H3C 1000BASE-X-SFP Quick Start Manual

Manual version: 6PW103-20180115
24-port 1000BASE-X-SFP + 4-port 10GBASE-R-SFP+
optical Ethernet interface card—LSQM2GP24TSSA0
1 Card identifier
The card identifier LSQM2GP24TSSA0 is in the upper right corner of the front panel.
2 Specifications
IMPORTANT:
Before installing the card, you must remove the protection cover from the card to ensure correct
installation.
Table 1 Card specifications
Item
Card size (H × W × D)
SDRAM (DDR3)
Power consumption
Ports
Connector type
Port rate
Transmission medium and
max transmission distance
Applicable hardware platforms
System software version
Table 2 describes the SFP transceiver modules available for the card.
Table 2 SFP transceiver module specifications
Module
SFP-GE-SX-MM850-A
Specifications
40 × 399 × 355 mm (1.57 × 15.71 × 13.98 in)
1GB
25 W to 49 W
•
24 x 1000BASE-X-SFP fiber ports
•
4 x 10GBASE-R-SFP+ fiber ports
LC
•
1000 Mbps
•
10 Gbps
•
1000BASE-X-SFP fiber port: see
•
10GBASE-R-SFP+ fiber port: see
•
All S7500E models
•
All S7500X models
Release 7178 and Later
Central Connector
wavelength type
850 nm LC
850 nm LC
i
Table 2
Table 2 , Table
Cable
specifications
50/125 µm multi-mode
optical fiber
62.5/125 µm
multi-mode optical fiber
BOM: 3123A1AJ
3and Table 4
Maximum
transmission
distance
550 m (0.34 miles)
275 m (0.17 miles)
