- Page 1 FOT-F3 FIBER OPTIC TRANSCEIVER USER’S MANUAL...
- Page 3 Cabletron Systems reserves the right to make changes in specifications and other information contained in this document without prior notice. The reader should in all cases consult Cabletron Systems to determine whether any such changes have been made. The hardware, firmware, or software described in this manual is subject to change without notice.
-
Page 4: Fcc Notice
FCC NOTICE This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. -
Page 5: Vcci Notice
VCCI NOTICE This equipment is in the 1st Class Category (information equipment to be used in commercial and/or industrial areas) and conforms to the standards set by the Voluntary Control Council for Interference by Information Technology Equipment (VCCI) aimed at preventing radio interference in commercial and/or industrial areas. -
Page 6: Declaration Of Conformity
Full Name Managing Director - E.M.E.A. ________________________ Title Newbury, Berkshire, England ________________________ Location 89/336/EEC 73/23/EEC Cabletron Systems, Inc. 35 Industrial Way PO Box 5005 Rochester, NH 03867 Mr. J. Solari Cabletron Systems Limited Nexus House, Newbury Business Park London Road, Newbury... -
Page 7: Table Of Contents
CHAPTER 1 INTRODUCTION 1.1 USING THIS MANUAL...1-1 1.2 CONVENTIONS ...1-2 1.3 OVERVIEW OF THE FOT-F3 ...1-2 1.3.1 Connections ...1-3 1.3.2 Distance and Cable Type...1-4 1.3.3 LANVIEW LEDs ...1-5 1.3.4 Application...1-7 1.4 GETTING HELP ...1-9 1.5 RELATED MANUALS ...1-10 CHAPTER 2 INSTALLATION REQUIREMENTS 2.1 NETWORK DESIGN GUIDELINES ...2-1 2.1.1... - Page 8 CONTENTS CHAPTER 4 TESTING AND TROUBLESHOOTING 4.1 INSTALLATION CHECK-OUT ...4-1 4.1.1 Testing the Fiber Optic Link Segment...4-1 4.1.2 Testing the FOT-F3 Fiber Optic Transceiver ...4-3 4.2 USING LANVIEW...4-4 APPENDIX A SPECIFICATIONS FIBER OPTIC INTERFACE ... A-1 AUI CONNECTOR ... A-3 POWER SUPPLY ...
-
Page 9: Installation Requirements
Welcome to Cabletron Systems FOT-F3 Fiber Optic Transceiver User’s Manual . This manual serves as a simple installation and reference guide for the FOT-F3 transceiver. You should have a general working knowledge of Ethernet or IEEE 802.3 type data communications networks and their physical layer components before installing the FOT-F3. -
Page 10: Conventions
AUI interface (the AUI port connects the transceiver to a device or workstation via an AUI cable). The FOT-F3 also has the Cabletron Systems LANVIEW diagnostic system that monitors network activity and can help to quickly diagnose physical layer problems using its LEDs. -
Page 11: Connections
Version 2, and/or IEEE 802.3 equipment through an AUI port. However, the FOT-F3 uses 1300 nm wave-length optical transmitters and receivers and should be used only with Cabletron Systems Ethernet single mode products such as the FOMIM-36, FOMIM-32, and the FOMIM-38. FOT-F3 USER’S MANUAL... -
Page 12: Chapter 1: Introduction
However, Cabletron Systems only supports a distance of 5 kilometers. If using 62.5/125 multimode cable, signal distance is about 2 km. An AUI cable, up to 50 meters long, is used to connect an Ethernet device to the AUI port on the transceiver. -
Page 13: Lanview Leds
The FOT-F3 incorporates Cabletron Systems LANVIEW diagnostic and monitoring system. LANVIEW is a series of LEDs incorporated into all Cabletron Systems products. If a problem arises, troubleshooting of power failures, collisions, cable faults, or many other problems can be diagnosed rapidly using these LEDs. - Page 14 CHAPTER 1: INTRODUCTION PWR (Power) When on, this green LED indicates that the FOT-F3 is receiving power. SQE (Signal Quality Error) Test Function When on, this yellow LED indicates that SQE is enabled. XMT (Transmit) This green LED flashes to indicate that the FOT-F3 is transmitting frames onto the network.
-
Page 15: Application
The FOT-F3 can be configured into your network in many ways. For example, in Figure 1-3, a fiber optic link segment (4) is attached to a Cabletron Systems Multi Media Access Center (MMAC) (5) with a FOMIM-32/36/38. The MMAC serves as an intelligent repeater hub that links the fiber optic link segment to other network segments, regardless of media type. - Page 16 (4) of up to five kilometers runs from the FOT-F3 (3) to another FOT-F3 (5). The hardware connection is completed via another AUI cable (6) to a Cabletron Systems NBR-220 Ethernet Bridge (7) configured to provide an AUI interface.
-
Page 17: Getting Help
A description of your network environment (layout, cable type, etc.) • Network load and frame size at the time of trouble (if known) • The serial and revision numbers of all Cabletron Systems products in the network FOT-F3 USER’S MANUAL (603) 332-9400 Monday – Friday; 8... -
Page 18: Related Manuals
Use the manuals identified below to supplement the procedures and other technical data provided in this manual. The procedures contained in these manuals are referenced only. Cabletron Systems LAN-MD Portable Ethernet Tester • User’s Manual Cabletron Systems FOMIM-32/36/38 Fiber Optic Interface •... -
Page 19: Chapter 2 Installation Requirements
INSTALLATION REQUIREMENTS Before installing the FOT-F3 Fiber Optic Transceiver, all conditions, guidelines, specifications, and requirements included in this chapter and Appendix A must be met to ensure satisfactory performance from the FOT-F3. Failure to follow these guidelines may result in unsatisfactory network performance. -
Page 20: Aui Cable Requirements
CHAPTER 2: INSTALLATION REQUIREMENTS • When determining the maximum fiber optic cable length, the fiber optic budget and total network propagation delay should be calculated and taken into consideration before fiber runs are incorporated into any network design. Fiber optic budget is the combination of the optical loss due to the fiber optic cable, in-line splices, and fiber optic connectors. -
Page 21: Chapter 3 Installation
This chapter contains instructions for unpacking the FOT-F3 Transceiver, connecting the FOT-F3 to an Ethernet device and the network, surface mounting the transceiver (if necessary), and cable support installation. Verify that all the requirements listed in Chapter 2, Installation Requirements, and Appendix A, Specifications, are met before installing the transceiver. -
Page 22: Connecting The Fot-F3 To The Network
CHAPTER 3: INSTALLATION If you notice any discrepancies, contact Cabletron Systems Technical Support immediately. Refer to Chapter 1, Getting Help, for instructions. 3.2 CONNECTING THE FOT-F3 TO THE NETWORK After you are sure that all the requirements listed in Chapter 2,... -
Page 23: Connecting The Aui Cable
OT-F3 3.2.2 Connecting the AUI Cable To connect your Ethernet device to the FOT-F3, attach an AUI cable as follows. See Figure 3-2. Attach an AUI cable to the device to which the FOT-F3 will be connected. FOT-F3 USER’S MANUAL CONNECTING THE FOT-F3 TO THE NETWORK SQE SWITCH Enabled... - Page 24 CHAPTER 3: INSTALLATION Attach the female connector on the AUI cable to the AUI port on the FOT-F3. If the power is on for the Ethernet device, the PWR LED should be lit, indicating the transceiver is receiving power from the device. Also, if the SQE test is enabled, the SQE LED should be lit.
-
Page 25: Connecting The Fiber Optic Cable
Note: It is recommended to label the fiber optic cable to indicate which fiber is Receive and which is Transmit. When you buy fiber optic cable from Cabletron Systems, at one end of the cable, one fiber is labeled 1, and the other fiber is labeled 2. This pattern is repeated at the other end of the cable. - Page 26 CHAPTER 3: INSTALLATION ST connectors attach to ST ports much like BNC connectors attach to BNC ports. See Figure 3-3. The connector is inserted into the port with an alignment key on the connector inserted into the alignment slot on the port. The connector is then turned to lock it down.
- Page 27 ST Connectors Figure 3-3 ST Connectors Check that the LNK LED on the FOT-F3 is on. If the LED is off, perform each of the following steps until the LED is on: Check that the power is on for the device at the other end of the link.
-
Page 28: Surface Mounting The Fot-F3
CHAPTER 3: INSTALLATION If a link is not established, contact Cabletron Systems Technical Support. Refer to Chapter 1, Getting Help, for instructions. 3.3 SURFACE MOUNTING THE FOT-F3 Using the contents of the accessory package, you can mount the FOT-F3 on a surface close to the workstation or on the workstation itself. -
Page 29: Cable Support Installation
3.4 CABLE SUPPORT INSTALLATION Relieve the strain from the cables attached to the FOT-F3, whether or not the transceiver is mounted to a surface such as a wall. Note: Be sure each cable is securely attached to its port and that the slide latch on the AUI connector is secured to the lock posts on the AUI port. -
Page 30: Cable Strain Relief For Non-Mounted Fot-F3
CHAPTER 3: INSTALLATION DEVICE AUI Cable Figure 3-4 Surface Mounting the FOT-F3 3.4.2 Cable Strain Relief for Non-Mounted FOT-F3 To relieve the strain to cables connected to a FOT-F3 that is not surface mounted, proceed as follows: If possible, use long tie wraps to secure the FOT-F3 to a structural support such as a beam or a rafter. - Page 31 CABLE SUPPORT INSTALLATION The FOT-F3 is now ready for operation. We recommend that you test the system prior to transmitting data. Refer to Chapter 4, Testing And Troubleshooting, for information about how to test the system. FOT-F3 USER’S MANUAL 3-11...
- Page 32 CHAPTER 3: INSTALLATION 3-12 FOT-F3 USER’S MANUAL...
-
Page 33: Chapter 4 Testing And Troubleshooting
TESTING AND TROUBLESHOOTING This chapter lists procedures to test the FOT-F3 after it is connected to the network. A description of LANVIEW and its function in troubleshooting physical layer network problems is also provided. 4.1 INSTALLATION CHECK-OUT This section contains procedures to test the following •... - Page 34 CHAPTER 4: TESTING AND TROUBLESHOOTING Following the instructions for the test set, test the jumpers to get a reference level. Make a note of this reading. Disconnect the jumpers from the barrel connector. Using the jumper, attach the optical power meter to one end of one strand of the link segment.
-
Page 35: Testing The Fot-F3 Fiber Optic Transceiver
4.1.2 Testing the FOT-F3 Fiber Optic Transceiver Two Ethernet node testers capable of generating valid data packets, such as the LAN-MD, are required for this procedure. Refer to Figure 4-1 and proceed as follows: Using an AUI cable (2), connect a LAN-MD (1) to the FOT-F3 (3). -
Page 36: Using Lanview
If any failures are noted, please contact Cabletron Systems Technical Support. 4.2 USING LANVIEW The FOT-F3 Fiber Optic Transceiver uses Cabletron Systems LANVIEW, a built-in visual diagnostic and status monitoring system. LANVIEW LEDs are more effective than a network... - Page 37 Figure 4-2 shows the location of the LANVIEW LEDs on the FOT-F3. This is followed by a description of how to interpret the indications of these LANVIEW LEDs. FOT-F3 802.3 COMPATIBLE SINGLE MODE FIBER OPTIC TRANSCEIVER ® with LANVIEW Figure 4-2 LANVIEW LEDs Optical Link OK (LNK) LED When on, this green LED indicates that a link has been established between the receive circuitry of the FOT-F3 and the...
- Page 38 CHAPTER 4: TESTING AND TROUBLESHOOTING Receive (RCV) LED This yellow LED flashes to indicate that the transceiver is receiving a frame from the network. The flash of the LED is pulse stretched for easy viewing. The LED flashes when traffic is on the network, even if the data is not intended for the device attached to the FOT-F3.
- Page 39 USING LANVIEW Power (PWR) LED When on, this green LED indicates that the transceiver is receiving power from the device connected to the FOT-F3 AUI port. If this LED is off, power is not being received from the device or the DC-to-DC converter in the transceiver has failed.
- Page 40 CHAPTER 4: TESTING AND TROUBLESHOOTING FOT-F3 USER’S MANUAL...
-
Page 41: Fiber Optic Interface
This appendix contains the operational specifications for the FOT-F3. A.1 FIBER OPTIC INTERFACE The FOT-F3 has ST fiber optic ports. Table A-1 lists the parameters along with the associated typical, and minimum/ maximum specifications. Table A-1 Fiber Optic Interface Specifications Parameter Transmitter Peak Wave Length:... - Page 42 APPENDIX A: SPECIFICATIONS Table A-1 Fiber Optic Interface Specifications (Continued) Parameter Receive Sensitivity: Max. Receive Input Power: Transmitter Power at 25 C Into 8.3/125 m fiber: Output Power Coefficient: Notes: Transmitter Power decreases as temperatures rise and increases as temperatures fall. Use the Output Power Coefficient to calculate increased or decreased power output for your operating environment.
-
Page 43: A.2 Aui Connector
A.2 AUI CONNECTOR The AUI connector is a male DB15 receptacle with a metal shell for cable shielding. Refer to Figure A-1 for pinout identification. Pin 8 Logic Ref. Pin 7 No Connection Pin 6 Power Return Pin 5 Receive + Pin 4 Logic Ref. -
Page 44: A.5 Agency Approvals
APPENDIX A: SPECIFICATIONS A.4 ENVIRONMENTAL Table A-3 provides the FOT-F3 environmental specifications. Table A-3 Environmental Specifications Parameter Operating Temperature: Operating Humidity: A.5 AGENCY APPROVALS Safety The FOT-F3 meets the safety requirements of UL1950, CSA C22.2 No. 950, EN 60950, and 73/23/EEC. Electromagnetic Compatibility The FOT-F3 meets the EMC requirements of FCC Part 15 Class A, EN 55022 Class A, VCCI Class I, EN 50082-1, and...
