OWNER'S MANUAL
DRYER
Before beginning installation, read these instructions carefully.
This will simplify installation and ensure that the product is
installed correctly and safely. Leave these instructions near the
product after installation for future reference.
TD-H802SJW
MFL68721086
Rev.02_082217
Copyright © 2017 LG Electronics Inc. All Rights Reserved.
www.lg.com

Advertisement

Table of Contents
loading

Related Manuals for LG TD-H802SJW

Summary of Contents for LG TD-H802SJW

  • Page 1 Before beginning installation, read these instructions carefully. This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. TD-H802SJW www.lg.com MFL68721086 Copyright © 2017 LG Electronics Inc. All Rights Reserved. Rev.02_082217...

  • Page 2: Table Of Contents

    Programme Table ..................18 Option Programme ................... 21 Rack Dry (Optional) .................. 23 SMART FUNCTIONS ...............24 Using LG SmartThinQ Application ............24 Using Smart Diagnosis™ ................. 27 MAINTENANCE ...............28 Cleaning the Lint Filter ................28 Emptying the Water Container..............29 Cleaning the Cool Air Inlet Grill ..............

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. This symbol is displayed to indicate matters and operations that can cause risk.
  • Page 4 WARNING - To avoid a fire Do not wash or dry clothes or items that have any contaminants of flammable solvents or substances. Do not clean the product or expose it to flammable substances. Installation •Make sure the appliance is properly installed, grounded, and adjusted by qualified service personnel according to the installation instructions.
  • Page 5 •This appliance must not be installed behind a lockable door, a sliding door or a door with a hinge on the opposite side to that of the appliance, in such a way that a full opening of the appliance door is restricted. •This appliance must be grounded (earthed via the power cord).
  • Page 6 Improper use can cause a fire or explosion. •In case of flood, disconnect the power plug and contact the LG Electronics customer information centre. •Do not push down the door excessively, when the appliance door is open.
  • Page 7 •If the drain hose or inlet hose is frozen during winter, use it only after thawing. •Keep all washing detergents, softener and bleach away from children. •Do not touch the power plug or the appliance controls with wet hands. •Do not bend the power cable excessively or place a heavy object on it.
  • Page 8 Technical Safety for Using the Dryer •Do not dry unwashed items in the appliance. •Fabric softeners, or similar products, should be used as specified by the fabric softener instructions. •Remove all objects from pockets such as lighters and matches. •Never stop the appliance before the end of the drying cycle unless all items are quickly removed and spread out so that the heat is dissipated.
  • Page 9 •The appliance must not be supplied through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by a utility. •Remove clothes from the product immediately when drying is complete or the power is turned off during the drying process. Leaving clothes that has been dried in the appliance unattended could result in fire.

  • Page 10: Installation

    Max. capacity 8 kg • Appearance and specifications may vary without notice to improve the quality of the appliance. Accessories Please contact the LG Electronics Customer Information Centre for purchase. Condensing Drain Hose Dry Rack Stacking Kit and Hose Holder...

  • Page 11: Installation Place Requirements

    Installation Place Positioning Requirements • Install the appliance on a flat hard floor. • Make sure that air circulation around the Location appliance is not impeded by carpets, rugs, etc. Level floor : Allowable slope under the entire appliance is 1°. •...

  • Page 12: Stacking Installation Instructions

    • Avoid installing the appliance around a heat source.The rear side of the appliance must be Your dryer can be placed on top of an LG front well ventilated. Failure to follow these load washing machine and securely fixed with a instructions may result in problems.
  • Page 13 Installation Procedure WARNING • Incorrect installation can cause serious Place the LG dryer on the LG washing accidents. machine. • The weight of the appliance and the height of installation make the stacking procedure too risky for one person. This procedure should...
  • Page 14 Condensed Water Drain-out Leveling the appliance Normally, condensed water is pumped up to the Leveling the appliance prevents unnecessary water container where water is collected until noise and vibration. Place the appliance on a manually emptied. Water can also be drained solid, level floor.

  • Page 15: Operation

    OPERATION Using the Appliance CAUTION • Be careful not to trap laundry between the Before the first cycle, set the appliance to dry door and rubber seal. for five minutes to warm up the drum. Open the door between loads the first few times you use Turn the power on.

  • Page 16: Sorting Laundry

    Baby Clothes and Night Gowns CAUTION • Always check fabric care labels. • Be careful! The drum inside may still be hot. • The appliance must not be used for purposes Rubber and Plastics other than those for which it was designed. •...

  • Page 17: Control Panel

    Control Panel Display Power Button • : This icon indicates that the lint filter • Press the Power button to turn power on should be cleaned or is clogged. and off. − Cleaning notice: When you press the Power • Press the Power button to cancel the button, the icon will be displayed.

  • Page 18: Programme Table

    Programme Table Drying Programme Sensor Dry Programmes Programme Laundry Type Detail Drying Max. Load Level Capacity Towels, dressing gowns For thick and quilted Extra 8 kg and bed linen fabrics Bath towels, tea towels, For fabrics that do not underwear and cotton Cupboard 8 kg need to be ironed...
  • Page 19 Sensor Dry Programmes Programme Laundry Type Detail Drying Max. Load Level Capacity Sports Soccer kit and training For polyester material 2 kg Wear wear For fabrics that are Silk, fine fabrics and Delicate heat-sensitive, such as 1.5 kg lingerie synthetic fabrics Wool Wool For wool fabrics...
  • Page 20 Extra Options = Default Programme Dry Mode Option Damp Dry Programme Dry Level Normal Turbo Hand Iron Beep Extra ● ● ● Cotton Cupboard ● ● ● Iron ● ● ● Extra ● ● ● Mixed Cupboard ● ● ● Fabric Iron ●...

  • Page 21: Option Programme

    Option Programme Drum Light Whilst the appliance is running it is possible to Delay End see inside the drum if you select the Drum Light function. You can use the Delay End option to delay the finishing time of the drying cycle. Maximum •...
  • Page 22 Damp Dry Beep Child Lock ( With this option, the appliance will beep when Use this option to disable the controls. This the load is ready for ironing. feature can prevent children from changing This allows you to remove faster-drying cycles or operating the appliance.

  • Page 23: Rack Dry (Optional)

    Rack Dry (Optional) Close the door. The dryer rack is placed inside the appliance, as in the picture below. Remove and discard Turn power on and select Rack Dry. packing material before use. The Rack Dry is designed for use with laundry Press the Start/Pause button.

  • Page 24: Smart Functions

    • For appliances with the logo • LG SmartThinQ is not responsible for any network connection problems or any faults, Check the distance between the appliance and the wireless router (Wi-Fi network).
  • Page 25 • Once the Remote Start mode is enabled, you push notifications on a smart phone. can start a cycle from the LG SmartThinQ smartphone application. The Dryer cannot be used manually in the home until the Remote Start option is turned off remotely from the application or from the Dryer itself.
  • Page 26 In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com.

  • Page 27: Using Smart Diagnosis

    • If the call centre agent is not able to get Use this function if you need an accurate an accurate recording of the data, you diagnosis by an LG Electronics customer may be asked to try again. information centre when the appliance malfunctions or fails.

  • Page 28: Maintenance

    MAINTENANCE WARNING • Open the second lint filter. • Remove the power plug when you clean the appliance. Not removing the plug may result in electric shock. Cleaning the Lint Filter Clean the lint filter before each drying cycle. It should also be cleaned if the icon becomes illuminated and a chime will sound while the...

  • Page 29: Emptying The Water Container

    Emptying the Water Container Cleaning the Cool Air Inlet Grill Condensed water is collected in the water container. Vacuum the Cool Air Inlet grill 3 – 4 times a Empty the water container after every use. Not year to make sure there is no build up of lint or doing so will affect the drying performance.

  • Page 30: Troubleshooting

    TROUBLESHOOTING The appliance is equipped with an automatic error-monitoring system to detect and diagnose problems at an early stage. If the appliance does not function properly or does not function at all, check the following before you call for service: Diagnosing Problems Symptoms Reason...
  • Page 31 Symptoms Reason Solution • Reset circuit breaker or replace fuse. House fuse is blown, circuit Do not increase fuse capacity. If the breaker has tripped, or power problem is a circuit overload, have it outage has occurred. corrected by a qualified electrician. •...
  • Page 32 Symptoms Reason Solution • Over drying a load of laundry can lead Clothes have dried too long to wrinkled clothes. Try a shorter (overdried). drying time. Clothes are wrinkled. Clothes have been left in the appliance for too long after •...
  • Page 33 If water leaks continuously, is caught in the door. contact the LG Electronics Customer Information Centre. • If items are too tightly packed or too sparse the sensor may have trouble reading the dryness level of the load.

  • Page 34: Error Codes

    Error Codes Symptoms Reason Solution Error code: tE1 • Turn off the appliance and call for Temperature sensor failure. through tE8 service. The door has been opened while the appliance is in • Close the door completely. operation or the appliance is •...
  • Page 35 Memo...
