- Page 1 INTRODUCTION E115SR E135SR WORKSHOP MANUAL ENGLISH Print No. 604.13.426 Edition: 03/2005 English - Printed in Italy Printed by Studio ti - 20005...
- Page 2 Find manuals at https://best-manuals.com...
- Page 3 - E115SR Workshop Manual "Excavator" • The complete Workshop Manual for the excavator model E115SR consists of the following volumes • "Excavator" and "Engine" Workshop Manuals identified by print number as shown herebelow: contain the technical information necessary for...
- Page 4 BY NEW HOLLAND KOBELCO CONSTRUCTION COPYRIGHT MACHINERY S.p.A. Product Support - Documentation Centre Strada di Settimo, 323 - 10099 - S.
- Page 5 INDEX INDEX SPECIFICATIONS Section 1 - Outline Section 2 - Specification Section 3 - Attachment dimension MAINTENANCE Section 11 - Tools Section 12 - Standard maintenance time schedule Section 13 - Maintenance standard and test procedure SYSTEM Section 21 - Mechatro control system Section 22 - Hydraulic system Section 23 - Electric system Section 24 - Components system...
- Page 6 SAFETY PRECAUTIONS SAFETY PRECAUTIONS Do not work on any machine that is supported only by lift, jacks or a hoist. Always use blocks or jack stands, capable of supporting the machine, WARNING before performing any disassembly. The proper and safe lubrication and maintenance for this machine, recommended by Distributor, are outlined in the OPERATOR’S MANUAL for the WARNING...
- Page 7 SAFETY PRECAUTIONS greater if the machine has just been stopped Shields that protect against oil spray onto hot because fluids can be hot. exhaust components in event of a line, tube or seal failure must be installed correctly. 13. Always use the proper tools that are in good condition and that are suited for the job at hand.
- Page 8 SAFETY PRECAUTIONS NOTE Find manuals at https://best-manuals.com...
-
Page 9: Table Of Contents
E115SR E135SR SECTION 1 OUTLINE TABLE OF CONTENTS 1. General precautions for repairs ................1-1 1.1 Preparation before disassembling ....................1-1 1.2 Safety in disassembling and assembling ..................1-1 1.3 Disassembling and assembling hydraulic equipment ..............1-1 1.4 Electrical equipment ........................1-2 1.5 Hydraulic parts .......................... - Page 10 Find manuals at https://best-manuals.com...
-
Page 11: General Precautions For Repairs
1. GENERAL PRECAUTIONS FOR REPAIRS 3) Stop the engine before starting inspection and PREPARATION BEFORE maintenance to prevent the operator being caught DISASSEMBLING in machine. (1) Understanding operating procedure 4) Identify the location of a first-aid kit and a fire Read OPERATION &... -
Page 12: Electrical Equipment
specified. WARNING 6) If it is hard to remove a part according to the Operation of the hydraulic equipment without filling procedure, do not try it by force but investigate the hydraulic oil or lubricant or without performing air bleeding cause. -
Page 13: Hydraulic Parts
(6) Turn the key OFF prior to touching the terminal of used depending on the working pressure even starter or generator. the size of fitting and the total length of the hose is same. (7) Remove the ground (earth) terminal of battery •... -
Page 14: International Unit Conversion System
2. INTERNATIONAL UNIT CONVERSION SYSTEM (4) Derived Units bearing Peculiar Designations Introduction Although this manual uses the JIS unit system. Table 2-4 If you need SI unit, refer to following QUANTITIES DERIVED UNIT DESIGNATION SIGN Frequency Hertz Hz 1Hz=1s international system of units. Force Newton 1N=1kgf m/s... - Page 15 E115SR E135SR SECTION 2 SPECIFICATIONS TABLE OF CONTENTS 1. Name of components ....................2-1 2. General dimension ....................2-2 2.1 4.6m (15’1”) boom ........................... 2-2 2.2 4.26m (14’) boom ..........................2-2 3. Weight of components .................... 2-3 4. Transportation dimension and weight ..............2-4 5.
-
Page 17: Name Of Components
1. NAME OF COMPONENTS... -
Page 18: General Dimension
4.6m (15′ 1″ ) Boom+2.45m (8′ ) Arm+0.5m (0.65cu yd) Bucket+700mm (28″ ) Shoe *Marked dimensions do not include height of shoe lug. 2.3 E115SR 4.26m (14′ ) Boom+2.2m (7′ 3″ ) Arm+0.45m (0.59cu yd) Bucket+600mm (23.6″ ) Shoe *Marked dimensions do not include height of shoe lug. -
Page 19: Weight Of Components
3. WEIGHT OF COMPONENTS Unit : kg (lbs) Model E135SR LC E135SR E115SR Item [ E135SR L] Machine complete 13,700(30,200) 13,900(30,640) 11,900(26,230) [15,700(34,610)] 1. Upper frame assy (including the following :) 7,330(16,160) 6,080(13,400) ← Counterweight 3,490(7,690) ← 2,340(5,160) Counterweight (Add-on) 600(1,320) ←... -
Page 20: Transportation Dimension And Weight
4. TRANSPORTATION DIMENSION AND WEIGHT E135SR E135SR (LC) OVERALL DIMENSIONS OF A STD COMPLETE MACHINE ON A TRAILER ● Model E135SR E135SR E135SR Item Shoe & Width mm(ft-in) 600mm (24″ ) 2,590 (8′ 6″ ) 800mm (32″ ) 2,790 (9′ 2″ ) Weight kg(lbs) 13,700 (30,200) - Page 21 OVERALL DIMENSIONS OF BOOM ● Type 4.6m (15ft-1in) Boom Item Length×Height×Width 4.76×1.39×0.57 L×H×W m(ft-in) (15′ 7″ ×4′ 7″ ×1′ 10″ ) Weight kg (lbs) 940 (2,080) OVERALL DIMENSIONS OF ARM+BUCKET ● Type 2.45m (8ft) Arm+0.5m (0.65cu･yd) Bucket Item Length×Height×Width 4.36×0.81×1.00 L×H×W m(ft-in) (14′...
- Page 22 OVERALL DIMENSIONS OF BUCKET ● Type Hoe bucket Length× 1.19×1.07×0.70 1.19×1.07×0.70 1.19×1.07×0.80 1.19×1.07×0.90 Height×Width (3′ 11×3′ 6″ ×2′ 4″ ) (3′ 11×3′ 6×2′ 4″ ) (3′ 11″ ×3′ 6″ ×2′ 7″ ) (3′ 11″ ×3′ 6″ ×2′ 11″ ) L×H×W m (ft-in) Weight kg 280 (620) 300 (660)
- Page 23 E115SR OVERALL DIMENSIONS OF A COMPLETE MACHINE ON A TRAILER ● 4.26m (14ft) Boom+2.2m (7ft-3in) Arm+ Type 0.45m (0.59cu･yd) Bucket+600mm (23.6in) Shoes Item Width mm(ft-in) 2,590 (8′ 6″ ) Weight kg(lbs) 11,900 (26,230) OVERALL DIMENSIONS OF WITHOUT ARM AND BUCKET ●...
- Page 24 OVERALL DIMENSIONS OF BOOM ● Type 4.26m (14ft) Boom Item Length×Height×Width 4.42×1.33×0.57 L×H×W m(ft-in) (14′ 6″ ×4′ 4″ ×1′ 10″ ) Weight kg (lbs) 790 (1,740) OVERALL DIMENSIONS OF ARM+BUCKET ● Type 2.2m (7ft-3in) Arm+0.45m (0.59cu･yd) Bucket Item Length×Height×Width 4.07×0.79×0.95 L×H×W m(ft-in) (13′...
- Page 25 OVERALL DIMENSIONS OF BUCKET ● Type Hoe bucket Length× 1.35×0.60×0.46 1.19×1.03×0.60 1.19×1.03×0.70 1.19×1.03×0.80 Height×Width (4′ 5″ ×2′ ×1′ 6″ ) (3′ 11″ ×3′ 5″ ×2′ ) (3′ 11″ ×3′ 5″ ×2′ 4″ ) (3′ 11″ ×3′ 5″ ×2′ 7″ ) L×H×W m (ft-in) Weight kg 210 (460)
- Page 26 E135SR DOZER OVERALL DIMENSIONS OF A COMPLETE MACHINE ● DOZER SPECIFICATIONS ● ITEM E135SR E135SR (From the center of the arm Length R1,630mm (5´4˝ ) R1,730mm (5´8˝ ) fixing pin to the tip of the blade) Width [600mm (23. 6˝ ) shoe only] 2,590mm (8´6˝...
- Page 27 E115SR OVERALL DIMENSIONS A COMPLETE MACHINE ● DOZER SPECIFICATIONS ● ITEM E115SR (From the center of the arm Length R1,630mm (5´4˝ ) fixing pin to the tip of the blade) Width [600mm (23. 6˝ ) shoe only] 2,590mm (8´6˝ ) Height 570mm (1´10˝...
-
Page 28: Specifications And Performance
5. SPECIFICATIONS AND PERFORMANCE E135SR E135SR (LC) 5.1 SPEED AND GRADEABILITY Model E135SR , E135SR (LC) Item Swing speed 11.7rpm km/h Travel speed (1-speed/2-speed) 2.8 / 5.1 (1.7 / 3.2) (mph) Gradeability %(degree) 70 (35) 5.2 ENGINE Engine model ISUZU BB－4BG1T Type Water-cooled, 4-cycle direct injection, turbo charged engine 4－105mm×125mm... - Page 29 E115SR 5.5 SPEED AND CLIMBING CAPABILITY Model E115SR Item Swing speed 11.4rpm km/h 3.5 / 6.0 (2.2 / 3.7) TRAVEL SPEED (1-speed/2-speed) (mph) Gradeability %(degree) 70 (35) 5.6 ENGINE Engine model ISUZU BB－4BG1T Type Water-cooled 4-cycle direct injection turbo charger engine 4－105mm×125mm...
-
Page 30: Type Of Crawler
6. TYPE OF CRAWLER E135SR( E135SR Overall width of Ground pressure Shape Shoe width mm (in) crawler mm (ft-in) kgf /cm (psi) Grouser shoe 500 (20) 2,490 (8′2″) 0.43 (6.12) 600 (24) 2,590 (8′6″) 0.36 (5.1) 700 (28) 2,690 (9′0″) 0.32 (4.49) 800 (32) 2,790 (9′2″) - Page 31 E115SR Overall width of Ground pressure Shape Shoe width mm (in) crawler mm (ft-in) kgf /cm (psi) Grouser shoe 500 (20) 2,490 (8′ 2″ ) 0.41 (5.83) 600 (24) 2,590 (8′ 6″ ) 0.34 (4.8) 700 (28) 2,690 (9′ 0″ ) 0.31 (4.41)
-
Page 32: Type Of Bucket
0.57(0.75) (0.56) (3′ 7″ ) (3′ 3″ ) (880) 0.50 1,150 0.70(0.92) ── (0.65) (3′ 9″ ) (880) E115SR Heaped Availability Hoe bucket Outer width mm (ft-in) W or W/O Struck Number of Weight capacity of face With side Without side tooth (cu･yd) -
Page 33: Combinations Of Attachment
(0.50) 0.43 0.57(0.75) ◎ △ × (0.56) 0.50 0.70(0.929 △ × × (0.65) E115SR Heaped Applicable Arm Hoe bucket Struck capacity (cu･yd) 1.9m (6′ 3″ ) Arm 2.2m (7′ 3″ ) Arm 2.7m (8′ 10″ ) Arm (cu･yd) 0.13 0.17(0.22) ○... -
Page 34: Engine Specification
9. ENGINE SPECIFICATION 9.1 SPECIFICATIONS Model E135SR E115SR Engine model ISUZU BB－4BG1T ISUZU BB－4BG1T Diesel, 4-cycle water-cooled, Diesel, 4-cycle water-cooled, in-line, direct injection, in-line, direct injection, Type turbo charger turbo charger Number of cylinder－ mm (in) 4×105(4.13)×125(4.92) ← Bore×Stroke Total displacement cc (cu･in) -
Page 35: Engine Characteristic Curve (Isuzu Bb 4Bg1T)
E135SR E135SR E135SR 9.2 ENGINE CHARACTERISTIC CURVE (ISUZU BB－4BG1T) Condition to be measured : With fan and generator Without muffler and air cleaner (N m) (kgf m) 313±20.0N m /About1600min － － (31.9±2.0kgf m /About1600min (33) (31) SHAFT SHAFT TORQUE TORQUE (29) (PS) - Page 36 E115SR 9.3 ENGINE CHARACTERISTIC CURVE (ISUZU BB－4BG1T) Condition to be measured : With fan and generator Without muffler and air cleaner (N m) (kgf m) 300±20.0N m /About1600min － (30.6±2.0kgf m /About1600min － (33) SHAFT TORQUE (31) SHAFT TORQUE (29)
- Page 37 E115SR E135SR SECTION 3 ATTACHMENT DIMENSIONS TABLE OF CONTENTS 1. Boom ........................3-1 1.1 Boom dimensional drawing ......................3-1 1.2 Boom maintenance standard ......................3-2 2. Arm ......................... 3-4 2.1 Arm dimensional drawing ........................ 3-4 2.2 Arm maintenance standard ......................3-5 3.
- Page 39 SECTION BB SECTION CC Fig. 1-1 Boom dimensional drawing Table 1-1 Unit : mm (ft-in) E135SR (LC) NAME E115SR E135SR Boom length 4,600 (15´1˝ ) 4,260 (13´12˝ ) Boom foot width 574 (1´10.6˝ ) 574 (1´10.6˝ ) Boom end inner width 274 (10.8˝...
- Page 40 (Rod side) (3.1496) (+0.0039) (+0.0028) +0.030 +0.180 Arm cylinder ∅70 (+0.0012) (+0.0071) +0.070 (Head side) (2.7559) (+0.0028) 2) E115SR Table 1-2 (2/2) Unit : mm (in) Standard value Clearance Remedy Item Bushing Pin dia. Standard Repairable Service -bol i.d. dia.
