By Waterite, Inc.
Advanced Water Conditioners
Addendum for the F2TC Time Clock Valve
OWNER'S MANUAL ADDENDUM
FOR ALL FUSION² F SERIES AND FCA SERIES WATER CONDITIONERS
EQUIPPED WITH THE F2TC TIME CLOCK VALVE
THIS MANUAL IS TO BE LEFT WITH THE OWNER OF THE EQUIPMENT FOR
REFERENCE PURPOSES AND TECHNICAL GUIDANCE. IT IS STRONGLY
RECOMMENDED
THAT
QUALIFIED
DEALER
SERVICE
PERSONNEL
BE
CONTACTED IN THE EVENT OF AN UNKNOWN INTERRUPTION OF SERVICE OR
APPARENT
PRODUCT
MALFUNCTION.
AN
ANNUAL
PREVENTATIVE
MAINTENANCE INSPECTION BY A WATER PROFESSIONAL IS RECOMMENDED
TO ENSURE TROUBLE-FREE AND CONTINUOUS OPERATION.
www.waterite.com
R2
Waterite, Inc. ■ Winnipeg, MB Canada
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Waterite Fusion 2
Summary of Contents for Waterite Fusion 2
- Page 1 DEALER SERVICE PERSONNEL CONTACTED IN THE EVENT OF AN UNKNOWN INTERRUPTION OF SERVICE OR APPARENT PRODUCT MALFUNCTION. ANNUAL PREVENTATIVE MAINTENANCE INSPECTION BY A WATER PROFESSIONAL IS RECOMMENDED TO ENSURE TROUBLE-FREE AND CONTINUOUS OPERATION. www.waterite.com Waterite, Inc. ■ Winnipeg, MB Canada...
-
Page 3: Quick Reference Information
QUICK REFERENCE INFORMATION Arrow will point to Regen if a GENERAL OPERATION regeneration is expected “Tonight.” When the system is operating one of two displays will be shown: time of day or days until the next regenera- _______ tion. Pressing UP or DOWN will toggle between the two choices. - Page 4 Addendum to Main Manual for timeclock softeners and filters HOW TO USE THIS ADDENDUM THE DEALER... Before Installation: 1. Read GENERAL INSTRUCTIONS, QUICK REFERENCE INFORMANCE page, INSTALLER SETTINGS, and NORMAL OPERATING DISPLAYS. 2. Complete the SYSTEM SETUP section. a. Decide if unit is to be a softener or a filter. b.
-
Page 5: General Instructions
GENERAL INSTRUCTIONS The control valve offers multiple procedures that allow the valve to be modified to suit the needs of the installation. These procedures are: • SYSTEM SETUP • INSTALLER SETTINGS These procedures can be accessed in any order. Details on each of the procedures are provided on the following pages. - Page 6 STEP 4SS — Use UP or DOWN buttons to switch between: • 1-99 Days, or • 7-Days Between Regenerations Press SET HOUR button to go to Step 5SS. STEP 5SS — Use UP or DOWN buttons to switch between 60 Hz or 50 Hz option. Supply your own transformer if using 50 Hz option.
-
Page 7: Installer Settings
INSTALLER SETTINGS REGENERATION TIME & DAYS BETWEEN (1-99 day option) STEP 1ID – From normal mode, press SET HOUR + UP buttons simultaneously for 3 STEP 1ID seconds and release. Set Regeneration Time STEP 2ID – Regeneration Time: Set the clock to the hour the regeneration should occur STEP 2ID by using the UP or DOWN buttons. -
Page 8: Setting The Time Of Day
SETTING THE TIME OF DAY STEP 1U – Press SET HOUR STEP1U STEP 2U – Current time: Set the clock to the closest hour by using the UP and DOWN button. An arrow points to PM after 12. After a power outage, the time of day will need to be reset. -
Page 9: Start-Up Instructions
START UP INSTRUCTIONS • After installation is completed and checked for leaks, rotate the bypass handles to the bypass position (see Figure 2, Bypass Valve diagram page in main manual). • Fully open a cold water faucet. • Allow water to run until clear to rid pipes of debris, which may have occurred during installation. •... - Page 10 TROUBLESHOOTING PROCEDURES, TIMECLOCK UNITS Problem Cause Solution a. Transformer unplugged a. Reconnect b. No power at outlet b. Restore power 1. Timer does not display time of day c. Defective transformer c. Replace transformer d. Defective PC board d. Replace PC board a.
- Page 11 PAGE LEFT BLANK INTENTIONALLY...
- Page 12 WATERITE, INC. Winnipeg, Manitoba Canada www.waterite.com...
