  • Page 1 Workshop Service Manual Pickup Header 4300 North America July 2020 4205 River Green Parkway, Duluth GA 30096 USA 79037386D FENDT is a worldwide brand of AGCO © AGCO 2020 English...
  • Page 2 CALIFORNIA Proposition 65 Warning WARNING: Diesel engine exhaust and some of its constituents are known to the State of California to cause cancer, birth defects, or other reproductive harm. WARNING: Battery posts, terminals and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm.
  • Page 3 TABLE OF CONTENT General Frame Augers Drive system Draper Hydraulic system Electrical system Shielding Index Find manuals at https://best-manuals.com...

  • Page 4: Table Of Contents

    Table of contents 1 General ........... . 1-3 General information 1.1.1 Introduction to this service manual .
  • Page 5 Table of contents 1.9.2 Disconnect the header ..........1-35 1.10 Field operation .

  • Page 6: General Information

    1. General 1.1 General information GUID-D0FA2E94-0D28-42E9-A80B-6BB593BA9687 [V1] 1.1.1 Introduction to this service manual This service manual gives information from engineering tests, operating data, and the latest service techniques at the time of publication. Read this service manual carefully before doing any service on the machine.
  • Page 7 1. General Refrigerants for air conditioner released into the air can damage the air. It can be mandatory by local regulations that an approved maintenance center recover and recycle the used refrigerants. Make a check with a local environment or recycle center on the correct procedure to recycle or dispose of the waste.

  • Page 8: Safety

    1. General 1.2 Safety GUID-5D9F270E-D748-4741-82B1-BE49B78685F2 [V7] 1.2.1 Safety symbol The safety symbol tells you about an area that can be dangerous. Look for the safety symbol in this Operator's Manual and on the machine. The safety symbols tell you that there are important safety instructions in the manual.

  • Page 9: A Word To The Technician

    1. General Always make sure that the safety signs are in the correct locations and that you can read the safety signs. The illustrations of safety sign locations are in this section. Keep the safety signs clean. If it is necessary, clean the safety signs with a weak soap and water solution. GUID-3C35D58D-1F5D-4B85-A915-C7BB48F47262 [V1] 1.2.5 A word to the technician Read and understand the safety section in this...

  • Page 10: The Service Manual

    1. General GUID-0CC50E5C-AD62-4FFD-9435-62214FEFA5F4 [V1] 1.2.6 The service manual Read the table of contents and basic layout. Become familiar with all parts of this service manual. This service manual gives the technician very important information. Machine movement when in normal use determines right-hand and left-hand. This manual covers general safety practices for this machine.
  • Page 11 1. General Make sure the machine is in the proper operating condition according to the Operator Manual. Always operate the machine with the control console turned on. Do not dismount from moving machinery. Stay off slopes too steep for operation. Be aware of the size of the machine and have enough space available to allow for operation.
  • Page 12 1. General GUID-F38524AD-E24F-4FCC-9154-E5357EFDE9D2 [V3] 1.2.7.4 Seat instructions Put on the seat belt before you operate the machine. Always sit in the seat and have the seat belt on while you operate the machine. Replace the seat belts when they become worn or broken. Do not use a seat belt loosely.
  • Page 13 1. General GUID-AC6BA923-B398-43F4-BFAE-5130AFED6FC5 [V4] 1.2.7.6 Exhaust warning WARNING: Inhalation hazard. Exhaust gases. Death or serious illness can occur. Do not operate the engine in a closed building unless the exhaust is ventilated to the outside. Do not tamper with or modify the exhaust system with unapproved extensions.

  • Page 14: Travel On Public Roads

    1. General Use the same precautions when you do the adjustments, do servicing, clean or put the machine into storage. Tell all persons who are near chemicals of the possible dangerous results and the safety precautions that are necessary. Stay away from smoke from a chemical fire. Stay out of direction of wind if it is possible. Correctly keep or discard all chemicals that you do not use.

  • Page 15: Maintenance

    1. General Know the total width, length, height, and weight of the machine. Be careful when you operate the machine on narrow roads and across narrow bridges. Do not let the machine touch electrical power lines. If the machine touches electrical power lines, electrical shock injury and death can occur.
  • Page 16 1. General Do not operate the machine with the drive shaft shields open or removed. Entanglement in drive shafts that rotate can cause injury or death. Stay clear of components that rotate. Make sure that guards that rotate can rotate freely. A loose yoke can come off a shaft and result in injury to persons or damage to the machine.
  • Page 17 1. General GUID-9D716526-CF1A-4CD9-89A6-FD350D1B1E7A [V7] 1.2.9.2 Fire prevention and first aid Be prepared for emergencies. Keep a first aid kit available for use on small cuts and scratches. Keep one or more fire extinguishers of the correct type. Examine fire extinguishers regularly as stated by the manufacturer.
  • Page 18 1. General GUID-68111A90-0641-4B8F-9AB9-A5B05A044C46 [V4] 1.2.9.3 High pressure leaks WARNING: Hydraulic fluid under pressure can penetrate the skin or eyes. Serious personal injury, blindness, or death can occur. Relieve the pressure from the system or component before disconnecting components. Wear personal protective gear while working on the machine or equipment.

  • Page 19: Cylinder Stops

    1. General 1.3 Cylinder stops GUID-1AA01CA7-617D-474D-B875-6892E765C1A0 [V1] 1.3.1 Header lift cylinder stop Combines are equipped with a header lift cylinder stop on the left-hand side of the machine. Install the header lift cylinder stop on the header lift cylinder to prevent lowering of the header. See the information in the combine operator manual for header lift cylinder stop operation.
  • Page 20 1. General Move the hold-down cylinder supports (1) to the disengaged position. Install the retaining pin into the hold-down cylinder supports. GUID-AB30364A-FC25-4B4B-9BFC-154D9C7489A9-high.jpg [High] Fig. 26 Related Links page 1-16 Engage the hold-down cylinder support Pickup Header 1-17 79037386D...

  • Page 21: Machine Identification

    1. General GUID-0853B3F6-8A91-438A-9326-C54D60DEDBE0 [V5] 1.4 Machine identification Each machine is identified by a model and a serial number. Record these numbers in the spaces given. Give the model number and serial number to your dealer when parts or servicing are necessary. Machine model number: Machine serial number: Date of delivery:...
  • Page 22 1. General Check letter (0 or used if model identifier is Plant code five digits) Family code Model year code (G = 2016, H = 2017 , J = Unit number of the year 2018, K = 2019) (10) End symbol Pickup Header 1-19 79037386D...
  • Page 23 1. General GUID-C1C9BE9D-5D21-4B63-8373-C550392ACF74 [V3] 1.5 Component identification Draper Header This illustration shows the header components. GUID-BF6E5732-FECB-4FB3-AD8F-1F00E743C3CB-high.jpg [High] Fig. 29 Transport lamp (13) Draper drive motor Right-hand end shield, no hinge (14) Hold-down lift cylinder Throat frame (15) Gauge wheel Stripper plate (16) Reflector Auger (17) Handle...
  • Page 24 1. General HVJHE0110379701 GUID-EBCA7707-4D9F-46A4-B29F-39DA108C7606-low.svg [Low] Fig. 30 Coupler front side Original art: /m/TECHNICL/_MASSEY/MacDon/Svcman/4300 Pickup Header/2018 files from MacDon/graphics/1026265.pdf Drive pressure, white disc Drive pressure Hold down lift, black disc Electrical connector Coupler rear side Coupler - model year 2020 and after...
  • Page 25 1. General HVKBE0110100101 GUID-9192FF19-49D5-4E3F-9C69-020E1708E488-low.svg [Low] Fig. 31 Coupler front side Original art: /m/TECHNICL/_MASSEY/MacDon/Svcman/4300 Pickup Header/2018 files from MacDon/graphics/1026265.pdf Drive pressure, white disc Drive pressure Hold down lift, black disc Electrical connector Coupler rear side 1-22 Pickup Header 79037386D...

  • Page 26: Header Specifications

    Specifications and design are subject to change without notice and without liability therefore. GUID-6172DA69-A7B4-41FD-A45C-041DE4B28D6F [V1] 1.6.1 Header specifications Specifications and design can change at any time without notice or obligation to update previously sold machines. Specification 4300 Frame and Weight 3006 kg (3006 lb) structure Lighting...

  • Page 27: Header Dimensions

    1. General GUID-79D274D5-D3E3-42F4-9E2B-C941575C2633 [V1] 1.6.2 Header dimensions GUID-60904969-9EB3-4B03-91E0-236BA7825391-high.jpg [High] Fig. 32 5658 mm (222.8 in) 4766 mm (187 .6 in) 5170 mm (203.5 in) 5318 mm (209.4 in) 4523 mm (178.1 in) 2460 mm (96.9 in) 2513 mm (98.9 in) 1544 mm (60.8 in) 1380 mm (54.4 in) GUID-089791EA-EAA5-4528-A287-4D197680917F-high.jpg [High]...

  • Page 28: Lubrication Specifications

    1. General GUID-BA5D6CFD-1CE3-4F57-962A-DC717537D421 [V2] 1.6.3 Lubrication specifications Lubricant Specification Description Grease SAE Multi- High temperature extreme pressure All, unless a difference Purpose (EP2) performance with 1% max lubricant is specified. molybdenum disulphide (NLGI Grade 2) lithium base Extreme pressure (EP) performance Drive motor shaft with 1.5 to 5.0% molybdenum disulphide (NLGI Grade 2) lithium...
  • Page 29 1. General GUID-5BC19909-4AC7-4839-9B63-92554F3CEF30 [V2] 1.7 Troubleshooting Crop material goes over the table auger. Cause(s) Solution(s) Pickup is running too fast Slow the pickup down so the pickup is pushing the swath a small amount. Header height too high or too low Adjust the header height to 300 mm (12 in) measured from the ground to the center of the rear draper roller.
  • Page 30 1. General Pickup is picking up a large amount of dirt and stones. Cause(s) Solution(s) Pickup is running too fast. Slow the pickup down so the pickup is pushing the swath a small amount. Pickup teeth are set too low. Adjust the wheels so the teeth are 25 mm (1 in) off the ground Crop material stalls on the header before the auger pulls the material into the feeder house.
  • Page 31 This as a preview PDF file from best-manuals.com Download full PDF manual at best-manuals.com...
