USER GUIDE
mITX-KBL-S-C236
Doc. Rev. 1.6
Doc-ID: 1061-6790

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Kontron mITX-KBL-S-C236 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for S&T Kontron mITX-KBL-S-C236

Summary of Contents for S&T Kontron mITX-KBL-S-C236

  • Page 1  USER GUIDE mITX-KBL-S-C236 Doc. Rev. 1.6 Doc-ID: 1061-6790...
  • Page 2 mITX-KBL-S-C236 Doc. Rev. 1.6  MITX-KBL-S-C236 – USER GUIDE Disclaimer Kontron would like to point out that the information contained in this manual may be subject to alteration, particularly as a result of the constant upgrading of Kontron products. This document does not entail any guarantee on the part of Kontron with respect to technical processes described in the manual or any product characteristics set out in the manual.
  • Page 3 mITX-KBL-S-C236 Doc. Rev. 1.6 Intended Use THIS DEVICE AND ASSOCIATED SOFTWARE ARE NOT DESIGNED, MANUFACTURED OR INTENDED FOR USE OR RESALE FOR THE OPERATION OF NUCLEAR FACILITIES, THE NAVIGATION, CONTROL OR COMMUNICATION SYSTEMS FOR AIRCRAFT OR OTHER TRANSPORTATION, AIR TRAFFIC CONTROL, LIFE SUPPORT OR LIFE SUSTAINING APPLICATIONS, WEAPONS SYSTEMS, OR ANY OTHER APPLICATION IN A HAZARDOUS ENVIRONMENT, OR REQUIRING FAIL-SAFE PERFORMANCE, OR IN WHICH THE FAILURE OF PRODUCTS COULD LEAD DIRECTLY TO DEATH, PERSONAL INJURY, OR SEVERE PHYSICAL OR ENVIRONMENTAL DAMAGE (COLLECTIVELY, "HIGH RISK APPLICATIONS").
  • Page 4 mITX-KBL-S-C236 Doc. Rev. 1.6 Revision History Revision Brief Description of Changes Date of Issue Author Basic draft 2017-September-15 BIOS chapter added 2017-September-21 Block diagram modified 2018-January-12 added front panel connector, DP- 2018-October-09 ports Note Power Supply, SPK chapter 2019-May-07 removed, changed audio dat in technical data COM-Ports in Figure 2, picture in 2020-February-11...

  • Page 5: Symbols

    mITX-KBL-S-C236 Doc. Rev. 1.6 Symbols The following symbols may be used in this manual DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury. WARNING indicates a hazardous situation which, if not avoided, could result in death or serious injury. CAUTION indicates a hazardous situation which, if not avoided, may result in minor or moderate injury.

  • Page 6: Table Of Contents

    mITX-KBL-S-C236 Doc. Rev. 1.6 Table of Contents Symbols ..........................................5 Table of Contents ....................................... 6 List of Tables ........................................7 List of Figures ........................................7 Introduction ......................................9 Description ......................................10 Installation procedure ..................................11 3.1. Packing Check List ...................................... 11 3.2.

  • Page 7: List Of Tables

    mITX-KBL-S-C236 Doc. Rev. 1.6 Technical Support ..................................... 79 9.1. Warranty ........................................79 9.2. Returning Defective Merchandise ..............................79 List of Acronyms ....................................... 81 About Kontron ........................................82 List of Tables Table 1: Component Main Data ..................................15 Table 2: Environmental Conditions ................................17 Table 3: Certification and Compliance Information ..........................
  • Page 8 mITX-KBL-S-C236 Doc. Rev. 1.6 Figure 12: 9-pin COM1/2 Internal Connector (2 mm raster) ......................30 Figure 13: GPIO Internal Connector ................................31 Figure 14: CMOS1 Jumper ....................................32 Figure 15: Always ON Jumper ..................................32 Figure 16: LCD_PWR1 Internal Connector ..............................33 Figure 17: LVDS Connector ....................................

  • Page 9: 1/ Introduction

    mITX-KBL-S-C236 Doc. Rev. 1.6 1/ Introduction This manual describes the Mini ITX 8th generation S-C236 board. This board will also be denoted mITX-KBL-S-C236 within this Users Guide. The use of this Users Guide implies a basic knowledge of PC hard- and software. This manual is focussed on describing the mITX-KBL-S-C236 board’s special features and is not intended to be a standard PC textbook.

  • Page 10: 2/ Description

    mITX-KBL-S-C236 Doc. Rev. 1.6 2/ Description The mainboard mITX-KBL-S-C236 is based on the 8th generation processor family. It uses the Chipset C236 PCH from Intel. This powerful hardware with efficient graphic and network capabilities offers a broad range of application areas. The processor, graphics and memory controller is built on 22 nm die. Main characteristics are: ...

  • Page 11: 3/ Installation Procedure

    mITX-KBL-S-C236 Doc. Rev. 1.6 3/ Installation procedure 3.1. Packing Check List The mITX-KBL-S-C236 package includes the following basic items accompany with this manual.  One main board  One IO shield If any of these items is damaged or missed, please contact your vendor and save all packing materials for future replacement and maintenance.

  • Page 12: Requirements Iec60950-1

    mITX-KBL-S-C236 Doc. Rev. 1.6 Connecting Interfaces Insert all external cables for hard disk, keyboard etc. A monitor must be connected in order to change BIOS settings. Connect and turn on PSU Connect PSU to the board by the External Power of ATXPWR (20 poles power plug) and Internal Power of ATX4p (4 poles power plug) to the I/O Power jack.

  • Page 13: Lithium Battery Precautions

    mITX-KBL-S-C236 Doc. Rev. 1.6 3.4. Lithium battery precautions Danger of explosion if the lithium battery is incorrectly replaced. • Replace only with the same or equivalent type recommended by the manufacturer Dispose of used batteries according to the manufacturer’s instructions •...

  • Page 14: 4/ System Specifications

    mITX-KBL-S-C236 Doc. Rev. 1.6 4/ System specifications 4.1. Functional Block Diagram Figure 1: Functional Block Diagram www.kontron.com // 14...

  • Page 15: Component Main Data

    mITX-KBL-S-C236 Doc. Rev. 1.6 4.2. Component Main Data The table below summarizes the features of the mITX-KBL-S-C236 embedded motherboard. Table 1: Component Main Data Motherboard mITX-KBL-S-C236 Form factor Mini ITX (170.18 mm by 170.18 mm) Processor Onboard CPU variants Intel® 8th generation S Processor line, LGA1151 CPU Socket (37.5 mm x 37.5 mm) Range from 65 to 80 W TDP, Core™...
  • Page 16 mITX-KBL-S-C236 Doc. Rev. 1.6 CMOS Clear 1x 3 2 mm pin-header Front Panel 1x 24 pin connector LCD Power/Always 2x 3 2.0 mm pin-header; PS/2 1x 2.0 mm pin-header (for installing Windows) Display Intel®Gen 9 LP (generation 9 Low Power) graphics core with three pipes and 72 Execution Units ...

  • Page 17: Table 2: Environmental Conditions

    mITX-KBL-S-C236 Doc. Rev. 1.6 Table 2: Environmental Conditions Operating 0°C to +60°C (32°F~140°F) operating temperature (forced cooling). It is the customer’s responsibility to provide sufficient airflow around each of the components to keep them within allowed temperature range. Please refer to the thermal simulation report for information about airflow.

  • Page 18: 5/ Jumpers And Connectors

    mITX-KBL-S-C236 Doc. Rev. 1.6 5/ Jumpers and Connectors 5.1. Hardware Configuration Setting This chapter gives the definitions and shows the positions of jumpers, headers and connectors. All of the configuration jumpers on the board are in the proper position. The default settings shipped from factory are marked with an asterisk (*).

  • Page 19: Mainboard Placement And Rear I/O Locations

    mITX-KBL-S-C236 Doc. Rev. 1.6 5.2. Mainboard Placement and Rear I/O locations Figure 2: Front Side and Interfaces ATX-4-pin Power connector ATX 12 V power interface LPC1 Bus SATA connector Sys-Fan Battery holder COM2/COMB1 RS-232 Memory connector COM1/COMA1 RS232/422/485 CPU connector PCH chip controller Speaker GPIO feature connector...

  • Page 20: Figure 3: Rear View With Interfaces

    mITX-KBL-S-C236 Doc. Rev. 1.6 Figure 3: Rear View with Interfaces 4xUSB/3xEthernet 2x Display Port 1x DisplayPort (optional) Audio jacks www.kontron.com // 20...

  • Page 21: Rear Side

    mITX-KBL-S-C236 Doc. Rev. 1.6 5.3. Rear Side Figure 4: Bottom Side M.2 Interface Mounting hole for M.2-card www.kontron.com // 21...

  • Page 22: 6/ Pin Definitions

    mITX-KBL-S-C236 Doc. Rev. 1.6 6/ Pin Definitions The following sections provide pin definitions and detailed description of all on-board connectors. The connector definitions follow the following notation: Table 4: Connector Definitions Column Name Description Shows the pin-numbers in the connector. The graphical layout of the connector definition tables is made similar to the physical connectors.

  • Page 23: Processor Support

    mITX-KBL-S-C236 Doc. Rev. 1.6 6.1. Processor Support The Intel 8th generation Processor is a 64-bit, multi-core processor built on 14-nanometer process technology. The S-processor line is offered in a Two-Chip Platform and is connected to a discrete Intel® C236 Series Chipset Family Platform Controller Hub (KBL PCH-S) on the motherboard.

  • Page 24: Ethernet Connectors (I/O Area)

    mITX-KBL-S-C236 Doc. Rev. 1.6 Memory Module Description Part number DDR4-2133 non-ECC SODIMM 16GB 1060-2761 DDR4-2133 ECC SODIMM 4GB 1060-2762 DDR4-2133 ECC SODIMM 8GB 1060-2763 DDR4-2133 ECC SODIMM 16GB 1060-2764 6.3. Ethernet Connectors (I/O area) The mITX-KBL-S-C236 supports three channels of 10/100/1000 Mbit/s Ethernet (LAN1 to LAN3). In order to achieve the specified performance of the Ethernet port, Category 5 twisted pair cables must be used with 10/100 MByte/s and Category 5E, 6 or 6E with 1 Gbit/s LAN networks.

  • Page 25: Usb Connectors (I/O Area)

    mITX-KBL-S-C236 Doc. Rev. 1.6 Signal Description In MDI crossover mode, this pair acts as the BI_DD+/- pair. MDI[3]+ / MDI[3]- In MDI mode, this is the fourth pair in 1000Base-T, i.e. the BI_DD+/- pair. In MDI crossover mode, this pair acts as the BI_DC+/- pair. 6.4.

  • Page 26: Figure 7: Usb 2.0 High Speed Cable

    mITX-KBL-S-C236 Doc. Rev. 1.6 Figure 7: USB 2.0 High Speed Cable Polyvinyl Chloride (PVC) Jacket On-Twisted Power Pair: Red: V Black: Power Ground Twisted Signaling Pair: White: D- Green: D+ Inner Shield Aluminum Metallized Polyester Outer Shield ≥ 65% Interwoven Tinned Copper Braid 28 AWG Tinned Copper Drain Wire For USB3.0 cabling it is required to use only HiSpeed USB cable, specified in USB3.0 standard:...

  • Page 27: Audio Jack Connectors (I/O Area)

    mITX-KBL-S-C236 Doc. Rev. 1.6 6.5. Audio Jack Connectors (I/O area) Figure 9: Audio Jack Ring Sleeve Mating Audio Jack (example) Table 11: Pin Assignment (Line Out, green) Pin Designation Signal Type Note Front_OUT_L For headphone, max 1.6 V Ring Front_OUT_R For headphone, max 1.6 V Sleeve Table 12: Pin Assignment (Line In, blue)

  • Page 28: Fan Connectors (Internal)

    mITX-KBL-S-C236 Doc. Rev. 1.6 6.6. Fan Connectors (internal) The FANSYS (SYS_FAN) can be used to power, control and monitor a fan for chassis ventilation etc. The FANCPU (CPU_FAN) is used for the connection of the FAN for the CPU. The 4-pin header is recommended to be used for driving 4-wire type Fan in order to implement FAN speed control. Figure 10: 4-pin Fan Connector Table 15: 4-pin Mode Signal...

  • Page 29: Front Panel 1 (Internal)

    mITX-KBL-S-C236 Doc. Rev. 1.6 6.7. Front Panel 1 (internal) Figure 11: FP1 Connector Table 17: FP1 Connector Signal Signal USB6/7_5V USB6/7_5V USB6- USB7- USB6+ USB7+ LINE2-L SATA_LED SUS_LED PWRBTN_IN# RSTIN# SBV3V3 LINE-2R AGND AGND MIC2-L MIC2-R www.kontron.com // 29...

  • Page 30: Com1/Com2 Internal

    mITX-KBL-S-C236 Doc. Rev. 1.6 6.8. COM1/COM2 Internal Figure 12: 9-pin COM1/2 Internal Connector (2 mm raster) Table 18: COM1/2 Internal Connectors Description Description NDCD NDSR NSIN NRTS NSOUT NCTS NDTR Table 19: Signal Description Signal Description NDCD Data Carrier Detect NDSR Data Set Ready NSIN...

  • Page 31: Kontron Feature Connector (Gpio Internal)

    mITX-KBL-S-C236 Doc. Rev. 1.6 6.9. Kontron Feature Connector (GPIO Internal) Figure 13: GPIO Internal Connector Table 20: Pinout GPIO Description Description CASE_OPEN# SMBC SMBD PWR_OK EXT_BAT FAN3OUT FAN3IN SB3V3 SB5V GPIO0 GPIO1 GPIO2 GPIO3 GPIO4 GPIO5 GPIO6 GPIO7 GPIO8 GPIO9 GPIO10 GPIO11 GPIO12...

  • Page 32: Cmos1 Jumper

    mITX-KBL-S-C236 Doc. Rev. 1.6 6.10. CMOS1 Jumper Figure 14: CMOS1 Jumper Table 21: CMOS1 Internal Connection Description 3V_BATT RTCRST# Function: Pin1-2: Default Position Pin2-3: Clear CMOS 6.11. Always ON Jumper Figure 15: Always ON Jumper Table 22: Always ON Jumper Description PWRBTN_N PCH_RSMRST_N...

  • Page 33: Lcd_Pwr1 Internal

    mITX-KBL-S-C236 Doc. Rev. 1.6 6.12. LCD_PWR1 Internal Figure 16: LCD_PWR1 Internal Connector Table 23: LCD_PWR1 Internal Connection Description LCD_VOLTAGE 3.3V 6.13. LVDS (internal) Figure 17: LVDS Connector Table 24: LVDS Pin Assignment Description Description 12 V 12 V 12 V 12 V 12 V LCDVCC...

  • Page 34: Sata (Serial Ata) Disk Interfaces (Internal)

    mITX-KBL-S-C236 Doc. Rev. 1.6 Description Description LVDS B3- LVDS B3+ 6.14. SATA (Serial ATA) Disk Interfaces (internal) Figure 18: SATA Connector Table 25: Pin Assignment Signal Type SATA* TX+ SATA* TX- SATA* RX- SATA* RX+ Table 26: Signal Description Signal Description SATA* RX+ / RX- Host transmitter differential signal pair...

  • Page 35: 7/ Features And Power Supply

    mITX-KBL-S-C236 Doc. Rev. 1.6 7/ Features and Power Supply 7.1. Onboard Power Supply The KBL-S/mITX implements an on-board Intel IMVP8 regulator for the processor core and graphics core power supply. The main feature of Intel IMVP8 regulator is that it is serial Voltage Identification Definition (VID) based. Both the processor core and graphics core Voltage Regulator (VRs) are integrated into a single package.

  • Page 36: Power Management

    mITX-KBL-S-C236 Doc. Rev. 1.6 7.3. Power Management Processor supports ACPI 4.0a C0, C1, C1E, C3, C6, C7, C8, C9, C10 states. All power management handshakes are made on the DMI interface. None of the ‘Power State’ status signals can be observed on the board directly. Table 27: Power States State Description...

  • Page 37: 8/ Bios Setup Structure

    mITX-KBL-S-C236 Doc. Rev. 1.6 8/ BIOS Setup structure The Setup utility features for menus listed in the selection bar at the top of the screen:  Main  Advanced  Chipset  Security  Boot  Save & Exit The Setup menus are selected via the left and right arrow keys. The currently active menu and the currently active uEFI BIOS Setup item are highlighted in white.
  • Page 38 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description Low Power SO Idle Enable/Disable Low Power SO Idle Lpit Recidency Counter Select Recidency Counter PCI Delay Optimization Enable/Disable PCI Delay Optimization ZpODD Enable/Disable ZpODD C6DRAM Enable/Disable C6DRAM SW Guard Extensions (SGX) Enable/Disable Software Guard Extensions (SGX) Select Owner EPOCH input type There are three owner EPOCH modes...
  • Page 39 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description Flash Wear Out Protection Enable/Disable Flash Wear Out Protection Current Debug Interface Status Display Current Debug Interface Status Debug Interface Enable/Disable Debug Interface Support Debug Interface Lock Enable/Disable Debug Interface Lock Processor trace memory allocation Disable or select processor trace memory region size: from 4KB ~ 128MB CPU SMM...
  • Page 40 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description Configurable TDP Enable/Disable Configurable TDP Lock Lock CTDP BIOS Control Enable/Disable CTDP Control via runtime ACPI BIOS methods ConfigTDP Levels ConfigTDP Turbo Activation Ratio, Power Limit 1, Power Limit 2 Custom Settings Setting for Power Limit 1, Power Limit 2, Nominal Power Limit 1 Time Window, ConfigTDP Turbo Activation Ratio...
  • Page 41 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description Display PS Current Threshold3 Current Threshol Enable/Disable PS3 Enable Enable/Disable PS4 Enable IMON Display IMON Slope Slope IMON Display IMON Offset Offset IMON Set the Offset value as positive or Prefix negative Display VR Current Limit Current Limit Display VR Voltage Limit...
  • Page 42 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description Threshol Enable/Disable PS3 Enable Enable/Disable PS4 Enable IMON Display IMON Slope Slope IMON Display IMON Offset Offset IMON Set the Offset value as positive or Prefix negative Display VR Current Limit Current Limit Display VR Voltage Limit Voltage Limit...
  • Page 43 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description Enable/Disable PS3 Enable Enable/Disable PS4 Enable IMON Display IMON Slope Slope IMON Display IMON Offset Offset IMON Set the Offset value as positive or Prefix negative Display VR Current Limit Current Limit Display VR Voltage Limit Voltage Limit Enable/Disable TDC...
  • Page 44 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description IO MWAIT Redirection When set, will map IO_read instructions sent to IO registers PMG_IO_BASE_ADDRBASE+off set to MWAIT(offset) Package C State Limit Maximum Package C State Limit Setting C3 Latency Control (MSR 0X60A) Setting of Time Unit (Unit of measurement for IRTL value) and Latency C6/7 Short Latency Control (MSR...
  • Page 45 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description Features State Display Features State AMT BIOS Features Display AMT BIOS Features AMT Configuration ASF support Enable/Disable Alert Standard Format Support USB Provisioning of AMT Enable/Disable of AMT USB Provisioning CIRA Active Trigger CIRA boot Configuration Remote Assistance...
  • Page 46 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description ME Unconfig on RTC Clear Display ME Unconfig on RTC Clear Comms Hub Support Enable/Disable support for Comms Hub JHI Support Enable/Disable Intel® DAL Host Interface Service (JHI) Core Bios Done Message Enable/Disable Core Bios Done message sent to ME Firmware Update Configuration Enable/Disable Me FW Image Re-Flash...
  • Page 47 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description SensorHub Delay after applying power to SensorHub device I2C1 Controller Delay in _PSO I2C1 Controller TouchPad Delay after applying power to TouchPad device TouchPanel Delay in PR _ON after applying power to TouchPanel device P-state Capping Set _PPC and send ACPI notification USB Port 1...
  • Page 48 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description Hibernate ACPI Sleep State Select the highest ACPI sleep state the system will enter when the SUSPEND button is pressed Lock Legacy Resources Enable/Disable Lock Legacy Resources S3 Video Repost Enable/Disable S3 Video Repost SMART SMART Self Test Run SMART Self Test on all HDDs during...
  • Page 49 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description Putty KeyPad Select function key and keypad on Putty Redirection After BIOS The settings specify if bootLoader is POST selected then Legacy console redirection is disable before booting to Legacy OS COM1(Pci Bus0, Dev0, Func0) Enable Console Redirection Port is disable...
  • Page 50 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description LVDS LVDS Flat Panel Display Support Enable/Disable LVDS Flat Panel Display Configuration Support Panel Type Select the type or Manufacturer’s name of the display panel Resolution Select the screen resolution of the display panel Panel Color Depth Select the display panel color depth Panel Voltage...

  • Page 51: Chipset Setup Menu

    mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description specified speed Watchdog Function 0 = Disable. Enter the service interval in seconds before the system will reset ITE8528 Firmware Update This option is enable Auto Update when version is not match, force update or disable update EC firmware PC Speaker/Beep Control the default beeps during boot of...
  • Page 52 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description floor values Dram Display Dram Power Meter Setting Power Meter Setting Memory Lock Enabled: lock several PCU Thermal Thermal registers related to DDR Reportin Manage power/thermal ment management Register Extern Enabled: The value from EXTTS is used Therm Status...
  • Page 53 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description Warm Range [255;0]=[31.875;0] in Thresho W for OLTM, [127.5;0] in C ld Ch1 for CLTM Dimm1 Range [255;0]=[31.875;0] in Thresho W for OLTM, [127.5;0] in C for CLTM ld Ch1 Dimm0 Range [255;0]=[31.875;0] in Thresho W for OLTM, [127.5;0] in C ld Ch1...
  • Page 54 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description 1 enable Disable(Disable= Def) RAPL PL Range[0;2^14- 1 Power 1]=[2047.875;0] in W, (0= Def) RAPL PL Power PL 1 time windowX value, Window (1/1024)*(1+(x/4))*(2^y)(0= Def) RAPL PL Power PL 1 time windowY value, Window (1/1024)*(1+(x/4))*(2^y)(0= Def)
  • Page 55 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description Time Centering 2D Write Timing Centering 1D Enable/Disable Write Timing Centering 1D Write Voltage Centering 1D Enable/Disable Write Voltage Centering 1D Read Timing Centering 1D Enable/Disable Read Timing Centering 1D Dimm ODT Training* Dimm On-Die Termination Training Max RTT_WR...
  • Page 56 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description DIMM SPD Alias Test Test to determine if the SPD has been corrupted to cause memory aliasing Receive Enable Centering 1D Enable/Disable Receive Enable Centering 1D Retrain Margin Check Enable/Disable Retrain Margin Check Write Drive Strength Up/Dn Enable/Disable Write Drive independently...
  • Page 57 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description Probeless Trace HD Port, GDXC IOT/MOT od Disable Enable/Disable IED (Intel Enhanced Debug) Intel Enhanced Debug requires 4MB SMM memory Ch Hash Support Enable/Disable Channel Hash Support Ch Hash Mask Set the BIT(s) to be included in the XOR function Ch Hash Interleaved Bit Select the BIT to be used for...
  • Page 58 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description AUTO: 64 for ULX/ULT, 128 for DT/Halo Mrc Fast Boot Enable/Disable fast path thru the MRC Lpddr Mem WL Set Only applicable to LPDDR, Memory Write Latency Set selection (A is default, B will be used if memory devices support it) EV Loader...
  • Page 59 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description PAVP Enable Enable/Disable PAVP Cdynmax Clamping Enable Enable/Disable Cdynmax Clamping Cd Clock Frequency Select the highest Cd Clock Frequency supported by the platform IUER Button Enable Enable/Disable IUER Button Functionality DMI/OPI DMI Max Link Speed Set DMI Speed Configuration Gen1/Gen2/Gen3...
  • Page 60 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description control on DMI DMI IOT Enable/Disable DMI IOT PEG Port PEG 0:1:0 Enable Root Port Enable/Disable the Root Configuration Port Max Link Speed Configure PEG 0:1:0 Max Speed PEGO Slot Power Limit Value Sets the upper limit on power supplied by slot PEGO Slot Power Limit Scale...
  • Page 61 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description value for each Lane Lane 1 Value for Lane 1 Lane 2 Value for Lane 2 Lane 3 Value for Lane 3 Lane 4 Value for Lane 4 Lane 5 Value for Lane 5 Lane 6 Value for Lane 6 Lane 7...
  • Page 62 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description Lane 5 Value for Lane 5 Lane 6 Value for Lane 6 Lane 7 Value for Lane 7 Lane 8 Value for Lane 8 Lane 9 Value for Lane 9 Lane 10 Value for Lane 10 Lane 11 Value for Lane 11 Lane 12...
  • Page 63 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description test mode Jitter Dwell Time PEG Gen3 Preset Search dwell time [0..65535] in [usec] Jitter Error Target The margin search error target value [1..65535] VOC Dwell Time The VOC margin search dwell time [0..65535] in [usec] VOC Error Target The VOC margin search...
  • Page 64 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description Peer Memory Write Enable Peer Memory Write Enable/Disable Compliance Test Mode Enable when using Compliance Load Board PCIe-USB Glitch W/A PCIe-USB Glitch W/A for bad USB device(s) connected behind PCIE/PEG Port PCIe Function swap When Disabled, prevents PCIE rootport function swap PCI Express Gen3 Eq...
  • Page 65 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description PCIE15 Cm Display PCIE15 Cm PCIE15 Cp Display PCIE15 Cp PCIE16 Cm Display PCIE16 Cm PCIE16 Cp Display PCIE16 Cp PCIE17 Cm Display PCIE17 Cm PCIE17 Cp Display PCIE17 Cp PCIE18 Cm Display PCIE18 Cm PCIE18 Cp Display PCIE18 Cp PCIE19 Cm...
  • Page 66 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description Enable/Disable PCI Express Completion Timer T0 Enable/Disable SEFE Root PCI Express System Error on Fatal Error Enable/Disable SENFE Root PCI Express System Error on Non-Fatal Error Enable/Disable SECE Root PCI Express System Error on Correctable Error Enable/Disable PME SCI PCI Express PME SCI...
  • Page 67 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description Override default platform mapping Extra Detect Non- Detect Non-Compliance PCI options Express Device Compliance Device Prefetchable Prefetchable Memory Memory Range for this Root Bridge Reserved Reserved Memory Memory Alignment (0-31 bits) Alignment Prefetchable Prefetchable Memory Memory Alignment (0-31 bits)
  • Page 68 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description DITO Configuration Enable/Disable DITO Configuration DITO Value Display DITO Value DM Value Display DM Value SATA1 mSATA: Unknown Software Preserve Software Preserve Port 1 Enable/Disable SATA Port Hot Plug Designates this port as Hot Pluggable Configured as eSATA Hot Plug Supported...
  • Page 69 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description DITO Value Display DITO Value DM Value Display DM Value SATA3 J12: Unknown Software Preserve Software Preserve Port 3 Enable/Disable SATA Port Hot Plug Designates this port as Hot Pluggable Configured as eSATA Hot Plug Supported Spin Up Device Enable/Disable Spin Up...
  • Page 70 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description SATA7 J13: Unknown Software Preserve Software Preserve Port 7 Enable/Disable SATA Port Designates this port as Hot Pluggable Configured as eSATA Hot Plug Supported Spin Up Device Enable/Disable Spin Up Device SATA Device Type Identify the SATA port is connected to solid state drive or hard disk drive...
  • Page 71 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description iDisplay Audio Disconnect Disconnects SDI2 signal to hide/disable iDisplay Audio Codec PME Enable Enables PME wake of HD Audio controller during POST HD Audio I/O Buffer Select the ownership of the Advanced Control: I/O buffer between Intel HD Configuration Audio link vs I2S port (for...
  • Page 72 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description Detection Feature Audio DSP Enables/Disables 3rd Party Pre/Post- Processing Module Support Processing (identified by GUID) Module Support: Waves Post- process Enables/Disables 3rd Party Processing Module Support (identified by GUID) IntelSST Speech Enables/Disables 3rd Party Processing Module Support (identified by GUID) Dolby...
  • Page 73 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description Icepower IP Enables/Disables 3rd Party MFX sub Processing Module Support module (identified by GUID) Icepower IP EFX Enables/Disables 3rd Party sub module Processing Module Support (identified by GUID) Icepower IP SFX Enables/Disables 3rd Party sub module Processing Module Support (identified by GUID)
  • Page 74 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description Settings Connected Device Indicate what type of device is connected to this serial IO controller Serial IO ChipSelect Polarity Sets initial polarity for SPI0 ChipSelect signal Settings Serial IO Bluetooth Device Enables/Disables the UART0 vendor Sensor Settings...
  • Page 75 mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description the DCI which allows debug over the USB3 interface DCI Auto Detect Enable When set to Auto Detect, it detect DCI being connected during BIOS post time and enables DCI Debug Port Selection Select Kernel Debug Port and report in ACPI DBG2 table...

  • Page 76: Security Setup Menu

    mITX-KBL-S-C236 Doc. Rev. 1.6 Sub-Screen Function Description PCH Cross Throttling Enable/Disable PCH Cross Throttling feature Disable energy reporting Enable/Disable energy reporting feature Enable TC0 Timer Enable/Disable TC0 timer Pcie Pll SSC Pcie Pll SSC percentage Unlock PCH P2SB Unlock PCH P2SB SBI and configuration space by PSF PMC READ DISABLE This is TEST feature for PMC...
  • Page 77 mITX-KBL-S-C236 Doc. Rev. 1.6 Function Description Intel® BIOS Guard Intel BIOS Guard Support Enable or Disable Intel BIOS Guard Technology Support Intel TXT Display Intel TXT Information (Chipset, BiosScm, Chipset Txt, Cpu Txt, Error Code, Class Code, Information Major Code and Minor Code) Secure Boot System Mode Display System Mode...

  • Page 78: Boot Setup Menu

    mITX-KBL-S-C236 Doc. Rev. 1.6 8.5. Boot Setup Menu The Boot Setup menu lists the for boot device priority order, which is dynamically generated. Table 32: Boot Priority Order Function Description Boot Configuration Number of seconds to wait for setup activation key Setup Prompt Timeout Bootup NumLock State Select the keyboard NumLock state...

  • Page 79: 9/ Technical Support

    mITX-KBL-S-C236 Doc. Rev. 1.6 9/ Technical Support For technical support contact our Support department: E-mail: support@kontron.com Phone: +49-821-4086-888 Make sure you have the following information available when you call: Product ID Number (PN), Serial Number (SN) The serial number can be found on the Type Label, located on the product’s rear side. Be ready to explain the nature of your problem to the service technician.
  • Page 80 mITX-KBL-S-C236 Doc. Rev. 1.6 The goods for repair must be packed properly for shipping, considering shock and ESD protection. Goods returned to Kontron Europe GmbH in non-proper packaging will be considered as customer caused faults and cannot be accepted as warranty repairs. Include the RMA-Number with the shipping paperwork and send the product to the delivery address provided in the RMA form or received from Kontron RMA Support.

  • Page 81: List Of Acronyms

    mITX-KBL-S-C236 Doc. Rev. 1.6 List of Acronyms Error Checking and Correction Real Time Clock Field Replaceable Unit Trusted Platform Module Graphics Processing Unit UEFI Unified Extensible Firmware Interface Hard Disk mITX Mini ITX PCIe PCI-Express PECI Platform Environment Control Interface www.kontron.com // 81...

  • Page 82: About Kontron
