- Page 1 BTS3701B V300R003 Installation Guide Issue: 01 Date: 2010-03-20 HUAWEI TECHNOLOGIES CO., LTD.
-
Page 2: Safety Precautions
When operating Huawei products or equipment, strictly follow all precautions and special safety instructions required by Huawei. The "Safety Warning" in the manual is only based on the knowledge of Huawei. Huawei will not assume any responsibility for the loss incurred by operations violating the universal safety rules or standards for designing, producing, or using the equipment. - Page 3 Wire stripper When an external antenna is used, connect the antenna to the BTS3701B before installing the BTS3701B. When the BTS3701B is installed on a wall, the integrated mode is recommended. The BTS3701B must be installed at least 0.5 m (1'-7 11/16'') away from the...
- Page 4 ≥ 250 mm (9 13/16'') ≥ 100 mm ≥ 250 mm (3 15/16'') (9 13/16'') ≥ 170 mm (6 11/16'') A minimum of 500 mm (1'-7 11/16'') should be reserved at the back of the BTS3701B only in the ceiling installation mode.
-
Page 5: Installation Modes
BTS3701B Transitional piece Mounting bracket Ceiling mounting Mounting bracket for the adapter bracket for the module Installing the BTS3701B on a Wall (Separated Mode) Regular installation Reverse installation Installing the BTS3701B on a Wall (Integrated Mode) Regular installation Reverse installation... - Page 6 20 mm (13/16'') to 65 mm (2 9/16'') 75 mm (2 15/16'') Pole Angle steel U-steel Installing the BTS3701B on a Pole (Separated Mode) Regular installation Reverse installation Installing the BTS3701B on a Pole (Integrated Mode) Regular installation Reverse installation...
- Page 7 Installing the BTS3701B on a Ceiling Regular installation Reverse installation If the BTS3701B is installed on a ceiling, the ceiling must be made of concrete and can bear a weight of 323.6 N.m (2864.10 lbf.in.). Installing the BTS3701B on a Wall...
- Page 8 Installing the BTS3701B on a Wall Separated Mode M3.5×20 3 ± 0.5 N.m (26.55 ± 4.43 lbf.in.) Installation procedure The procedures of regular installation and reverse installation are identical.
- Page 9 Installing the BTS3701B on a Wall Integrated Mode 3 ± 0.5 N.m (26.55 ± 4.43 lbf.in.) 10 N.m (88.51 lbf.in.) The procedures of regular installation and reverse installation are identical.
- Page 10 Installing the BTS3701B on a Pole Separated Mode 3 ± 0.5 N.m (26.55 ± 4.43 lbf.in.) Integrated Mode 3 ± 0.5 N.m 10 N.m (26.55 ± 4.43 lbf.in.) (88.51 lbf.in.) The procedures of regular installation and reverse installation are identical.
- Page 11 Installing the BTS3701B on a Ceiling Determining Installation Positions of Drilling Holes and Installing Bolts Expansion Bolts 24 mm (15/16'') to 25 mm (1'') Marking template Installing the BTS3701B on a Ceiling M3.5×20 Installation procedure 10 N.m (88.51 lbf.in.) The procedures of regular installation and reverse installation are identical.
-
Page 12: Connecting Cables
Blinking at 0.5 Hz (green) (on for 1s, off for 1s) The BTS3701B is running normally. Red and green Blinking at 4 Hz (green) (on for 0.125s, off for The BTS3701B is being loaded, or 0.125s) the BTS3701B is not started. On (red) An alarm is generated, and the BTS3701B needs to be replaced. - Page 13 Ceiling Separated Mode Integrated Mode Straight-through cable When the BTS3701B is installed on a pole, fix the input power DC input power cable cable of the power adapter on the pole using a tie wrap. Power cable Before powering on the equipment, ensure that the antenna of the...
- Page 14 The distance between the PSE and the PD should be more than 1 m (3'-3 3/8''). The Power sourcing equipment (PSE) PSE cannot be installed on a ceiling. Appendix: Removing the Equipment Spring Press the spring pad and rotate the BTS3701B clockwise to remove it.
- Page 15 Huawei Technologies Co., Ltd. Administration Building, Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, P. R Zip code: 518129 www.huawei.com...
