operation

switching on your unit

1. Connect the mains cable to the mains socket. The
internal temperature of your unit is controlled by a
thermostat. There are eight settings, of which position
7 is the coldest and position 0 turns the unit off.
2. Adjust the thermostat control dial to the desired position, bear in mind that the higher the
number, the lower the temperature. Position 3 is the recommended setting when operating at
normal room temperature (between 16°C and 43°C).
3. The unit may not operate at the correct temperature if it is in a particularly hot or a particularly
cold room, or if you open the doors often.
4. To ensure that the unit is cool enough to sufficiently chill your food, wait 24 hours before filling it
with food.
5. If you are concerned that your unit is not being kept
cold enough and wish to check the temperature, you
will need a special fridge/freezer thermometer. These
are available from most supermarkets and hardware
shops. Place the thermometer in either the fridge or
freezer compartment and leave overnight. The correct
temperature for the fridge compartment should be at
the recommended 0-8°C. The correct temperature for
the freezer compartment should be -18°C or lower.

adjusting the temperature

The internal temperature of the unit is controlled by a thermostat. The recommended position is
between 1 to 4 for colder working environments (i.e., during winter) and between 5 to 7 for hotter
environments. Please adjust according to the environment.

filling the water tank

Lift open the water tank flap cover. Fill drinking water into the
water tank through the hole.
• Do not fill above the level, otherwise, it may
overflow.
• Before filling with water, ensure that the water tank
is steady and in a correct position.
• Apart from drinking water, other beverages (such
as milk, juice, carbonated beverage, etc) are not
suggested to be used, especially beverages that
include grain must not be used (may result in
blockage and damage).
• Hot water must not be filled into the water tank
directly.
• Do not touch other parts of the unit when filling
water, it may lead to leakage.
