Manual No.: ANGM21EN-04014-A4
Aurora Fire Table / Westport Fire Table
!
!
IMPORTANT
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
!
WARNING
Do not store or use gasoline or other
flammable vapors and liquids, in the
vicinity of this or any other appliance.
This unit is not for use with propane.
Use only with Natural gas.
FIRE OR EXPLOSION HAZARD
If you smell gas:
• Shut off gas to the appliance.
• Extinguish any open flame.
• If odor continues, leave the area immediately.
• After leaving the area, call your gas supplier or fire department.
Failure to follow these instructions could result in fire or explosion,
which could cause property damage, personal injury, or death.
OFG114NG , OFG135NG
Gas Type: Natural Gas
!
DANGER
Owner's Manual
!
• If the information in this manual is not followed exactly,
a fire or explosion may result causing property damage
personal injury or loss of life.
•
Installation and service must be
performed by a qualified installer,
service agency or gas supplier.
•
Improper Installation, adjustment,
alteration, service or maintenance
can cause injury or property
damage.
WARNING
•
Read the installation, operation
and maintenance instructions
thoroughly before installing or
servicing this equipment.
•
Save these instructions for
future reference. If you are
assembling this unit for someone
else, give this manual to him or her
to read and savefor future
reference.
!
WARNING
For outdoor use only
Installation and service must be
performed by a qualified installer,
service agency, or the gas supplier.
R
C
US

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Aurora and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MODENO Aurora

Summary of Contents for MODENO Aurora

  • Page 1 Manual No.: ANGM21EN-04014-A4 Aurora Fire Table / Westport Fire Table OFG114NG , OFG135NG Owner's Manual Gas Type: Natural Gas IMPORTANT WARNING INSTALLER: • If the information in this manual is not followed exactly, Leave this manual with the appliance. a fire or explosion may result causing property damage CONSUMER: personal injury or loss of life.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Important Safety Information -----------------------------------------------------------------------3 Natural Gas Warnings -------------------------------------------------------------------------------5 Parts List ------------------------------------------------------------------------------------------------7 Pre-use Instructions ---------------------------------------------------------------------------------12 Lighting Instructions ---------------------------------------------------------------------------------13 Care and Cleaning -----------------------------------------------------------------------------------14 Gas Component Connection Checks -----------------------------------------------------------15 Troubleshooting --------------------------------------------------------------------------------------17 Warranty -----------------------------------------------------------------------------------------------19 DANGER CARBON MONOXIDE HAZARD This appliance can produce carbon monoxide which has no odor.

  • Page 3: Important Safety Information

    IMPORTANT SAFETY INFORMATION WARNING FIRE TABLE IS FOR OUTDOOR USE ONLY IF YOU SMELL GAS • Shut off gas supply to the fire table. • Extinguish any open fame. • Do not try lighting any appliance. • Do not touch any electrical switch; do not use any phone in your building. •...
  • Page 4 IMPORTANT SAFETY INFORMATION • DO NOT use this outdoor gas fire table for indoor heating. Toxic carbon monoxide fumes can accumulate and cause asphyxiation. • NEVER leave this gas fire pit unattended when in use. • Children and adults should be alerted to the hazards of high surface temperatures and should stay away to avoid burns or clothing ignition.

  • Page 5: Natural Gas Warnings

    IMPORTANT SAFETY INFORMATION • It is essential to keep the outdoor fire table valve compartment, burners, and circulating air passages clean. Inspect outdoor fire table before each use. • Prior to each fire table operation, check the hose for evidence of excessive abrasion or wear by looking through the visual check hole.
  • Page 6 NATURAL GAS DANGERS AND WARNINGS • Never store or use gasoline or other volatile substance in the vicinity of this fire table. Natural Gas Connection Connect a manual shut-off valve to gas supply line. Apply sealing compound or pipe thread tape of the type resistant to the action of natural gas on all male pipe threads.

  • Page 7: Parts List

    PARTS LIST Item Picture Description Qty. WARNING Burner Ring 1 pc For technical support or replacement parts or missing parts please contact Ocean Rock USA at 800-678-7294. Air inlet pipe 1 pc Guard 1 pc Burner Pan 1 pc Orifice 1 pc Valve 1 pc...
  • Page 8 ASSEMBLY INSTRUCTIONS Install the AAA battery as shown in the diagram below. Battery not included. Place lava rock by hand. DO NOT dump bag out in to the tray to avoid clogging the burner with dust. Position the lava rock to a level about 1” above the t op of the burner.
  • Page 9 ASSEMBLY INSTRUCTIONS Connecting your Fire Table to the Natural Gas Source A professionally installed shut-off valve between the supply piping and the socket is recommended by the National Fuel Gas Code. Socket connection must be made outdoors. 9 / 20...
  • Page 10 ASSEMBLY INSTRUCTIONS Connecting the Socket Coat the gas supply pipe nipple with gas resistant pipe compound or approved Teflon PTFE tape. Screw socket onto gas supply pipe (house gas source) as shown to the right, and wrench tighten. The quick disconnect socket should never be connected to the fire table.
  • Page 11 ASSEMBLY INSTRUCTIONS Using the Quick Connect Socket Pull back the sleeve on the quick disconnect socket and insert the unattached end of the gas hose into the socket. Release the sleeve and continue pushing the hose into the socket until the sleeve snaps into the locked position. After making all connections, perform a leak test as described on page 12 of this manual.

  • Page 12: Pre-Use Instructions

    PRE-USE INSTRUCTIONS WARNING Before using this outdoor fire table, make sure you have read, understand and are following all information provided in the Important Safety Information section of this manual. Failure to follow those instructions can cause death, serious injury or property damage.

  • Page 13: Lighting Instructions

    LIGHTING INSTRUCTIONS Using the Ignitor 1. Read instructions before lighting. 2. Burner control knob must be in the “OFF” position. 3. Connect natural gas source (see above pages). 4. Open the natural gas supply to the unit. 5. Push and hold igniter but t urn to create sparks. 6.

  • Page 14: Care And Cleaning

    CARE AND CLEANING Inspecting This outdoor fire table must be inspected regularly to insure that the product is safe to use and to extend product life. DO NOT inspect this outdoor fireplace until the fire is WARNING COMPLETELY out. 1. Check the burner to make sure it is securely in place. 2.

  • Page 15: Gas Component Connection Checks

    GAS COMPONENT CONNECTION CHECKS If the burner will not light or stay lit, please perform the following checks. 1. Make sure the electrode wire is correctly connected. Both electrode wires must be fully inserted into the igniter box. the inner side Valve Thermocouple...
  • Page 16 GAS COMPONENT CONNECTION CHECKS 5mm / Thermocouple 0.196” Igniter Pin 3. Make sure that the igniter pin and thermocouple are correctly positioned. - The igniter pin should be pointed straight to the thermocouple. - The thermocouple should be positioned 5mm / 0.196” away from the burner tube. Valve Thermocouple Wire Thermocouple...

  • Page 17: Troubleshooting

    TROUBLESHOOTING Problem: Burner will not light using igniter Possible Cause 1: Electrode and burners are wet. -Wipe dry with cloth. Possible Cause 2: Igniter battery is dead or backwards. -Check that the AAA battery is inserted correctly in the igniter (see page 8) or replace the battery. Possible Cause 3: Igniter Pin cracked or broken - sparks at crack.
  • Page 18 TROUBLESHOOTING Problem: Sudden drop in gas flow, or a reduced flame height Possible Cause 1: Out of gas. -Call your local gas company. Possible Cause 2: Excess flow safety device may have been activated. -Turn control knob to “OFF”, wait 30 seconds and light outdoor fire table. If flames are still too low reset the excessive flow safety device by turning off the control knob and the gas supply.

  • Page 19: Warranty

    Warranty Ocean Rock USA INC. warrants fire features and accessories to be free from defects in parts and workmanship under normal use and service for a period of 1 year from the date of purchase. In the event of such defects Ocean Rock will, at its option, repair or replace the defective product. The foregoing is at the discretion of Ocean Rock.
  • Page 20 Ocean Rock USA INC. 692 Parkridge Ave Norco, CA 92860, USA www.oceanrockusa.com info@oceanrockusa.com Tel: 800-678-7294...
