Machine Components - Unoclean UN18C Operator's & Parts Manual

1. Brush cover
4. Recovery tank
7. Squeegee
10. Adjusting handle
13. Squeegee lifting handle
16. Brush plunger
19. Clear tube
23. Circuit breaker
25
24
18
19
UN18C

MACHINE COMPONENTS

Machine Structure
2. Brush
5. Solution tank
8. Control box
11. Water filter
14. Power cord hook
17. Plug of water filling port
20. Switch for brush motor
24. Power cord
16
14
17
12
20 23 21
3
4
5
15
10
1
2
OPERATOR MANUAL
3. Cover tank
6. 8" wheels
9. Trigger
12. Ball valve
15. Brush/pad driving hub
18. Knob
21. Switch for vacuum motor
25. Support wheel
