- Page 1 OWNER’S MANUAL LG HEAT PUMP DRYER Please read this manual carefully before operating your dryer and retain it for future reference. TD-H9055E www.lg.com MFL67653045...
-
Page 2: Table Of Contents
Ease of Use The wide, electronically controlled LED display on this machine is very easy to use. Simply select the cycle you require and your LG dryer will do the rest. Smart Diagnosis™ is available. Contents Safety Instructions ....3... -
Page 3: Safety Instructions
• Serious injury or death may occur when not observing the following rules. • It is strictly forbidden to use the product for anything other than the manufacturer authorised usage. LG doesn't take full responsibility for the damage by inaccurate and improper usages. - Page 4 Safety Instructions • Do not touch the plug or switch on with wet hands. May cause electric shock. • Disconnect the power cord by grasping the plug, not the cord. May cause damage of cord resulting in fire or electric shock. •...
- Page 5 Safety Instructions • Items made of foam, rubber, plastic, or other heat-sensitive fabrics (such as bathroom rugs, nonslip mats or raincoats) should not be dried in a tumble dryer on a heat setting. Items such as foam rubber (latex foam), shower caps, waterproof •...
-
Page 6: Installation Instructions
■ Stacking Installation Instructions Your LG dryer can be placed on top of a front loading washing machine and securely fixed with a stacking kit (see following page for instructions). This installation must be conducted by an experienced installer to ensure it has been installed correctly. - Page 7 Installation Instructions Stacking Kit WARNING In order to stack this dryer an LG stacking • Incorrect installation can cause serious kit is required. accidents. • The weight of the dryer and the height of installation makes the stacking procedure too risky for one person.
- Page 8 Installation Instructions Earthing Instructions NOTE This appliance must be earthed. In the - For better drying performance, event of malfunction or breakdown, earthing please keep the rear of product will reduce the risk of electric shock by away from wall. providing a path of least resistance for the - Do not install the dryer where there electric current.
- Page 9 Installation Instructions ■ Level the Dryer 1. Levelling the dryer prevents unnecessary noise and vibration. Place your dryer on a solid, level floor. Place the dryer in an area free from flammable materials, condensation and not liable to freezing. 2. If the dryer is not properly level, adjust the front levelling feet as necessary.
-
Page 10: Appearance & Design
Appearance & Design ■ Product Layout - TD-H9055E Control Panel Water Container Glass Opaque Door Door Air Ventilation Grill ■ Control Panel Smart Diagnosis™ function is available only for the products with a Smart Diagnosis™ mark. Options • Time Delay •... -
Page 11: Operating Your Dryer
Operating Your Dryer ■ Cycle Selection Table Sensor Dry Cycle Drying Cycle Laundry Type Detail Level Towels, dressing gowns and For thick and quilted fabrics Extra bed linen Terry towels, tea towels, For thick and quilted fabrics that Very towels and bed linen do not need to be ironed Bath towels, tea towels, For fabrics that do not need to be... - Page 12 Operating Your Dryer Sensor Dry Cycle Drying Cycle Laundry Type Detail Level Bulky Item Bed clothes, sheets For bulky items Jeans and colour fading For jeans which do not need to be Jeans garments. ironed T-shirts, pillowcase, and For cotton fabrics which do not Skin Care towels need to be ironed...
- Page 13 After removing the packaging, please carry out the following checks to ensure the LG dryer is correctly installed and ready for use. (See installation instructions.) 1. Check the dryer is well balanced by using a spirit level. If not, adjust the feet of the LG dryer until the machine is balanced.
- Page 14 Operating Your Dryer 5. Close the door. Before you close the door, make sure fabrics are placed well inside and that foreign objects, especially flammable ones, are not caught around door. CAUTION - Be careful not to trap laundry between the door and rubber seal.
- Page 15 Operating Your Dryer NOTE Clean the filter. The final part of a tumble dryer cycle (Replace occurs without heat (cool down the filter if it is cycle) to ensure that the items are left damaged.) at a temperature that will not damage them.
- Page 16 Operating Your Dryer ■ NOTE Rack Dry Check the filter and remove any lint The dryer rack is placed inside the dryer like accumulated from items dried on the the picture. Remove and discard packing Rack. material before use. If preferred, set up Eco by pressing Eco The Rack Dry is designed for use with items Hybrid button.
-
Page 17: Additional Functions
Additional Functions Option buttons Power Cycle Start/Pause Additional selector programme buttons Power Additional Programme • Press the Power button to turn power on • Use these buttons to select the desired and off. options for the selected cycle. • To cancel the Time Delay function, the power button should be pressed. - Page 18 Additional Functions ■ ■ Time Delay Option You can use the Time Delay option to delay Hand Iron the finishing time of drying cycle. This function keeps the garments more Maximum Time Delay is 19 hours. moist than the standard Iron dry level. Minimum Time Delay is 3 hours.
-
Page 19: Caring For Your Dryer
Caring for Your Dryer Caring for your Dryer is very Important Empty Water Container It’s not difficult to care for your dryer but it is Condensed water is collected in the water important that you do care for it to get the container. - Page 20 Caring for Your Dryer ■ 3. Connect Ventilation Grill and Cool Air drain hose Inlet Grill to the kit. Vacuum the front ventilation grill 3-4 times a year to make sure there is no build up of lint or dirt that may cause improper air flow. ■...
-
Page 21: Additional Tips For Smart Use
Additional Tips for Smart Use ■ Drying Guide Display Drying Time (Including Cooling Time) Capacity of CYCLE dryer Speed Extra 9 kg 200 min 125 min Very 9 kg 190 min 120 min Cotton Cupboard 9 kg 180 min 115 min Light 9 kg 170 min... - Page 22 Additional Tips for Smart Use Woollens Below are fabric care labels. Dry woollens on ‘’wool’’ cycle. Be sure to Symbols Instructions follow fabric care label "symbols“ first. Wool may not be completely dried from the cycle, so don't repeat drying. Pull woollens to their Tumble dry original shape and dry them flat.
- Page 23 5. Date of Purchase. • The stacking kit can be used for washer top plate size 550mm and 600mm for both. If stacking is needed, you must stack the dryer upon an LG washing machine. A stacking kit is sold separately.
-
Page 24: Troubleshooting Guide
Troubleshooting Guide ■ Troubleshooting Tips To save you time and money, the following page will help answer your questions before service call. Questions What to do Dryer won’t run 1. Check dryer is plugged in. 2. Check "Start/Pause" button is pressed. 3. - Page 25 Troubleshooting Guide ■ Error Mode • : The door must be closed and Start/Pause button must be pressed for re- operation.If error message continues to occur, unplug the power cord and call the service center for advice. • : If error message continues to occur, unplug the power cord and call the service center for advice.
- Page 26 Accordingly, LG does not guarantee that Smart Diagnosis would accurately troubleshoot any given issue.”...
-
Page 27: Technical Data
Technical Data 850 mm 640 mm Net Weight : 55.9kg ,Opaque Door 600 mm 57.4kg ,Glass(Cr) Door ■ ■ Electrical Requirements Ventilation Requirement Alcove or Closet Volts Hertz Watts under counter Ensure air flow Closet door must have 230 V 50 Hz 1800 of 112 cu.ft./min... -
Page 28: Warranty
Warranty Disposal of your old appliance 1. All electrical and electronic products should be disposed of separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities. 2. The correct disposal of your old appliance will help prevent potential negative consequences for the environment and human health. - Page 29 LG Electronics, if the 2. During the warranty period, we will apparatus is used for commercial purposes. correct any defects at no cost to you, if it 6.
- Page 30 Memo...
