TW90 SportBuds
User Guide | Models: GDI-EXTW90...99
Quick Start
1 Place SportBuds in Charging Carrying Case and Charge the
Case until SportBuds are fully charged
2 Remove the SportBuds from the Charging Carrying Case to
turn them on
The SportBuds will automatically pair to each other
3
4 Search your Bluetooth Connection on your Smart Device
for "ECOXGEAR-R"
5 Pair & Play
Multi-Function Button Chart
PRESS ONCE
PRESS & HOLD FOR 2 SECONDS
DOUBLE-CLICK
AUDIO
INCREASE VOLUME
DECREASE VOLUME
PAUSE AUDIO
PLAY AUDIO
ADVANCE TRACK SELECTION
PREVIOUS TRACK SELECTION
ECOTALK VOICE ASSISTANT
PHONE CALLS
ANSWER INCOMING PHONE CALL
END PHONE CALL
REJECT INCOMING PHONE CALL
TWO-CALL HANDLING
END CURRENT/ANSWER INCOMING
PLACE CURRENT ON HOLD
SWITCH BETWEEN PHONE CALLS
END CURRENT CALL
Control Buttons & Operations Details
On / Off
Remove the SportBuds from the Charging Carrying Case to turn them on. The SportBuds
will automatically pair to each other.
Return the SportBuds to their slots in the Charging Carrying Case to turn them off.
Alternately, you can PRESS & HOLD the Multi-Function Button
2 seconds to turn them on. PRESS & HOLD
or until the LED flashes RED 3 times, to turn the SportBuds off. Both SportBuds will
announce, "Power off. "
Once on, the Left SportBud will announce, "Left channel," the Right SportBud will
announce, "Right channel, pairing," and the LED Indicator on the right SportBud will flash
BLUE and RED. The SportBuds will enter into Bluetooth Pairing Mode and search for your
Bluetooth device to pair and connect.
Refer to Bluetooth Pairing & Audio for details.
Volume
While listening to music or on a phone call, DOUBLE-CLICK the Multi-Function
Button on the Right SportBud to increase the volume.
DOUBLE-CLICK
NOTE: Some Bluetooth devices must be manually set at maximum audio level.
•
Your SportBuds will beep to indicate when the maximum or minimum volume
level is reached.
• • • • • • • • • • • • • • • • • • • • • • •
Phone Calls
• •
When answering an incoming phone call, the LED Indicator on the Right SportBud will
flash RED.
When ending a call, the SportBuds will beep.
When rejecting a call, the SportBuds will beep twice & announce, "Call reject. "
• •
If you have an incoming phone call while already on a call:
RIGHT
• PRESS & HOLD
• •
answer the incoming call.
LEFT
• PRESS ONCE on either SportBud to place the current call on hold and answer the
•
incoming call.
RIGHT
•
° PRESS
RIGHT
° PRESS & HOLD
• • • • • • • • • • • • • • • • • • • • • • •
° PRESS & HOLD
RIGHT
• • • • • • • • • • • • • • • • • • • • • • •
NOTE: This feature is only available when paired to a device with Two-Call
Handling functionality.
LEFT
•
EcoTalk - Voice Assistant
LEFT
To activate Voice Assistant (Siri, OK Google, etc.) PRESS
The SportBuds will beep. Once your Voice Assistant is activated, speak your command into
•
the built-in microphone on the SportBuds.
EITHER
NOTE: Before using the EcoTalk function, your device must be connected to the
•
SportBuds via Bluetooth. Not all devices have voice assistant functionality; refer
EITHER
to your device for details.
• • • • • • • • • • • • • • • • • • • • • • •
EITHER
Bluetooth Pairing & Audio
Connect to Your Smart Device & Play Audio
• • • • • • • • • • • • • • • • • • • • • • •
RIGHT
When your SportBuds are turned on for the first time, the LED Indicator on the right
•
earphone will flash BLUE and RED, indicating the unit is powered on and ready to pair. The
EITHER
units shall also announce, "Left channel," and "Right channel, pairing," when powered on.
•
Pairing Mode
EITHER
• • • • • • • • • • • • • • • • • • • • • • •
Pairing Mode will last for approximately 3 minutes. If no devices are paired within that time,
the SportBuds will automatically turn off.
EITHER
on both SportBuds for
on either SportBud for about 5 seconds,
on the Left SportBud to decrease the volume.
on the Right SportBud for 2 seconds to end the current call and
ONCE on either SportBud again to switch between both phone calls.
on either SportBud for 2 seconds to end the current call.
on either SportBud for 2 seconds to end the remaining call.
ONCE on the Left SportBud.
Turn on your smartphone's Bluetooth. Set the smartphone to Pairing Mode. Available
Bluetooth connections shall appear. Select 'ECOXGEAR-R' from the list of discovered
devices on your smartphone. Wait a few seconds until the connection is completed.
NOTE: Some Bluetooth devices may ask for a password. Enter, '0000' to connect.
When the 'ECOXGEAR-R' selection is made and the Bluetooth connection is complete,
your SportBuds will announce, "Second device connected," and the LED Indicator will flash
BLUE. Once connected, select and play your desired audio.
Your SportBuds should sync & wirelessly pair with most Bluetooth enabled devices. The
SportBuds remember the last device paired and will automatically search for previous
connections when they are turned on or when a device comes back into Bluetooth range.
If a connection is dropped, the SportBuds will look to re-establish that connection. If
Bluetooth is turned off on your smartphone, the SportBuds may NOT automatically look
for the device.
RECOMMENDATION: If you are not familiar with Bluetooth pairing for your smartphone, or
other Smart-Device, refer to the User Guide for your smartphone to learn how to add and
pair a new device (the TW90 SportBuds for instance) to your smartphone using Bluetooth.
Bluetooth Pairing & Connections
Once paired, should you have an issue switching between Bluetooth connections on
current or new devices, open the Bluetooth Section within the device currently connected
to the SportBuds and delete the 'ECOXGEAR-R' Bluetooth selection from your phone.
The SportBuds will then be available to pair & connect to an alternate Bluetooth enabled
smartphone / Audio Device.
If pairing is unsuccessful, turn off the SportBuds first and then re-pair again following the
above steps.
Charge Your SportBuds
LED Indicator
The LED indicator on the bottom of each SportBud will flash RED once every 20 seconds
when the batteries are running low.
Place both SportBuds in the Charging Carrying Case to charge them. The LED located on
the bottom of each SportBud indicates the charging status when charging:
• RED LED indicates charging in process
• LED turning off indicates a full charge
WARNING: SportBuds MUST be completely dry before charging. If wet, contact may cause
electric shock and injury.
The Charging Carrying Case can charge both SportBuds up to 4 times without needing to
be recharged.
NOTE: Approximately 1.5 hours of continuous charging time is required to fully charge
your SportBuds.
LED Indicator
