- Page 1 Owner's Manual Original Instructions Portable air conditioner Model: ML-PC07AM-K5NNA2B ML-PC07AM-K5NNA2C ML-PC07AM-K5NNA2D ML-PC09AM-K5NNA2B ML-PC09AM-K5NNA2C Thank you for choosing our product. Please read this Owner’s Manual carefully before operation and retain it for future reference.
-
Page 2: Table Of Contents
Content Operation Notices The Refrigerant .......................1 Safety Warning ......................2 Operation Environment ...................3 Part's Name ......................4 Operation Guide Operation Introduction for Control Panel ..............5 Buttons on Remote Controller .................7 Introduction for Icons on Display Screen ..............7 Introduction for Buttons on Remote Controller ............8 Function Introduction for Combination Buttons ............10 Replacement of Batteries in Remote Controller ............10 Maintenance... - Page 3 Explanation of Symbols Indicates a hazardous situation that, if not avoided, will DANGER result in death or serious injury. Indicates a hazardous situation that, if not avoided, could WARNING result in death or serious injury. Indicates a hazardous situation that, if not avoided, may CAUTION result in minor or moderate injury.
-
Page 4: The Refrigerant
Appliance filled with flammable gas R290. Appliance shall be installed, operated and stored in a room with a floor area: Model Min. floor area (m ) ML-PC07AM-K5NNA2B ML-PC07AM-K5NNA2C, ML-PC07AM-K5NNA2D ML-PC09AM-K5NNA2B, ML-PC09AM-K5NNA2C The appliance shall be stored in a room without continuously operating ignition sources . -
Page 5: Safety Warning
Safety Warning ● This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. -
Page 6: Operation Environment
Safety Warning ● Do not use an extension cord. ● Do not through sundries into the air duct. If there are sundries get into the air duct, please contact the professionals to deal with it. Operation Environment ● The air conditioner must be operated within the temperature range: 16°C ~ 35°C. -
Page 7: Part's Name
Part's Name Controller panel Guide louver Swing louver Castor Filter Joint Heat discharge pipe Rear Clip Plug of power cord Wire-fixing hook FAN AUTO OPER On/Off Mode Swing Sleep Timer Health WiFi Remote controller NOTICE: Heat discharge pipe and other installation accessories can't be discarded. -
Page 8: Operation Introduction For Control Panel
Operation Introduction for Control Panel Name of control panel Dual-8 nixie tube Cool mode indicator + / - button Dry mode indicator Fan speed indicator Fan mode indicator Sleep button Wifi button Mode button ON/OFF button Fan button Operation of control panel Note: After putting through the power, the air conditioner will give out a sound. - Page 9 Operation Introduction for Control Panel Mode button Press this button and the mode will circulate according to below sequence: → COOL COOL: Under this mode, cooling mode indicator is bright. Dual-8 nix set temperature. Temperature setting range is 16°C~30°C. DRY: Under this mode, drying mode indicator is bright. Dual-8 nixie tube won’t display.
-
Page 10: Buttons On Remote Controller
Buttons on remote controller On/Off button FAN AUTO OPER Mode button + / - button Swing button (Not available for this unit) On/Off Mode Fan button Swing Sleep button Sleep Timer Timer button Health WiFi Health button (Not available for this unit) WiFi button Introduction for icons on display screen Temp. -
Page 11: Introduction For Buttons On Remote Controller
Introduction for buttons on remote controller Note: ● This is a general use remote controller, it could be used for the air conditioners with multifunction; For some function, which the model doesn't have, if press the corresponding button on the remote controller that the unit will keep the original running status. - Page 12 Introduction for buttons on remote controller Swing button Not available for this unit. Fan button This button is used for setting Fan Speed in the sequence that goes from AUTO, , to then back to Auto. Auto Speed 1 Speed 2 Speed 3 NOTE: There are 3 speeds for the Fan Speed of this model.
-
Page 13: Function Introduction For Combination Buttons
the lamp is defaulted on. signal sender battery reinstall are correct. NOTICE conditioner when using the remote controller. batteries. -
Page 14: Clean And Maintenance
Clean and Maintenance WARNING ● Before cleaning the air conditioner, please turn off the unit and disconnect power. Otherwise, it may cause electric shock. ● Do not wash air conditioner with water. Otherwise, it may cause electric shock. ● Do not use volatile liquid (such as thinner or gas) to clean the air conditioner. Otherwise, it may damage the appearance of air conditioner. - Page 15 Clean and Maintenance Clean heat discharge pipe Remove the heat discharge pipe from air conditioner, clean and dry it , and then reinstall it. (For the method of installation and removal , please refer to the instruction for "Installation and disassembly of heat discharge pipe"). Checking before use-season 1.
-
Page 16: Malfunction Analysis
Malfunction Analysis Please check below items before asking for maintenance. If the malfunction still can’t be eliminated, please contact local dealer or qualified professionals. Phenomenon Troubleshooting Solution ● Power failure? ● Wait after power recovery. ● Is plug loose? ● Reinsert the plug. ●... - Page 17 Malfunction Analysis Phenomenon Troubleshooting Solution ● Whether air outlet or air inlet is ● Eliminate the obstacles. blocked? ● Under heating mode, whether ● The unit will stop blowing indoor temperature is reached fan after reaching set temperature. to set temperature? ●...
- Page 18 Malfunction Analysis Malfunction code Error code Troubleshooting F1、 F2 F4 F0 Please contact qualified professionals for service. 1.Check if the unit is under high-temperature and high-humidi- ty environment; if ambient temperature is too high, power off the unit and then energize it for operation after the ambient temperature drops to 35℃below.
-
Page 19: Installation Precaution
Installation Precaution WARNING ● Observe all governing codes and ordinances. ● Do not use damaged or non-standard power cord. ● Be caution during installation and maintenance. Prohibit incorrect operation to prevent electric shock, casualty and other accidents. Selection of installation location Basic requirement Installing the unit in the following places may cause malfunction. - Page 20 Installation Precaution Requirements for electric connection WARNING: Safety precaution 1. Must follow the electric safety regulations when installing the unit. 2. According to the local safety regulations, use qualified power supply circuit. 3. For appliances with type Y attachment,the instructions shall contain the substance of the following.If the supply cord is damaged,it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
-
Page 21: Preparation Before Installation
Preparation before Installation Note: check if the accessories are available before installation. Accessory list Joint Rear clip Adapter heat discharge pipe FAN AUTO OPER On/Off Mode Swing Sleep Timer battery Health WiFi (AAA 1.5V) wire hook screw user's manual remote controller... -
Page 22: Install Wire Hook
Install Wire Hook ● Assemble the wire hook at the back of the unit with screws (the direction of wire direction of wire hook is upward wire hook screw direction of wire hook is downward ● Wind the power cord around the wire hook. -
Page 23: Drain Water
Drain Water To reach the maximum performance, it is not recommended to drain water, during Cool mode. It is recommended to use the middle drainage port to drain water during Dry mode. It is recommended to use the bottom drainage port to drain water during Heat mode. To drain water from the bottom drainage port when the display shows "H8". - Page 24 Drain Water Drain water from the middle drainage port. NOTICE: Water can be automatically emptied into a floor drain by attaching 13.5mm inner diameter hose (not included). Remove the continuous drain cap 1 by turning it counter clockwise then remove the rubber stopper 2 from the spout.
-
Page 25: Installation Of Heat Discharge Pipe
Installation of Heat Discharge Pipe Install heat discharge pipe Rotate joint and Rear clip clockwise into the two ends of heat discharge pipe. clockwise clockwise joint heat discharge pipe Rear clip 2. Insert joint of heat discharge pipe into the groove until you hear a sound. clasp groove Lead the heat discharge pipe outdoors. - Page 26 Installation of Heat Discharge Pipe Note of Installingheat discharge pipe The discharge pipe is suggested to be installed according to below figure by the manufacturer. correct User can adjust the installation method of the discharge pipe basing on the requirement, while the similar installation methods as below which will lead to unsmoothly air-out are not allowed.
-
Page 27: Operation Test
MAIN BOARD WIFI HIGH-WP WIFI MODULE N1 WATER1 CAP. OPTIONAL MOTOR YEGN YEGN WATER LEVEL SWITCH WATER MOTOR CAP. ML-PC07AM-K5NNA2B, ML-PC07AM-K5NNA2C, ML-PC09AM-K5NNA2B POWER BN(BK) TUBE TEMP. ROOM TEMP. OUTTUBE TEMP. RECEIVER SENSOR SENSOR SENSOR BOARD BU(WH) YEGN(GN) ROOM OUTTUBE TUBE... -
Page 28: Specialist's Manual
Specialist’s Manual Aptitude requirement for maintenance man(repairs should be done only be specialists). Any person who is involved with working on or breaking into a refrigerant circuit should hold a current valid certificate from an industry-accredited assessment authority, which authorises their competence to handle refrigerants safely in accordance with an industry recognised assessment specification. - Page 29 Specialist’s Manual exposing any pipe work shall use any sources of ignition in such a manner that it may lead to the risk of fire or explosion. All possible ignition sources, including cigarette smoking, should be kept sufficiently far away from the site of installation, repairing, removing and disposal, during which refrigerant can possibly be released to the surrounding space.
- Page 30 Specialist’s Manual purging the system; ---That there is continuity of earth bonding. Repairs to sealed components During repairs to sealed components, all electrical supplies shall be disconnected from the equipment being worked upon prior to any removal of sealed covers, etc. If it is abso- lutely necessary to have an electrical supply to equipment during servicing, then a perm- to warn...
- Page 31 Specialist’s Manual Electronic leak detectors may be used to detect refrigerant leaks but, in the case of flammable refrigerants, the sensitivity may not be adequate, or may need re-calibration. (Detection equipment shall be calibrated in a refrigerant-free area.) Ensure that the detector is not a potential source of ignition and is suitable for the refrigerant used.
- Page 32 Specialist’s Manual –Ensure that contamination of different refrigerants does not occur when using charging equipment. Hoses or lines shall be as short as possible to minimise the amount of refrigerant contained in them. Cylinders shall be kept upright. – Ensure that the refrigeration system is earthed prior to charging the system with refrigerant. –...
- Page 33 Specialist’s Manual Recovery When removing refrigerant from a system, either for servicing or decommissioning, it is recommended good practice that all refrigerants are removed safely. When transferring refrigerant into cylinders, ensure that only appropriate refrigerant recovery cylinders are employed. Ensure that the correct number of cylinders for holding the total system charge are available.
- Page 34 66129937320...
