MODENO Aurora Owner's Manual page 16

GAS COMPONENT CONNECTION CHECKS
Thermocouple
3. Make sure that the igniter pin and thermocouple are correctly positioned.
- The igniter pin should be pointed straight to the thermocouple.
- The thermocouple should be positioned 5mm / 0.196" away from the burner tube.
Thermocouple
Wire
4. Make sure that the thermocouple wire is correctly positioned. The thermocouple
wire should be in line with the valve.
Valve
Igniter Box
5mm /
0.196"
Thermocouple Wire
16 / 20
Igniter Pin
Wire should
be in line
with valve
Valve
