Service Manual
CONTENTS
Laser Beam Safety Precaution ........................................ 1
Tuner Adjustments ........................................................... 2
Tape Deck Adjustments ................................................... 3
Exploded View (Packing & Accessories) ......................... 4
Exploded View (Cabinet & Chassis) ................................ 5
Parts List .......................................................................... 6
Wiring Connection ............................................................ 9
Schematic Diagram (MAIN) ............................................. 10
Schematic Diagram (CD) ................................................. 12
Schematic Diagram (MCU) .............................................. 14
All manuals and user guides at all-guides.com
Micro Component System
FILE NO.
DC-UB1470
PRODUCT CODE No.
129 738 00
Schematic Diagram (TUNER) .......................................... 16
Schematic Diagram (TAPE) ............................................. 17
Schematic Diagram (CONTROL) ..................................... 18
Schematic Diagram (USB/SD) ......................................... 19
Wiring Diagram (CD) ........................................................ 20
Wiring Diagram (CONTROL) ........................................... 22
Wiring Diagram (TUNER) ................................................. 24
Wiring Diagram (TAPE) .................................................... 26
Wiring Diagram (USB/SD) ................................................ 28
Wiring Diagram (MAIN) .................................................... 29
REFERENCE No.
(XE)
SM
2810066

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DC-UB1470 and is the answer not in the manual?

Questions and answers

Related Manuals for Sanyo DC-UB1470

Summary of Contents for Sanyo DC-UB1470

  • Page 1: Table Of Contents

    All manuals and user guides at all-guides.com FILE NO. Service Manual Micro Component System DC-UB1470 (XE) PRODUCT CODE No. CONTENTS 129 738 00 Laser Beam Safety Precaution ........1 Schematic Diagram (TUNER) .......... 16 Tuner Adjustments ............2 Schematic Diagram (TAPE) ..........17 Tape Deck Adjustments ...........
