- Page 1 REPAIR MANUAL NEW HOLLAND VM3080 VL5060 VL5070 VL5080...
- Page 2 Find manuals at https://best-manuals.com...
- Page 3 R1_04 08 Machine name change Correspondence Previous name New name VL 550 VL 5080 Up to series 008 Starting from series 009 VL 540 VL 5060 Up to series 008 Starting from series 009 VL 530 Up to series 008 VM 340 VM 3080 Up to series 008...
- Page 4 87613077B - - 07 - - 2008 Find manuals at https://best-manuals.com...
- Page 5 REPAIR MANUAL CONTENTS Section Description Specifications Maintenance Preparing the machine Thermal engine Hydrostatic transmission Brakes Hydraulic system Frame Steering Front axles and wheels Electrical system Harvesting equipment Product feeding Cleaning Hoppers Accessories (multipurpose) NOTE: corresponding to machines starting from series 002. 87613077B - - 07 - - 2008 Find manuals at https://best-manuals.com...
- Page 6 87613077B - - 07 - - 2008 Find manuals at https://best-manuals.com...
- Page 7 SPECIFICATIONS SPECIFICATIONS Chapter 1 CONTENTS Section Description Page Machine identification data ........... . . Self--propelled machine technical data .
- Page 8 SPECIFICATIONS 87613077B - - 07 - - 2008 Find manuals at https://best-manuals.com...
- Page 9 Type Serial no. Machine number VL5080 VL5070 VL5060 VM3080 NOTE: the harvesting equipment number is the same as the self- -propelled machine one. A = manufacturer’s label B = stamped frame number OPERATOR’S MANUAL Reference: 87612986 (GB) SPARE PART CATALOGUE...
- Page 10 SPECIFICATIONS DAV3 DAV1 DAV2 La 1 La 3 La 2 La AR La AV 1800 litres 2160 litres 2360 litres La B1 La B2 87613077B - - 07 - - 2008 Find manuals at https://best-manuals.com...
- Page 11 SPECIFICATIONS COMMERCIAL DESCRIPTION VL5080 / 5070 / VM3080 5060 Code DIMENSIONS (mm) Height: without cab 3160 3040 (at the revolving beacon) (3745) (3615) (harvesting equipment on with cab the ground) at the revolving beacon 3605 3475 Harvesting equipment height at the railings...
- Page 12 SPECIFICATIONS COMMERCIAL DESCRIPTION 5080 5070 5060 3080 WEIGHTS PTAC -- Total allowed weight under load (kg) 8000 7800 Partition Front axle (kg) 3400 from 3100 to 3400 4700 Rear axle (kg) from 4960 to 5200 from 4600 to 4800 Empty weight (kg) with harvesting equipment 6940 6600 6440...
- Page 13 Torque decrease on front wheels optional Max. speed in road position (km/h) Max. speed in field position (km/h) Hydraulic oil Capacity (litres) Reservoir Oil type New Holland Hydrosystem 68 Hydrosystem 68 BIO S Hydraulic filtering (intake/return) 87613077B - - 07 - - 2008...
- Page 14 SPECIFICATIONS COMMERCIAL DESCRIPTION 5080 5070 5060 3080 DRIVE (follows) Conveyor and extractor Make SAUER pump Displacement (cm /rev.) Empty operating speed (rpm) engine speed Capacity (l/minute), output 0.9 Double pump Make SAUER for shaking Displacement (cm /rev.) Empty operating speed (rpm) (1.02 x engine speed) Capacity (l/minute), output 0.9 50.49...
- Page 15 SPECIFICATIONS COMMERCIAL DESCRIPTION 5080 5070 5060 3080 TILTING CORRECTION Max. tilting (%) Max. tilting in road position (%) Max. tilting in work position (%) (with destemmers or special implements and front wheels with ballasts) FRAME Harvesting header quick uncoupling Link fitting possibility Front and rear tracks = see relevant SB PLATFORM CAB Heated and A/C cab, optional...
- Page 16 SPECIFICATIONS COMMERCIAL DESCRIPTION 5080 5070 5060 3080 LIGHTING AND WARNING LIGHTS High/low beams Front parking lights Rear parking lights Direction indicator Front lights Rear Side Stop lights License plate light Reflector Rear Revolving beacons Supply voltage Alternator Battery (Ah) Starting presetting 87613077B - - 07 - - 2008...
- Page 17 SPECIFICATIONS COMMERCIAL DESCRIPTION 5080 5070 5060 3080 HARVESTING EQUIPMENT HARVESTING HEADER Harvesting header hour counter Type -- swinging, self--aligning SDC shaking system Number of shakers Straight/elbow flexible connecting rod 13/1 11/1 11/1 Shaking start Motor SAUER EATON Displacement /rev.) Reducer control unit: -- ratio -- grease (kg) AMBRA GR75MD...
- Page 18 SPECIFICATIONS COMMERCIAL DESCRIPTION 5080 5070 5060 3080 HARVESTING EQUIPMENT (follows) Operation Motor EATON Displacement /rev.) Harvesting conveyors Width (mm) Speed (rpm) max. Reverse Single operation Motor EATON Displacement 31.6 /rev.) CLEANING 2 upper extractors with removable Diameter (mm) stalk choppers Motor SAUER Displacement...
- Page 19 SECTION 00 - - MAINTENANCE - - CHAPTER 1 SECTION 00 - - MAINTENANCE Chapter 1 CONTENTS Section Description ............Page Lubricant and liquid capacities .
- Page 20 SECTION 00 - - MAINTENANCE - - CHAPTER 1 LUBRICANT AND LIQUID CAPACITIES Quantity Corresponding Item to be supplied Recommended product international (litres) classification Self--propelled machine Grease Lithium--calcium based grease fittings AMBRA GR 9 grease, consistency NLGI 2 Grease 24 cartridges Harvesting machine grease fit- tings Food type...
- Page 21 SECTION 00 - - MAINTENANCE - - CHAPTER 1 THERMAL ENGINE MAINTENANCE a) After the first 50 hours c) Every 400 hours, or before each harvest- ing season, replace: engine oil, Let the engine run until it reaches the stan- replace oil filter cartridge/s, dard operating temperature.
- Page 22 SECTION 00 - - MAINTENANCE - - CHAPTER 1 87613077B - - 07 - - 2008...
- Page 23 SECTION 00 - - MAINTENANCE - - CHAPTER 1 GREASE POINTS - - VL5080 VL5070 VL5060 and VM3080 Position and number of grease fittings Greasing frequency 10 h 50 h SELF- -PROPELLED MACHINE Front legs 2 x 3 Steering cylinder articulation...
- Page 24 SECTION 00 - - MAINTENANCE - - CHAPTER 1 Hydraulic filter cover During reassembly, pay attention to the assembly direction: the (A) side with only one arrow on the cover must be directed towards the return line, the (B) side with two arrows on the cover must be directed towards the intake lines.
- Page 25 SECTION 00 - - MAINTENANCE - - CHAPTER 1 MACHINE WASHING To avoid sugar deposits and harvesting equipment MACHINE ARRANGEMENT FOR WASHING clogging and to preserve the harvesting quality, the AT THE END OF THE CAMPAIGN machine must be washed once or more times a day, especially after its utilization.
- Page 26 SECTION 00 - - MAINTENANCE - - CHAPTER 1 WASHING (in the washing area) After entering the washing area, lower the machine to about 10 cm from the ground and tilt the hoppers WARNING: this is a departure from fully. Make sure the inching lever is in neutral, engage the general safety requirements specified in the the hand brake, stop the thermal engine, get off the Operator’s Manual.
- Page 27 SECTION 00 - - MAINTENANCE - - CHAPTER 1 Wash carefully the machine rear outer part and Operate the machine to empty the hoppers and clean carefully the rear deflector inner part. Inject return to the washing area. water into the rear left and right deflectors Lift the machine at half height, tilt the hoppers through the special openings.
- Page 28 SECTION 00 - - MAINTENANCE - - CHAPTER 1 87613077B - - 07 - - 2008...
- Page 29 SECTION 00 - - MAINTENANCE - - CHAPTER 1 HYDROSTATIC AND HYDRAULIC SYSTEM MAINTENANCE 1) Intake and return filter cartridge replace- ment This cartridge must be replaced: every 800 hours, or every two years, WARNING: at each emptying. when topping oil up, use the same type used for the initial filling.
- Page 30 SECTION 00 - - MAINTENANCE - - CHAPTER 1 87613077B - - 07 - - 2008...
- Page 31 This as a preview PDF file from best-manuals.com Download full PDF manual at best-manuals.com...
