Manual no: ALPM23EN-G605-A5
!
!
IMPORTANT
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
!
WARNING
Do not store or use gasoline or other
flammable vapors and liquids, in the
vicinity of this or any other appliance.
An LP-cylinder not connected for use
should not be stored in the vicinity of
this or any other appliance.
FIRE OR EXPLOSION HAZARD
If you smell gas:
• Shut off gas to the appliance.
• Extinguish any open flame.
• If odor continues, leave the area immediately.
• After leaving the area, call your gas supplier or fire department.
Failure to follow these instructions could result in fire or explosion,
which could cause property damage, personal injury, or death.
!
DANGER
!
• If the information in this manual is not followed exactly,
a fire or explosion may result causing property damage
personal injury or loss of life.
Installation and service must be
performed by a qualified installer,
service agency or gas supplier.
Improper Installation, adjustment,
alteration, service or maintenance
can cause injury or property
damage.
Arden Fire Pit
OFG605LP
Owner's Manual
Gas Type: Propane
WARNING
Read the installation, operation
and maintenance instructions
thoroughly before installing or
servicing this equipment.
Save these instructions for
future reference. If you are
assembling this unit for someone
else, give this manual to him or her
to read and savefor future
reference.
!
WARNING
For outdoor use only
Installation and service must be
performed by a qualified installer,
service agency, or the gas supplier.
R
C
US

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Arden and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MODENO Arden

  • Page 1 Manual no: ALPM23EN-G605-A5 Arden Fire Pit OFG605LP Owner's Manual Gas Type: Propane IMPORTANT WARNING INSTALLER: • If the information in this manual is not followed exactly, Leave this manual with the appliance. a fire or explosion may result causing property damage CONSUMER: personal injury or loss of life.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Important Safety Information -------------------------------------------------------------------- 3 Propane (LP) Dangers and Warnings ----------------------------------------------------------5 Hose & Regulator Assembly and Replacement ---------------------------------------------7 Parts List ----------------------------------------------------------------------------------------------8 Assembly Instructions ---------------------------------------------------------------------------- 9 Lighting Instructions ------------------------------------------------------------------------------13 Care and Cleaning --------------------------------------------------------------------------------14 Gas Component Checks ----------------------------------------------------------------------- 15 Troubleshooting -----------------------------------------------------------------------------------17 Warranty -------------------------------------------------------------------------------------------- 19 DANGER...
  • Page 3: Important Safety Information

    IMPORTANT SAFETY INFORMATION WARNING FIRE TABLE IS FOR OUTDOOR USE ONLY IF YOU SMELL GAS • Shut off gas supply to the fire table. • Extinguish any open fame. • Do not try lighting any appliance. • Do not touch any electrical switch; do not use any phone in your building. •...
  • Page 4 IMPORTANT SAFETY INFORMATION • DO NOT use in an explosive atmosphere. Keep gas fire table area clear and free from combustible materials, gasoline and other flammable vapors and liquids. • This outdoor fire table is NOT to be operated by children. Young children should be closely supervised when in the vicinity of this outdoor fire table.
  • Page 5: Propane (Lp) Dangers And Warnings

    IMPORTANT SAFETY INFORMATION • Before each use, remove the lava rocks. Examine the burner and its components. If dirty, clean with a soft brush and soapy water solution. Examine the area around the burner; any dirt or foreign material, such as spider webs or nests in this area should be removed. If it is evident that the burner is damaged, the fire table must not be used.
  • Page 6 PROPANE (LP) DANGERS AND WARNINGS • The LP gas tank must have a tank collar to protect the tank valve. • LP gas cylinder must contain a shut-o valve as specified in the Standard for Compressed Gas Cylinder Valve Outlet and Inlet Connection, ANSI/CGA-V-1-1977, CSA B96. •...
  • Page 7: Hose & Regulator Assembly And Replacement

    HOSE & REGULATOR ASSEMBLY AND REPLACEMENT 1. This fireplace comes equipped with a standard LP gas hose and regulator including the appliance side connection for a CGA No 791 Cylinder Connection Device. The LP gas hose and regulator supplied with this fire table must be used. Only a hose and regulator specified by manufacturer can be used for replacement.
  • Page 8: Parts List

    PARTS LIST Item Picture Description Qty. WARNING Burner Ring 1 pc For technical support or replacement parts or missing parts please contact Ocean Rock USA at 800-678-7294. Guard 1 pc Fire bowl 1 pc Orifice 1 pc Valve 1 pc Ignitor 1 pc Control Knob...
  • Page 9: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Make sure the gas supply system is turned to “OFF”. Install the AAA battery as shown in the diagram below. 9 / 20...
  • Page 10 ASSEMBLY INSTRUCTIONS Remove door to insert propane tank (see step #3). Place propane tank (not included) in the metal stand inside body and make sure the gas tank sits on the metal stand completely. Turn the wing screw on the outer part of metal stand clockwise to secure the gas tank tightly.
  • Page 11 ASSEMBLY INSTRUCTIONS Connecting the LP Gas Tank Disconnecting the LP Gas Tank Check to make sure there is no debris in the Make sure the valve on the LP gas tank is head of the LP gas tank or in the head of the OFF.
  • Page 12 PRE-USE INSTRUCTIONS WARNING Before using this outdoor fire table, make sure you have read, understand and are following all information provided in the Important Safety Information section of this manual. Failure to follow those instructions can cause death, serious injury or property damage. Prior to each gas fireplace operation, check the hose and valve for evidence of excessive abrasion or wear though the visual check hole on the side of the base.
  • Page 13: Lighting Instructions

    LIGHTING INSTRUCTIONS Using the Ignitor 1. Read instructions before lighting. 2. Control knob must be in the “OFF”position. 3. Connect propane cylinder (See Manual), slowly open valve on LP gas cylinder. 4. Push and hold igniter button to create sparks. 5.
  • Page 14: Care And Cleaning

    CARE AND CLEANING Inspecting This outdoor fire table must be inspected regularly to insure that the product is safe to use and to extend product life. DO NOT inspect this outdoor fireplace until the fire is WARNING COMPLETELY out. 1. Check the burner to make sure it is securely in place. 2.
  • Page 15: Gas Component Checks

    GAS COMPONENT CONNECTION CHECKS If the burner will not light or stay lit, please perform the following checks. 1. Make sure the electrode wire is correctly connected. Both electrode wires must be fully inserted into the igniter box. the inner side Valve Thermocouple...
  • Page 16 GAS COMPONENT CONNECTION CHECKS 5mm / Thermocouple 0.196” Igniter Pin 3. Make sure that the igniter pin and thermocouple are correctly positioned. - The igniter pin should be pointed straight to the thermocouple. - The thermocouple should be positioned 5mm / 0.196” away from the burner tube. Valve Thermocouple Wire Thermocouple...
  • Page 17: Troubleshooting

    TROUBLESHOOTING Problem: Burner will not light using igniter Possible Cause 1: Electrode and burners are wet. -Wipe dry with cloth. Possible Cause 2: Igniter battery is dead or backwards. -Check that the AAA battery is inserted correctly in the igniter (see page 9) or replace the battery. Possible Cause 3: Igniter Pin cracked or broken - sparks at crack.
  • Page 18 TROUBLESHOOTING Problem: Sudden drop in gas flow, or a reduced flame height Possible Cause 1: Out of gas. -Refill your LP tank. Possible Cause 2: Excess flow safety device may have been activated. -Turn control knob to “OFF”, wait 30 seconds and light outdoor fireplace. If flames are still too low reset the excessive flow safety device by turning off the control knob and LP gas tank valve.
  • Page 19: Warranty

    Warranty Ocean Rock USA INC. warrants fire features and accessories to be free from defects in parts and workmanship under normal use and service for a period of 1 year from the date of purchase. In the event of such defects Ocean Rock will, at its option, repair or replace the defective product. The foregoing is at the discretion of Ocean Rock.
  • Page 20 Ocean Rock USA INC. 692 Parkridge Ave Norco, CA 92860, USA www.oceanrockusa.com info@oceanrockusa.com Tel: 800-678-7294...
