  • Page 1 ESF8570ROX Dishwasher User Manual...

  • Page 2: Table Of Contents

    13. TECHNICAL INFORMATION................. 22 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time.

  • Page 3: Safety Information

    ENGLISH SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.

  • Page 4: Safety Instructions

    The operating water pressure (minimum and • maximum) must be between 0.5 (0.05) / 8 (0.8) bar (MPa) Obey the maximum number of 15 place settings. • If the supply cord is damaged, it must be replaced by •...
  • Page 5 ENGLISH • Connect the mains plug to the mains • If the water inlet hose is damaged, socket only at the end of the immediately close the water tap and installation. Make sure that there is disconnect the mains plug from the access to the mains plug after the mains socket.

  • Page 6: Product Description

    3. PRODUCT DESCRIPTION Worktop Air vent Top spray arm Rinse aid dispenser Upper spray arm Detergent dispenser Lower spray arm Lower basket Filters Upper basket Rating plate Cutlery drawer Salt container...

  • Page 7: Control Panel

    ENGLISH 4. CONTROL PANEL On/off button Start button Program button Indicators Programme indicators Option button Display Delay button 4.1 Indicators Indicator Description Washing phase. It comes on when the washing phase and the rinsing phases operate. Drying phase. It comes on when the drying phase operates. TimeManager indicator.

  • Page 8: Programmes

    5. PROGRAMMES Programme Degree of soil Programme pha‐ Options Type of load • Normal soil • Prewash • XtraDry • Crockery and • Wash 50 °C cutlery • Rinses • Dry • All • Prewash • XtraDry • Crockery, cut‐...

  • Page 9: Settings

    ENGLISH Water Energy Duration Programme (kWh) (min) 8 - 15 0.7 - 1.7 46 - 170 14 - 16 1.2 - 1.5 160 - 180 12.5 - 14.5 1.4 - 1.7 170 - 190 1) The pressure and the temperature of the water, the variations of the mains supply, the options and the quantity of dishes can change the values.
  • Page 10 The higher the content of these minerals, your area. Your local water authority can the harder your water is. Water hardness advise you on the hardness of the water is measured in equivalent scales. in your area. It is important to set the...
  • Page 11 ENGLISH 6.5 AirDry How to deactivate the rinse aid empty notification AirDry improves the drying results with less energy consumption. Make sure the appliance is in user mode. 1. Press Option. • The indicators are off. • The indicator still flashes.

  • Page 12: Options

    • The display shows the current It is also possible to set applicable options together with the programme. setting: = AirDry activated. 2. Press and hold simultaneously 2. Press Start to change the setting: Program and Delay until the = AirDry deactivated.

  • Page 13: Before First Use

    ENGLISH The washing results are the same as How to activate TimeManager with the normal programme duration. The drying results can decrease. Press Option until the indicator is on. This option increases the pressure and The display shows the updated the temperature of the water.

  • Page 14: Daily Use

    8.2 How to fill the rinse aid CAUTION! dispenser Only use rinse aid designed specifically for dishwashers. 1. Open the lid (C). 2. Fill the dispenser (B) until the rinse aid reaches the marking ''MAX''. 3. Remove the spilled rinse aid with an absorbent cloth to prevent excessive foam formation.

  • Page 15: Hints And Tips

    ENGLISH the energy consumption and the Starting a programme programme duration. After closing the door, the appliance continues from the 1. Press the on/off button to activate the point of interruption. appliance. Make sure that the appliance is in programme selection If the door is opened for mode.
  • Page 16 • Always use the whole space of the 3. Start the shortest programme with a baskets. rinsing phase. Do not add detergent • Make sure that items in the baskets and do not load the baskets. do not touch or cover each other.

  • Page 17: Care And Cleaning

    ENGLISH • The correct quantity of detergent is 2. First remove items from the lower used. basket, then from the upper basket. After the programme is 10.6 Unloading the baskets completed, water can still remain on the inside 1. Let the tableware cool down before surfaces of the appliance.
  • Page 18 3. Wash the spray arm under running water. Use a thin pointed tool, e.g. a 7. Reassemble the filters (B) and (C). toothpick, to remove particles of soil 8. Put back the filter (B) in the flat filter (A). Turn it clockwise until it locks.

  • Page 19: Troubleshooting

    ENGLISH 11.4 Internal cleaning • Do not use abrasive products, abrasive cleaning pads, sharp tools, • Carefully clean the appliance, strong chemicals, scourer or solvents. including the rubber gasket of the • Using short-duration programmes door, with a soft damp cloth. regularly can cause grease and •...
  • Page 20 Problem and alarm code Possible cause and solution The appliance does not • Make sure that the sink spigot is not clogged. drain the water. • Make sure that the filter in the outlet hose is not clog‐ ged.
  • Page 21 ENGLISH For alarm codes not described in the table, contact an Authorised Service Centre. 12.1 The washing and drying results are not satisfactory Problem Possible cause and solution Poor washing results. • Refer to "Daily use", "Hints and tips" and basket loading leaflet.

  • Page 22: Technical Information

    Problem Possible cause and solution There are residues of deter‐ • The detergent tablet got stuck in the dispenser and gent in the dispenser at the therefore was not completely washed away by wa‐ end of the programme. ter.
  • Page 23 ENGLISH Power consumption Left-on mode (W) Off-mode (W) 0.50 1) Refer to the rating plate for other values. 2) If the hot water comes from alternative source of energy (e.g. solar panels), use the hot water supply to decrease energy consumption. 14.
