Intr
Intr
oduction
oduction
Intr
Intr oduction
Intr
oduction
oduction
Thank you for purchasing this fine distribution amplifier (splitter)
for S-Video-based video equipment. These products allow for the
output of S-Video signals to be seen on up to 6 monitors
simultaneously or connected to video equipment depending on the
splitter purchased. Each connection can be located up to 250 feet
away from the splitter.
This product is supplied with the following components:
1 TwinSplit or HexiSplit for S-Video
1 Power Supply (a power cord may also be included on 220 Vac
models)
1 User's Manual and Product Registration card
Key features of these splitters are:
* 300 MHz bandwidth
* Independently buffered outputs
1 Full bandwidth on both Y and C channels
TwinSplit and HexiSplit are registered trademarks of Communications Specialties, Inc.
USER'S MANUAL
TwinSplit
& HexiSplit
55 Cabot Court, Hauppauge, NY 11788
Tel: (631) 273-0404 Fax: (631) 273-1638
www.commspecial.com
Communications Specialties Pte Ltd
Singapore
Tel: +65 6391 8790 Fax: +65 6396 0138
for S-Video
P/N 101194 Rev. D
