- Page 1 SIMP HOME L I F E B Y D E S I G N COSMOPOLITAN / CITY / ESSEX MEDIUM STORAGE CABINET MODEL # AXCRCOS15-MAH 1/17...
- Page 2 SIMP HOME L I F E B Y D E S I G N Questions, problems, assembly help, missing parts? No need to return the product, we will gladly help and ship your replacement parts free of charge Please call Customer Service at 1-866-518-0120 ext. 262 Monday to Friday between 9 am –...
-
Page 3: Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. SAFETY INFORMATION CAUTION: Injuries and damage can occur from furniture tip over if product is not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint provided with the product. -
Page 4: Care And Maintenance
IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. CARE and MAINTENANCE Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls, and in doing so it swells and shrinks. - Page 5 PRE-ASSEMBLY INFORMATION MODEL # AXCRCOS15-MAH PARTS DESCRIPTION LEFT SIDE RIGHT SIDE QTY 1 QTY 1 QTY 1 LEFT SHELF BOTTOM SHELF CENTRE SUPPORT QTY 2 QTY 1 QTY 1 LEFT DOOR RIGHT DOOR RIGHT SHELF QTY 1 QTY 1 QTY 2 Warning Label LEFT BACK PANEL RIGHT BACK PANEL...
- Page 6 PRE-ASSEMBLY INFORMATION MODEL # AXCRCOS15-MAH HARDWARE DESCRIPTION ALLEN KEY SCREW CAM LOCK PIN WOOD DOWEL Ø8 X 30 mm M6 X 30 mm CAM LOCK QTY 12 QTY 6 QTY 8 ALLEN KEY PHILLIPS SCREW ROUND HEAD SHELF SUPPORT QTY 1 QTY 19 QTY 24 M4 X 25 - QTY 2...
- Page 7 COMPONENTS – KEY DIAGRAM MODEL # AXCRCOS15-MAH 7/17...
- Page 8 ASSEMBLY MODEL # AXCRCOS15-MAH STEP 1 1. Insert 2 Wood Dowels 3 into pre-drilled holes on Bottom Shelf C . 2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. ½ length of Dowels should be exposed. 3.
- Page 9 ASSEMBLY MODEL # AXCRCOS15-MAH STEP 2 1. Insert 2 Wood Dowels 3 into pre-drilled holes on other side of Bottom Shelf C . 2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. ½ length of Dowels should be exposed. 3.
- Page 10 ASSEMBLY MODEL # AXCRCOS15-MAH STEP 3 1. Insert 2 Wood Dowels 3 into top corners of each Side BL , BR . 2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. ½ length of Dowels should be exposed. 3.
- Page 11 ASSEMBLY MODEL # AXCRCOS15-MAH STEP 4 Second Door First Door ( Left Door FL ) ( Right Door FR ) 1. Slide the wheels on bottom of each door to the slots on Bottom Shelf C . 2. Pull down the pins on top of each door then place the door to be parallel with the Cabinet side post.
- Page 12 ASSEMBLY MODEL # AXCRCOS15-MAH STEP 5 1. Use a Phillips screwdriver to attach Handles 7 to Doors FL , FR . 12/17...
- Page 13 ASSEMBLY MODEL # AXCRCOS15-MAH STEP 6 shelf level 1 shelf level 2 shelf level 3 shelf support anti - tipping 1. Use 4 Shelf Supports 5 for each Cabinet Shelf EL , ER in desired location. 2. 2 Shelf Supports 5 may be used on back top of each Cabinet Shelf EL , ER as a tipping restraint.
- Page 14 ASSEMBLY MODEL # AXCRCOS15-MAH STEP 7 1. Attach Back Panels GL , GR to back of cabinet using Phillips Screws Round Head 6 into guide holes. 2. Use Phillips screwdriver to tighten screws. 14/17...
- Page 15 FURNITURE TIP OVER RESTRAINT ASSEMBLY WARNING Serious or fatal crushing injuries can occur from furniture tip-over. If the furniture tip over restraint kit is not in the box, please contact our customer service department in order to obtain another kit before using the furniture. STEP 8 NOTE: The screwdriver is not included in the hardware pack.
- Page 16 FURNITURE TIP OVER RESTRAINT ASSEMBLY Furniture Tip Over Restraint Instructions: Attach one of the mounting brackets securely to the back edge of the furniture. Use the shorter screw. Determine where furniture is to be placed and mark location on the wall for mounting bracket screw hole approximately 2 inches below the bracket mounted to the furniture.
-
Page 17: Warranty
SIMP HOME L I F E B Y D E S I G N WARRANTY Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max product. These products have been made to demanding, high-quality standards and are guaranteed for domestic use against manufacturing faults for a period of 12 months from the date of purchase.
