Standard Features
• ComfortNet™ Communicating System compatible
• Heavy-duty stainless-steel tubular heat exchanger
• Stainless-steel secondary heat exchanger
• Two-stage gas valve provides quiet,
economical heating
• Durable Silicon Nitride igniter
• Quiet two-speed induced draft blower
• Utilizes ComfortNet™ communicating, two-stage
or single-stage thermostats
• Self-diagnostic control board with constant memory
fault code history output to a dual 7-segment display
• Color-coded low-voltage terminals with provisions
for electronic air cleaner and humidifier
• Efficient and quiet variable-speed airflow
system gently ramps up or down according
to heating or cooling demand
• Multiple continuous fan speed options
offer quiet air circulation
• Auto-Comfort and enhanced
dehumidification modes available
• All models comply with California 40 ng/J
Low NOx emissions standards
• AHRI Certified; ETL Listed
SS-ACVC96
Amana® is a trademark of Maytag Corporation or its related companies and used under license to Goodman Company, L.P., Houston, Texas.
Heating Input: 40,000-120,000 BTU/h
Cabinet Features
• Designed for multi-position installation -
downflow, horizontal left or right
• Certified for direct vent (2-pipe) or
non-direct vent (1-pipe)
• Convenient left or right connection
for gas and electrical service
• Cabinet air leakage (Q
• Heavy-gauge steel cabinet with durable finish
• Fully insulated heat exchanger and blower section
• Airtight solid bottom or side return with easy-
cut tabs for effortless removal in bottom air-inlet
applications
* Complete warranty details available from your local dealer or at www.amana-hac.com. To receive the Lifetime
Heat Exchanger Limited Warranty, the Lifetime Unit Replacement Limited Warranty (in both cases good for as
long as you own your home), and the 10-Year Parts Limited Warranty, online registration must be completed
within 60 days of installation. Online registration is not required in California or Québec.
www.amana-hac.com
ACVC96
Two-Stage, Variable-Speed
ECM Gas Furnace
Up to 96% AFUE
Contents
Nomenclature ............................................2
Accessories ................................................2
Product Specifications ............................... 3
Dimensions ................................................4
Airflow Specifications ................................5
Wiring Diagram ..........................................8
) ≤ 2%
Leak
ENERGY STAR® and the ENERGY STAR mark are registered trademarks owned
by the U.S. Environmental Protection Agency. ENERGY STAR products are
third-party certified by an EPA-recognized Certification Body. Products that
earn the ENERGY STAR prevent greenhouse gas emissions by meeting strict
energy efficiency guidelines set by the U.S. Environmental Protection Agency.
2/17
Supersedes 12/16
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Amana ACVC96
Summary of Contents for Amana ACVC96
- Page 1 • All models comply with California 40 ng/J Low NOx emissions standards • AHRI Certified; ETL Listed * Complete warranty details available from your local dealer or at www.amana-hac.com. To receive the Lifetime Heat Exchanger Limited Warranty, the Lifetime Unit Replacement Limited Warranty (in both cases good for as long as you own your home), and the 10-Year Parts Limited Warranty, online registration must be completed within 60 days of installation. Online registration is not required in California or Québec. SS-ACVC96 www.amana-hac.com 2/17 Amana® is a trademark of Maytag Corporation or its related companies and used under license to Goodman Company, L.P., Houston, Texas. Supersedes 12/16...
- Page 2 100 -‐ 1 00,000 B TU/h 060 -‐ 6 0,000 B TU/h 120 -‐ 1 20,000 B TU/h 080 -‐ 8 0,000 B TU/h Accessories ACVC96 ACVC96 ACVC96 ACVC96 ACVC96...
- Page 3 Product Specifications ACVC96 ACVC96 ACVC96 ACVC96 ACVC96 0403BNA 0603BNA 0804CNA 1005CNA 1205DNA Heating Data High Fire Input¹ 40,000 60,000 80,000 100,000 120,000 High Fire Output¹ 38,400 57,600 76,800 96,000 115,200 Low-Fire Steady-State Input¹ 28,000 42,000 56,000 70,000 84,000 Low-Fire Steady-State Output¹ 26,880 40,320 53,760 67,200 80,640 AFUE² Temperature Rise Range (°F)
- Page 4 19½" ACVC961005CNA 21" 18⅛" 17½" 18" 19½" ACVC961205DNA 24½" 21⅝" 21" 21½" 23" Minimum Clearances to Combustible Materials Position Sides Rear Front Bottom Flue Downflow 0" 0" 3" 0" 1" Horizontal 6" 0" 3" 0" 6" C = If placed on combustible floor, the floor MUST be wood ONLY. NC = For installation on non-combustible floors only. A combustible floor sub-base must be used for installations on combustible flooring. www.amana-hac.com SS-ACVC96...
- Page 5 Minus 10% Minus 10% Minus 5% Minus 5% Normal Normal Plus 5% 1,021 Plus 5% 1,035 Plus 10% 1,069 Plus 10% 1,085 Minus 10% 1,076 Minus 10% Minus 5% 1,135 Minus 5% Normal 1,195 Normal Plus 5% 1,255 Plus 5% 1,042 Plus 10% 1,315 Plus 10% 1,091 Notes • All furnaces ship as high speed for cooling. Installer must adjust blower speed as needed. • For most jobs, about 400 CFM per ton when cooling is desirable. • Installation is to be adjusted to obtain temperature rise within the range specified on the rating plate. SS-ACVC96 www.amana-hac.com...
- Page 6 ACVC96 Airflow Data (cont.) ACVC960804CNA ACVC960804CNA Cooling Speeds Heating Speed ( @ .1" - .8" w.c. ESP) (@ .1" - .5" w.c. ESP; Rise Range: 45 - 75°F) High-Stage Low-Stage High-Stage Low-Stage Rise Adjust Adjust (°F) Minus 10% Minus 10% 1,111 Minus 5%...
- Page 7 ACVC96 Airflow Data (cont.) ACVC961205DNA ACVC961205DNA Cooling Speeds Heating Speed ( @ .1" - .8" w.c. ESP) (@ .1" - .5" w.c. ESP; Rise Range: 35 - 65°F) High-Stage Low-Stage High-Stage Low-Stage Rise Adjust Adjust (°F) Minus 10% Minus 10% 1,570 1,156...
- Page 8 Wiring Diagram Amana® is a trademark of Maytag Corporation or its related companies and used under license to Goodman Company, L.P. All rights reserved. Our continuing commitment to quality products may mean a change in specifications without notice. © 2014 Goodman Company, L.P. • Houston, Texas • Printed in the USA.
