- Page 1 BTS3900B GSM V300R008&R009 Installation Guide Issue: 04 Date: 2010-01-15 HUAWEI TECHNOLOGIES CO., LTD.
-
Page 2: Safety Information
Huawei. The safety precautions in the document are related to only Huawei products. Huawei is not liable for any consequence that results from the violation of universal regulations for safety operations and safety codes on design, production, and equipment use. -
Page 3: Installation Tools
Installation Tools Long measuring Marking pen Percussion drill Ladder tape Vacuum cleaner Adjustable wrench Cross screwdrivers Claw hammer Diagonal plier Gradienter Wire stripper Scissors Installation Procedure Start 1. When the external antenna is used, you should connect the antenna to the Prepare the installation BTS3900B before installing the BTS3900B. - Page 4 Space Requirements (Unit: mm) Dimensions of the Minimum Clearance BTS3900B Requirement Recommended Clearance Space Requirements of the PSE Requirement At least 500 mm should be reserved at the back of the BTS3900B in ceiling installation mode.
- Page 5 Installation Modes (AC Power Supply) Installing the BTS3900B on a Installing the BTS3900B on Wall (in Separated Mode) a Wall (in Integrated Mode) Installing the BTS3900B Installing the BTS3900B on the Ceiling Inside the Ceiling Void Concrete floor Ceiling If the BTS3900B is to be installed on the ceiling, the If the BTS3900B is to be installed inside the ceiling, it ceiling must be made of concrete.
- Page 6 Installation Modes (PoE Power Supply) Installing the BTS3900B on a Wall •In PoE power supply mode, the AC power adapter and the mounting frame are not required if the BTS3900B is installed on a wall. The mounting frame of the adapter is required if the BTS3900B is installed on the ceiling.
- Page 7 Installing the BTS3900B on a Wall (AC Power Supply) Determining the Installation Drilling Holes and Installing Positions of the Mounting Expansion Bolts Pieces In integrated mode, only the dimensions of the power adapter are required. Installing the BTS3900B and Power Adapter Separately M3.5×20 Installing the BTS3900B and Power Adapter Together 10N·m...
- Page 8 Installing the BTS3900B Inside the Ceiling Void (AC Power Supply) Determining the Installation Installing the Mounting Positions Piece for the BTS3900B Concrete floor 10Kgf·cm Ceiling Installing the BTS3900B and Placing the Power Adapter The power adapter can be placed on the ceiling near the BTS3900B.
- Page 9 Installing the BTS3900B on the Ceiling (AC Power Supply) Determining the Installation Drilling Holes and Installing Positions Expansion Bolts Marking template Installing the Bolt and Installing the BTS3900B Mounting Pieces and Power Adapter M3.5×20 Before the BTS3900B is installed on the ceiling, the bolts and plastic washer should be fixed to prevent the bolts from falling off.
- Page 10 Installing the PSE (PoE Power Supply) Determining the Installation Drilling Holes and Installing Positions of the Mounting Expansion Bolts Pieces Assemblies Installing the PSE on a Wall M3.5×20...
- Page 11 Installing the Cables (AC Power Supply) Cables Connector Connects To... Straight RJ-45 FE/GE port connector 4-pin connector through RJ-45 Transmission devices of the DC cable connector of the user input power Power PA male AC power connector cable cable connector C7 female AC input port of the connector...
- Page 12 Powering on the BTS3900B •Powering on the BTS3900B (AC Power Supply) When the PA male connector is fixed to the wiring bar for the AC power cable, the BTS3900B is powered on. After the BTS3900B is powered on, check the status of the LEDs to decide whether the BTS3900B is properly powered on.
- Page 13 Powering on the BTS3900B Color Status Description Green The power supply is normal. The PSE has no power input or is faulty. PORT Green The connection between the main component of the BTS3900B and the PSE is normal. The connection between the main component of the BTS3900B and the PSE is faulty or the PSE is faulty.
- Page 14 Appendix : Routes for Cabling in Different Installation Modes (AC Power Supply) Installing the BTS3900B on a Installing the BTS3900B on Wall (in Separated Mode) a Wall (in Integrated Mode) Installing the BTS3900B Installing the BTS3900B on the Ceiling Inside the Ceiling Void •If the AC power cable is not long enough, the power Straight-through cable transfer board can be used.
- Page 15 Appendix : Routes for Cabling in Different Installation Mode (PSE) Straight-through cable Network equipment Power cable In PoE power supply mode, only the cabling routes of the straight-through cables should be considered. The cabling routes of cables connected to the BTS3900B side are the same as the cabling routes of cables in AC power supply mode.
-
Page 16: Change History
Change History This describes the changes in the BTS3900B GSM Installation Guide versions. Issue 04 (2010-01-15) This is the fourth commercial release. Issue 03 (2009-09-10) This is the third commercial release. Compared with issue 02 (2009-06-30), the following part is added: The description of Ethernet cable types in PoE power supply mode is added. - Page 17 HUAWEI TECHNOLOGIES CO., LTD. Huawei Industrial Base Bantian Longgang Shenzhen 518129 People’s Republic of China www.huawei.com...
