- Page 1 Glutz Home Biometrics Instruction manual...
- Page 2 Dear customer Thank you for your interest in the Glutz Home Biometrics electronic access control system. Read this instruction manual carefully to ensure optimal use of Glutz Home Biometrics. In case of enquiries, please contact your specialist dealer or contact the manufacturer directly.
-
Page 3: Table Of Contents
Table of Contents GENERAL INFORMATION 7.4 Pairingadditionalmobiledevices 1.1 Targetgroup 7.5 ManagingmultipleBluetoothfingerscanners21 1.2 Intendeduse 7.6 Storingtheuserpairingcode 1.3 Assemblyinstructions 7.7 Resettingtheappsecuritycode 1.4 Dangernotices 7.8 Protectingthesystemincasea 1.5 Abbreviationsandterminology mobiledeviceislost 1.6 Symbols 7.9 Openingthedoor SAFETY INFORMATION ESTABLISHING NORMAL OPERATION AND USE OF THE 2.1 Securityfrommanipulation FINGER SCANNER WITH ADMIN FINGER PRODUCT DESCRIPTION... -
Page 4: General Information
1.2 Intended use Your Glutz Home Biometrics system is an access system and must only be used for the purpose intended by the manufacturer, the unlocking and locking of doors. -
Page 5: DangerNotices
1.4 Danger notices Danger to persons WARNING Potentially imminent danger Identifies a potentially threatening danger that can lead to severe bodily injuries or death. CAUTION Potential danger Identifies a potentially threatening danger that can lead to minor bodily injuries. Danger to property NOTE Damage to the product Identifies a situation in which disregard of instructions can... -
Page 6: AbbreviationsAndTerminology
1.5 Abbreviations and terminology Surface-Mounted Bluetooth False Acceptance Rate False Rejection Rate Finger Scanner RFID Radio Frequency IDentification Control Unit Flush-Mounted 1.6 Symbols Step-by-step instructions References to other sections of this manual References to the assembly instructions References to the connection diagram •... -
Page 7: Safety Information
2. Safety instructions WARNING Life-threatening danger due to electricity All Glutz Home Biometrics devices must be operated with safety extra-low voltage. Only use the power supply units provided by Glutz AG. Disregarding this instruction entails life-threatening danger due to electric shock. -
Page 8: Product Description
MINT SV mechanical multipoint lock Security plate with half cylinder for ingress 230V Finger scanner to mini control unit cable Comfort set (for Glutz MINT SVM motorised lock) Finger scanner Mini control unit 1 relay MINT SVM motorised multipoint lock... -
Page 9: System Components
4. System components 4.1 Finger scanner The finger scanner detects the fingerprint with a line sensor and evaluates it. It compares the result with the biometric information stored from the reference fingerprint and opens the door if it matches. The finger scanner only works correctly and reliably with the papillary grooves of the front phalanx. -
Page 10: CorrectExecutionOfThe
4.2 Correct execution of the operator actions on the finger scanner Draw your finger Action Description Holding your finger straight, place it in the centre between the guide edges. Do not twist it. Place the joint of the front phalanx directly on the sensor. - Page 11 Finger touch Action Description Touch the sensor briefly and quickly with your finger. Hold up an RFID transponder Action Description Position the surface of the RFID transponder about 1–5 cm in front of the finger guide of the finger scanner. The 'Hold up an RFID transponder' operating mode is only possible with finger scanners with RFID function.
-
Page 12: OpticalSignalsOnTheFingerScanner
ISO14443A (only with finger scanner Transponder type MIFARE Desfire EV1 with at least RFID function) 1 kByte memory Tested media: Glutz G-Line Clip, Glutz G-Line Card, Glutz C-Line Clip (other media with ISO 14443A also possible, but must be tested first) -
Page 13: ControlUnits
4.5 Control units The control units are available in 3 versions. They can only operate one detection unit per control unit. Each detection unit operates with each control unit. Product name Figure Application 82730 Activation of a Micro control unit motorised lock 1 relay Integration in the door leaf... -
Page 14: OpticalSignalsOfTheControlUnits
4.6 Optical signals of the control units 82740 / 82741 / 82745 Mini control unit 1 relay The upper status LED indicates wheth- er the control unit is coupled with the finger scanner. The lower status LED indicates that a relay switches. 82730 Micro control unit 1 relay The LED indicates whether the control unit is coupled to the finger scanner... -
Page 15: Installation And Commissioning
5. Installation and commissioning 5.1 Commissioning devices 1. Variants: With control unit 82745 or 82730 Assemble and wire the product correctly before connecting the power supply. Failure to do so entails the risk of potential property damage! Do not connect the power supply yet! Assemble the system according to the supplied assembly instructions. - Page 16 The pairing can take place by means of card programming or software programming: 1. Card programming: See 'eAccess operating manual Card programming', available at www.glutz.com 2. Software programming: Both devices must be at the same access point see 'eAccess operating manual',...
-
Page 17: TestOfWiring
5.2 Test of wiring You can check the wiring using test mode. Executing test mode A test can only take place if an admin finger has not been stored and/or no mobile device is paired. Connect the mains voltage and perform the test within the next 10 minutes. -
Page 18: Operational Concept
6. Operational Concept Depending on the detection unit, there are different operating concepts available: • Open Biometric App – administration of the Bluetooth finger scanner with a mobile device • Admin finger – administration of the finger scanner with admin finger Browse to the operating concept of your detection unit! See chapter 7 'Establishing normal operation and use of the finger scanner with app'... -
Page 19: DownloadingTheApp
7.1 Downloading the app The app is available for Apple iOS and Google Android. Download the app from App Store or Google Play. Enter the search term 'Open Biometric'. 7.2 Pairing with a mobile device for the first time You need a security code to pair a device. The factory admin pairing code or app security code is 9999. -
Page 20: DeactivatingBluetooth
You can pair additional mobile devices with the Bluetooth finger scanner with your chosen 6-digit admin or user pairing code. Description Display Start the Glutz Open Biometric App. According to the instructions on the display: The status LED illuminates blue,... -
Page 21: ManagingMultipleBluetoothFingerScanners21
7.5 Managing multiple Bluetooth finger scanners The app enables administration of multiple Bluetooth scanners. In order to switch between two finger scanners, the pairing between finger scanner and mobile device must be reset. When resetting the pairing, the stored relay name and user prints are deleted. -
Page 22: StoringTheUserPairingCode
7.6 Storing the user pairing code You can store a user pairing code. You can share this user pairing code with another person. This person can perform the following actions with their mobile device using this user pairing code: • Open a door •... -
Page 23: ResettingTheAppSecurityCode
7.7 Resetting the app security code If you have forgotten the app security code, you can reset the pairing between finger scanner and mobile device using the app. The app security code is also reset to the factory value 9999 if you reset the pairing. Note: This can only be carried out using the most recently paired smartphone Instructions Start the Open Biometric App. -
Page 24: ProtectingTheSystemInCaseA
7.8 Protecting the system in case a mobile device is lost If you have lost your mobile device, you can change the admin and/or user pairing code using a second mobile device. With the new admin and/or user pairing code, you disable the connection with the lost mobile device. -
Page 25: OpeningTheDoor
7.9 Opening the door The main purpose of the product is door opening. This can take place with the finger scanner, an RFID transponder or with the digital input. With the finger scanner Action Description Display Draw a stored user finger over the Status LED illuminates green. -
Page 26: Establishing Normal
8. Establishing normal operation and use of the finger scanner with admin finger Before you begin with the administration of your system the devices must have been commissioned. See 5.1 'Commissioning devices' The finger scanner is ready to store the admin finger. The admin finger is used for system programming. -
Page 27: StoringTheAdminFingerAnd
8.1 Storing the admin finger and establishing normal operation You must store 4 admin fingers. We recommend storing 2 fingers from 2 different people. Initial situation: The system is in normal operation Action Description Display Perform three finger touches on the Status LED illuminates orange, sensor within 5 s. -
Page 28: StoringAUserFinger
8.2 Storing a user finger The system allows for storage of up to 99 user fingers. A user finger is a finger that triggers an action on the control unit, such as opening a door. We recommend storing 2 fingers each. Initial situation: The system is in normal operation. -
Page 29: StoringAnRfidTransponder
8.3 Storing an RFID transponder The system allows for storage of up to 99 RFID transponders. An RFID transponder can trigger an action on the control unit, such as opening a door. You can only store an RFID transponder with finger scanners with RFID function. -
Page 30: OpeningTheDoor
8.4 Opening the door The main purpose of the product is door opening. This can take place with the finger scanner, an RFID transponder or with the digital input. Initial situation: The system is in normal operation. With the finger scanner Action Description Display... -
Page 31: DeletingAUserFinger
8.5 Deleting a user finger You can only delete individual fingers of a user, if the person is still present. Initial situation: The system is in normal operation. Action Description Display Perform three finger touches on the Status LED illuminates blue, sensor within 5 s. -
Page 32: DeletingAnRfidTransponder
8.6 Deleting an RFID transponder You can only delete an individual RFID transponder if you have the RFID transponder available. Deletion of an RFID transponder is only possible with finger scanners with RFID function. Initial situation: The system is in normal operation. Action Description Display... -
Page 33: DeletingAllUsersAnd
8.7 Deleting all users and RFID transponders All user fingers and RFID transponders stored in the system are deleted. The admin fingers are still stored. Initial situation: The system is in normal operation. Action Description Display Perform three finger touches on the Status LED illuminates blue, sensor within 5 s. -
Page 34: Resetting The System To
You can reset the system to the factory settings with the detection unit, the control unit, the digital input (only Glutz micro control unit) or the app (only Bluetooth finger scanner). Find the device that is most accessible. All authorisations are permanently deleted and the system settings are reset to the factory settings when you perform a factory reset. -
Page 35: AboutTheFingerScanner
9.1 About the finger scanner The resetting to factory settings is triggered with the finger scanner. All user and admin fingers and all RFID transponders are permanently deleted. With the Bluetooth finger scanner, the pairing code is also reset to 9999. At least 2 admin fingers must be stored to reset the Bluetooth scanner. -
Page 36: AboutTheControlUnit
9.2 About the control unit The resetting to factory settings is triggered with the control unit. The settings of the detection unit are reset to the factory settings and the pairing between control unit and detection unit is deleted. Action Description Display Press the button with the control... -
Page 37: AboutTheApp
9.4 About the app The resetting to factory settings is triggered with the app. All user and admin fingers and all RFID transponders are permanently deleted. The pairing code is reset to the factory setting 9999, the relay switching time is set to 3 seconds and the LED brightness of the finger scanner is set to 2 (LED on). -
Page 38: Updating The Software
RFID function still works. red/green. If these remedies do not solve the problem, contact your specialist partner. If the system has to be sent to Glutz, please ensure that it is packed correctly. Unsuitable packaging may void any warranty claims. -
Page 39: Maintenance
Use clean water without cleansers. 13. Declaration of Conformity Glutz AG hereby declares that the wireless system of the type Home Biometrics conforms to Directive 2014/53/EU. The complete text of the EU Declaration of Conformity is available under the following internet address: www.glutz.com/service/downloads/... - Page 40 11 Finch Drive, Springwood Industrial Estate Braintree CM7 2SF, United Kingdom Tel. +44 1376 348 808, Fax +44 1376 348 848 info-uk@glutz.com, www.glutz.com Glutz Singapore Pte Ltd. 61 Ubi Avenue 1, #04-13, UB Point Singapore 408941 Tel. +65 6554 4111, Fax +65 6554 4610 info-sg@glutz.com, www.glutz.com...
