Door Controls (options may vary) POWER Press and hold for three seconds ON-OFF to turn off the cooling system. It also turns off the ice maker and all dispenser functions. The display will read “OFF”. DEFAULT Press and hold for three seconds to SETTINGS...
- Page 20 FRIGIDAIRE CONTROLS PROFESSIONAL Dispenser Controls Alarms (options may vary) Power Failure In the event of a power failure, the power fail alert will be illuminated. Press “mute alarm” to acknowledge the alarm. Other modes may be turned off until the alarm is acknowledged. While a power failure alert is displayed on the control panel, the unit will continue normal operation.
- Page 21 FRIGIDAIRE CONTROLS PROFESSIONAL Sabbath Mode The Sabbath Mode is a feature that disables portions of the refrigerator and its controls in accordance with observance of the weekly Sabbath and religious holidays within the Orthodox Jewish community. Sabbath Mode is turned ON and OFF by simultaneously pressing and holding both the freezer “-”...
-
Page 22: Automatic Ice & Water Dispenser
AUTOMATIC ICE & WATER DISPENSER Priming the water supply system Turning the fresh food ice maker on and off CAUTION Ice production is controlled by the ice maker’s On/Off feature on the control panel. Pressing For proper dispenser operation, recommended the On/Off feature turns the ice maker on &... - Page 23 AUTOMATIC ICE & WATER DISPENSER Ice maker/dispenser tips 3 Empty and carefully clean the ice bin with mild detergent. Do not use harsh or • If your refrigerator is not connected to a abrasive cleaners. Rinse with clear water. water supply or the water supply is turned 4 Allow the ice bin to dry completely before off, turn off the ice maker as described in replacing in the freezer.
-
Page 24: Automatic Ice Maker - Freezer
AUTOMATIC ICE MAKER - FREEZER (SELECT MODELS) Operation & Care of the Freezer Ice maker tips Ice Maker (select models) • The following sounds are normal when the ice maker is operating: After the refrigerator is installed properly, the ice maker can produce ice within 24 hours. - Motor running When using the ice maker for the first time, and - Ice dropping into ice bin... -
Page 25: Storage Features
STORAGE FEATURES Reposition the Air Seal CAUTION For slide-out shelves & crisper shelves: 1 Remove air seal by pushing down on the To avoid personal injury or property damage, flap with a downward rotation. handle tempered glass shelves carefully. Shelves may break suddenly if nicked, scratched, or 2 Position the air seal towards the outside exposed to sudden temperature change. - Page 26 STORAGE FEATURES Drawers 2 Lift the front slightly and remove the drawer. Your refrigerator includes a variety of storage drawers. These drawers are located in fixed positions at the bottom of the fresh food compartment. Crispers Crisper drawers are designed for storing fruits, vegetables, and other fresh produce.
- Page 27 STORAGE FEATURES 5 Lower the bin onto supports until locked in Dairy compartment place. Use the dairy compartment, at the top of the fresh food compartment door, for short-term storage of cheese, spreads, or butter. The dairy Dairy Compartment compartment is designed to be warmer than the open area and includes a lift-up cover and a dairy divider (select models).
- Page 28 STORAGE FEATURES Dividers Removal NOTE Lift up on the front of the divider and pull out. If basket is not resting on stabilizer bar retainer clips, the drawer will not close properly. Middle Basket Divider Removing Freezer Basket Instructions Retainers 1 Locate the basket clips in the rear corners of the basket and pull them out to remove.
-
Page 29: Storing Food And Saving Energy
STORING FOOD AND SAVING ENERGY Ideas for storing foods • Activating “quick freeze” also will help your freezer more efficiently maintain the Fresh food storage selected temperature after placing new purchases with pre-existing frozen foods. • Keep the fresh food compartment between 34°F and 40°F with an optimum •... -
Page 30: Normal Operating Sounds And Sights
NORMAL OPERATING SOUNDS AND SIGHTS Understanding the sounds you NOTE may hear Your new, high-efficiency refrigerator may Energy efficient foam in your refrigerator is introduce unfamiliar sounds. These sounds not a sound insulator. normally indicate your refrigerator is operating correctly. -
Page 31: Changing The Filter
CHANGING THE FILTER Air filter Ordering replacement filters (select models) The air filter is located under the utility bin. Order new filters by calling 877-808-4195, online at www.frigidaire.com/store, or through Replacing your PureAdvantage the dealer where you bought your refrigerator. You may want to consider ordering extra filters air filter when you first install your refrigerator. - Page 32 FRIGIDAIRE CHANGING THE FILTER PROFESSIONAL Locating the Filters More about your Advanced Water Filter Your refrigerator is equipped with water filtering system. The water filter system filters The PureSource Ultra II all dispensed drinking water, as well as the ice and water filter system is water used to produce ice.
- Page 33 FRIGIDAIRE & CHANGING THE FILTER FRIGIDAIRE GALLERY Locating the Filters More about your Advanced Water Filter Your refrigerator is equipped with water filtering system. The water filter system filters The PureSource Ultra ice and all dispensed drinking water, as well as the water filter system is tested and water used to produce ice.
-
Page 34: Care And Cleaning
CARE & CLEANING Protecting your investment Keeping your refrigerator clean maintains its appearance and prevents odor build-up. Wipe up any spills immediately and clean the freezer and fresh food compartments at least twice a year. NOTE Do not use abrasive cleaners such as window sprays, scouring cleansers, flammable fluids, cleaning waxes, concentrated detergents, bleaches, or cleansers containing petroleum products on plastic parts, interior doors, gaskets, or cabinet liners. - Page 35 CARE & CLEANING Care & Cleaning Tips Part What To Use Tips and Precautions Interior & Door • Soap and water Use two tablespoons of baking soda in one Liners quart of warm water. Be sure to wring • Baking soda and water excess water out of sponge or cloth before cleaning around controls, light bulb or any electrical part.
- Page 36 CARE & CLEANING Ice Chute Extension Installing the Ice Chute (select Extension models) The ice chute extension is designed to better 1 Turn the refrigerator off using the direct ice flow into containers. button on the control panel (refer to the “Controls”...
- Page 37 CARE & CLEANING Replacing LED Lights Replacing Light Bulbs (select models) (select models) CAUTION The fresh food compartments of your refrigerator may have LED lights. Always use Wear gloves when replacing incandescent Frigidaire parts for replacement. light bulbs to avoid getting cut. To replace LED Lights: 1 Unplug your refrigerator’s power cord.
-
Page 38: Before You Call
BEFORE YOU CALL 1-800-944-9044 (United States) Visit our web site at 1-800-265-8352 (Canada) www.frigidaire.com CONCERN POTENTIAL CAUSE COMMON SOLUTION AUTOMATIC ICE MAKER Ice maker is • Ice maker is turned off. • Turn on ice maker. For the fresh food ice not making maker, press ice maker on-off once. - Page 39 BEFORE YOU CALL CONCERN POTENTIAL CAUSE COMMON SOLUTION AUTOMATIC ICE MAKER (continued) Freezer ice • Ice maker wire signal arm • Move any item or frozen ice cubes that may maker will is being held down by a block the signal arm from being in the off or not stop package in the freezer upward position.
- Page 40 BEFORE YOU CALL CONCERN POTENTIAL CAUSE COMMON SOLUTION DISPENSER (Ice & Water) (continued) Water not • The water dispensing • Add ice to cup or container before dispensing cold enough. system is not designed to water. chill water. Water has •...
- Page 41 BEFORE YOU CALL CONCERN POTENTIAL CAUSE COMMON SOLUTION WATER/MOISTURE/FROST INSIDE REFRIGERATOR Moisture • Weather is hot and humid. • The rate of frost buildup and internal sweating collects on increases. inside of • Door is slightly open. • See CONCERN column OPENING/CLOSING OF refrigerator DOORS/DRAWERS.
-
Page 42: Major Appliance Warranty
Your appliance is covered by a one year limited warranty. For one year from your original date of purchase, Electrolux will pay all costs for repairing or replacing any parts of this appliance that prove to be defective in materials or workmanship when such appliance is installed, used and maintained in accordance with the provided instructions.
