Summary of Contents for HAMPTON BAY MORENO VALLEY FRS01606
Page 1
THANK YOU We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of these chairs. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity...
Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Right arm Left arm Backrest Chair seat Front skirt Seat cushion Back cushion Pillow...
Assembly Attaching the right arm to the backrest Attach the right arm (A) to the backrest (C) using the M6x35 combination bolts (BB). NOTE : Loosely tighten all bolts using the hex wrench (CC). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
Page 6
Assembly (continued) Attaching the left arm to the backrest Attach the left arm (B) to the backrest (C) using the M6x35combination bolts (BB). NOTE : Loosely tighten all bolts using the hex wrench (CC).
Page 7
Assembly (continued) Attaching the front skirt to the chair arms Attach the front skirt (E) to the right arm (A) and left arm (B) using the M6x30 combination bolts (AA). NOTE : Loosely tighten all bolts using the hex wrench (CC). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
Page 8
Assembly (continued) Attaching the chair seat to the arms, the backrest and the front skirt Attach the chair seat (D) to the right arm (A), the left arm (B) and the chair backrest (C) using the M6x35 combination bolts (BB). Attach the chair seat (D) to the front skirt (E) using M6x30 combination bolts (AA).
Assembly (continued) Checking the chair Turn the chair right side up. Ensure all connections are secure before use. Place the back cushion (G), the seat cushion (F) and the pillow (H) to nish the assembly of the chair. Care and Cleaning For best results, clean the frame and fabric with a damp cloth and dry thoroughly.
Page 10
Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
