TECHNICAL FEATURES

Water supply connection
Type of connection
Type of disconnection
Venturi flow rates
Actuating systems
No. of product inlets
Maximum dimensions
Working pressure
Temperature
Notes
READ CAREFULLY BEFORE INSTALLING
• The correct procedures for dispenser installations are provided.
• Do not install where the dispenser is directly exposed to vapors or chemical fumes. Do not position
near sources of heat.
• Protect yourself: wear protective clothing and eye-wear when installing or maintaining the system,
take specific precautions as necessary.
• Follow the safety and handling instructions.
• Direct product discharge hose only into a specific container—not toward yourself or another person.
• Calibrate the dosing as per the product label instructions.
• This unit is supplied with an internal back-flow prevention device to avoid water supply contamination.
Local compliances standards may vary. Some jurisdictions may require a back-flow prevention device
at the system's water inlet.
• The maximum operating pressure is 9 bars (130 PSI) and is intended as a maximum static pressure
applicable to the system. Care should be taken that the equipment cannot produce scenarios of
over-pressurization, which could cause damage to the structure of the system. The use of a pressure
reducer is always recommended and the installation of a tap on the water outlet of the system, which
can be closed when the system itself is not in use.
To prevent siphoning and to comply with ASME A112.1.2, install the dispenser so the end of the dis-
charge tube is a minimum of 10 cm (4") above the flood level of the sink or other fixed container.
The dispenser should be installed approximately 1.5 m (5 ft) from the ground and near the chemical
containers for convenient use.
Possible from right or left
3/4" Female GHT
F-Gap (Flexible membrane)
A-Gap (Physical, visible gap)
1 GPM (Gray)
Button
1 (models B1 and S1)
H = 22 cm (8 3/4")
Min 15 PSI (1 bar)
Ideal: 30 – 60 PSI (2 – 4 bars)
Max 160° F (70° C)
Possibility of adding modules after installation
3.5 – 4 GPM (Yellow)
W = 10 cm (3 7/8")
Max 130 PSI (9 bars)
D = 12 cm (4 5/8")
