Models / Modelos/ Modèles:
LRO-1G5, LRO-2G5, LRO-1E5, LRO-2E5
Installation, Service and Parts Manual
Installation, Service et Pièces Manuel / Instalación, Servicio y Manual de Piezas
Keep This Manual with the Oven
Conservez ce Manuel avec le Four / Mantener este Manual con el Horno
LBC Bakery Equipment, Inc.
st
6026 31
Ave NE, Marysville, WA 98271, USA
Toll Free: 888-722-5686
Email:
sales@lbcbakery.com
Rev: 10-19
Copyright 2016-2019 LBC Bakery Equipment Inc. Marysville WA USA
P a g e
| 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LBC LRO-1G5 and is the answer not in the manual?

Questions and answers

Related Manuals for sinmag LBC LRO-1G5

Summary of Contents for sinmag LBC LRO-1G5

  • Page 1 Models / Modelos/ Modèles: LRO-1G5, LRO-2G5, LRO-1E5, LRO-2E5 Installation, Service and Parts Manual Installation, Service et Pièces Manuel / Instalación, Servicio y Manual de Piezas Keep This Manual with the Oven Conservez ce Manuel avec le Four / Mantener este Manual con el Horno LBC Bakery Equipment, Inc.

  • Page 2: Table Of Contents

    Contents Notes ............................... 3 Notices (English) ..........................4 Notices (François) ........................... 5 Notices (Española) .......................... 6 Specifications (Gas Ovens)/ Specifications / Especificaciones ............7 Specifications (Electric Ovens)/ Spécifications / Especificaciones ..........8 Drawings ............................9 Conditions of Installation / 'Les conditions d'Installation / Condiciones la Instalación ....11 Must Read! (English)........................

  • Page 3: Notes

    Notes THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE. READ, UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS CONTAINED IN THIS MANUAL. CE MANUEL DOIT ÊTRE RETENU POUR RÉFÉRENCE FUTURE. LIRE, COMPRENDRE ET SUIVRE LES INSTRUCTIONS ET LES AVERTISSEMENTS CONTENUS DANS CE MANUEL. ESTE MANUAL DEBE SER RETENIDO PARA FUTURAS REFERENCIAS.

  • Page 4: Notices (English)

    Notices (English) FOR YOUR SAFETY DO NOT STORE OR USE GASOLINE OR OTHER FLAMABLE LIQUIDS IN THE VICINITY OF THIS OR ANY OTHER APPLIANCE. POST IN A PROMINENT LOCATION. IF YOU SMELL GAS, TURN OFF THE GAS AND CALL YOUR GAS SUPPLIER AND YOUR AUTHORIZED SERVICE AGENT.

  • Page 5: Notices (François)

    Notices (François) POUR VOTRE SÉCURITÉ NE PAS ENTREPOSER OU UTILISER DE L'ESSENCE OU D'AUTRES LIQUIDES INFLAMMABLES À PROXIMITÉ DE CET APPAREIL OU DE TOUT AUTRE APPAREIL. POSTE DANS UN ENDROIT PROBABLE. SI VOUS SENTEZ DU GAZ, ARRÊTEZ LE GAZ ET APPELER VOTRE FOURNISSEUR DE GAZ ET VOTRE AGENT DE SERVICE AUTORISÉ.

  • Page 6: Notices (Española)

    Notices (Española) POR TU SEGURIDAD NO ALMACENE NI UTILICE GASOLINA U OTROS LÍQUIDOS INFLAMABLES EN EL LUGAR DE ESTE O CUALQUIER OTRO APARATO. PUBLICAR EN UNA UBICACIÓN PROMINENTE. SI HUELE GAS, APAGUE EL GAS Y LLAME A SU PROVEEDOR DE GAS YA SU AGENTE DE SERVICIO AUTORIZADO.

  • Page 7: Specifications (Gas Ovens)/ Specifications / Especificaciones

    Specifications (Gas Ovens)/ Specifications / Especificaciones Class / Weight / Poids / Peso Classe / Model / Clearance to Combustibles / Clase Modèle / H x W x D* Distance aux combustibles / Actual / Crated / Modele Distancia hasta Combustibles Réel / Crated / Real...

  • Page 8: Specifications (Electric Ovens)/ Spécifications / Especificaciones

    Specifications (Electric Ovens)/ Spécifications / Especificaciones Class / Weight / Poids / Peso Classe / Model / Clearance to Combustibles / Clase Modèle / H x W x D* Distance aux combustibles / Actual / Crated / Modele Distancia hasta Combustibles Réel / Crated / Real...

  • Page 9: Drawings

    Drawings LRO-1E/G5 LRO-2E/G5 Copyright 2016-2019 LBC Bakery Equipment Inc. Marysville WA USA P a g e...
  • Page 10 1) Roof-top ventilator (not supplied) / Ventilateur de toit (non fourni) / Ventilador de techo (no suministrado) 2) Riser / Bordure du Trottoir / Bordillo 3) Pipe space to combustibles / Espace minimum pour combustiles / Espacio mínimo para combustiles If Type I Hood = 18in [460mm];...

  • Page 11: Conditions Of Installation / 'Les Conditions D'installation / Condiciones La Instalación

    Conditions of Installation / 'Les conditions d'Installation / Condiciones la Instalación CAUTION Rack ovens are large and require special handling equipment. Rack ovens cannot be off-loaded from a liftgate truck without a fork lift. Door openings to the site must be big enough for the crates.
  • Page 12 PRECAUCIÓN Los hornos de estantes son grandes y requieren un equipo de manejo especial. Los hornos Rack no se pueden descargar desde un camión con puerta levadiza sin una carretilla elevadora. Las aberturas de las puertas del sitio deben ser lo suficientemente grandes para las cajas.

  • Page 13: Must Read! (English)

    Must Read! (English) WARNING INSTALLATION OF THE UNIT MUST BE DONE BY PERSONNEL QUALIFIED TO WORK WITH ELECTRICITY AND PLUMBING. IMPROPER INSTALLATION CAN CAUSE INJURY TO PERSONNEL AND/OR DAMAGE TO EQUIPMENT. UNIT MUST BE INSTALLED IN ACCORDANCE WITH ALL APPLICABLE CODES. WARNING DO NOT ALLOW ANY PART OF YOUR BODY TO BE UNDER THE OVEN DURING THE LIFTING PROCESS.
  • Page 14 WIRING MUST BE IN ACCORDANCE WITH THE CURRENT CANADIAN ELECTRICAL CODE, C22.1 PART 1. GROUNDING THIS APPLIANCE MUST CONFORM TO CANADIAN ELECTRICAL CODE, CSA C22.2. CAUTION: TO REDUCE THE RISK OF FIRE, THE APPLIANCE IS TO BE MOUNTED ON FLOORS OF NON- COMBUSTIBLE CONSTRUCTION WITH NONCOMBUSTIBLE FLOORING, SURFACE FINISH AND WITH NO COMBUSTIBLE MATERIAL AGAINST THE UNDERSIDE THEREOF, OR ON NON-COMBUSTIBLE SLABS OR ARCHES HAVING NO COMBUSTIBLE MATERIAL AGAINST THE UNDERSIDE.

  • Page 15: Doit Lire! (François)

    Doit lire! (François) ATTENTION L'INSTALLATION DE L'UNITÉ DOIT ÊTRE EFFECTUÉE PAR DU PERSONNEL QUALIFIÉ POUR TRAVAILLER AVEC L'ÉLECTRICITÉ ET LA PLOMBERIE. UNE INSTALLATION INCORRECTE PEUT CAUSER DES BLESSURES AU PERSONNEL ET / OU ENDOMMAGER L'ÉQUIPEMENT. L'UNITE DOIT ETRE INSTALLEE CONFORMEMENT A TOUS LES CODES APPLICABLES.
  • Page 16 PRUDENCE: POUR RÉDUIRE LE RISQUE D'INCENDIE, L'APPAREIL DOIT ÊTRE MONTÉ SUR DES PLANCHERS DE CONSTRUCTION NON COMBUSTIBLE AVEC PLANCHER NON COMBUSTIBLE, FINI DE SURFACE ET SANS MATÉRIAU COMBUSTIBLE CONTRE LE SOUS-SOL OU SUR DES DALLES OU DES ARCHES NON COMBUSTIBLES N'AYANT AUCUN MATÉRIAU COMBUSTIBLE CONTRE LE FEU DESSOUS. CETTE CONSTRUCTION S'ÉTEND AU MINIMUM DE 12 POUCES AU-DELÀ...

  • Page 17: Debe Leer! (Español)

    Debe leer! (Español) ADVERTENCIA LA INSTALACIÓN DE LA UNIDAD DEBE SER REALIZADA POR PERSONAL CUALIFICADO PARA TRABAJAR CON ELECTRICIDAD Y PLOMERÍA. LA INSTALACIÓN INCORRECTA PUEDE CAUSAR LESIONES AL PERSONAL Y / O DAÑOS AL EQUIPO. LA UNIDAD DEBE INSTALARSE DE ACUERDO CON TODOS LOS CÓDIGOS APLICABLES. ADVERTENCIA NO PERMITA QUE CUALQUIER PARTE DEL CUERPO SE ENCUENTRE BAJO EL HORNO DURANTE EL PROCESO DE ELEVACIÓN.
  • Page 18 PRECAUCIÓN: PARA LA INSTALACIÓN EN CANADÁ, LA INSTALACIÓN DEBE ESTAR DE ACUERDO CON CAN / CGA-B149.1 Y 2 DEL CÓDIGO DE INSTALACIÓN, Y LOS CÓDIGOS LOCALES DONDE CORRESPONDA. TODOS LOS CABLEADOS ELÉCTRICOS DEBEN RESPETARSE CON EL CÓDIGO ELÉCTRICO CANADIENSE ACTUAL, C22.1 PARTE 1. PUESTA A TIERRA ESTE APARATO DEBE CONFORMARSE CON EL CÓDIGO ELÉCTRICO CANADIENSE, CSA C22.2.

  • Page 19: Assembly (English)

    Assembly (English) See Oven Assembly Instructions insert. Assemblée (François) Voir la notice d'instructions de montage du four. Asamblea (Español) Ver inserción de las instrucciones de montaje del horno. Copyright 2016-2019 LBC Bakery Equipment Inc. Marysville WA USA P a g e | 19...

  • Page 20: Electrical Connections (Gas)

    Electrical Connections (Gas) Note: The electrical connection for gas ovens requires a single supply for the circulation motor and the control circuit. This is important so that the oven will not operate without the circulation motor running. Remarque: Le raccordement électrique des fours à gaz nécessite une alimentation unique pour le moteur de circulation et le circuit de commande.

  • Page 21: Electrical Connections (Electric 208-240 Volt)

    Electrical Connections (Electric 208-240 Volt) Copyright 2016-2019 LBC Bakery Equipment Inc. Marysville WA USA P a g e | 21...

  • Page 22: Electrical Connections (480 Volt Electric )

    Electrical Connections (480 Volt Electric ) For US only For Canada only Copyright 2016-2019 LBC Bakery Equipment Inc. Marysville WA USA P a g e | 22...

  • Page 23: Gas Connection (English)

    Gas Connection (English) LRO-1G5 and LRO-2G5 ovens can operate on Natural Gas or Propane Gas. Refer to the data plate for the type of gas to which the oven is configured. Gas supply pressure should be within the following pressures: •...

  • Page 24: Connexion Au Gaz (François)

    Connexion au gaz (François) Les fours LRO-1G5 et LRO-2G5 peuvent fonctionner au gaz naturel ou au gaz propane. Reportez-vous à la plaque signalétique pour le type de gaz sur lequel le four est configuré. La pression d'alimentation en gaz doit être sous les pressions suivantes: •...

  • Page 25: Conexión De Gas (Español)

    Conexión de gas (Español) Los hornos LRO-1G5 y LRO-2G5 pueden operar con Gas Natural o Gas Propano. Consulte la placa de datos para conocer el tipo de gas al que está configurado el horno. La presión del suministro de gas debe estar dentro de las siguientes presiones: •...

  • Page 26: Lro Start-Up Form

    LRO START-UP FORM: This form MUST BE SIGNED & RETURNED to LBC via Email to service@lbcbakery.com or FAX 425-642-8310, in order for the Customers Warranty to take effect. LRO Rack Oven Inspection Procedure Specifics Serial Number __________________________________________________ Model Number __________________________________________________ Location Name __________________________________________________ Address...
  • Page 27 Burner test: Set to 125 Deg F. Number of tries to light? _____________ Supply side gas pressure when burner is running? _____________ Set to 300 F. Minutes to go from 150 to 250 F? _____________ Combustion Test: Set to 350, Fire one minute: Check Carbon Monoxide for 1 minute.

  • Page 28: Air Shutter Settings Lro-1

    Air Shutter Settings LRO-1 Use the spacing tool to measure the shutter Use the angle tool to confirm shutter angle as gap as shown. shown. Utilisez l'outil d'espacement pour mesurer Utilisez l'outil d'angle pour confirmer l'angle l'écart d'obturation comme indiqué. d'obturation comme indiqué.

  • Page 29: Air Shutter Settings Lro-2

    Air Shutter Settings LRO-2 Use the spacing tool to measure the shutter Use the angle tool to confirm shutter angle as gap as shown. shown. Utilisez l'outil d'espacement pour mesurer Utilisez l'outil d'angle pour confirmer l'angle l'écart d'obturation comme indiqué. d'obturation comme indiqué.

  • Page 30: Illustrated Parts List / Liste Illustrée Des Pièces / Ilustrado Lista De Piezas

    Illustrated Parts List / Liste illustrée des pièces / Ilustrado Lista de Piezas Not Shown/ Pas montré / No mostrada Water Assembly/ Assemblée de l'eau / Asamblea de agua Gas Inlet/ Entrée de gaz / Entrada de Gas Loading Door Hinges/ Charnières de porte de chargement / Bisagras para puertas de carga...
  • Page 31 Door with Digital Control / Porte avec contrôle numérique / Puerta con control digital Parts Item Description LRO-1__ LRO-2__ 60301-151-D 60301-151-D Overlay (-70) 40102-70 40102-70 Control 70301-04 70301-03 Handle Copyright 2016-2019 LBC Bakery Equipment Inc. Marysville WA USA P a g e | 31...
  • Page 32 Touch Screen Control with Android ™ / Contrôle d'écran tactile avec Android ™/ Control de pantalla táctil con Android ™ Item Parts - LRO Description 150-1415 Mounting Bracket 150-1416 Control Surround 150-1417 Back-up Control Assembly 150-225-4 Rear Cover 40102-100-3 Control Tablet 40102-100-1 I/O Board 41100-33...
  • Page 33 -70 Digital Control / contrôle numérique / control digital Item Parts - LRO Description 40102-70 Circuit Board, Digital 60301-175 Overlay LRO -70 150-1221 Panel, Control Mount 41100-42 Thermocouple, LRO/LMO/Pizza 150-1416 Surround, Control 150-1417 Assy, Back Up Control 150-225-4 Control, Rear Cover -54 Digital Control / Contrôle numérique / Control digital...
  • Page 34 Blower Assembly / Ensemble Soufflante / Parts Item Description Conjunto del Soplador LRO-1__ LRO-2__ 30200-59 30200-59 Motor, 3-Phase 30200-59-1 30200-59-1 Motor, 1-Phase 71500-14 71500-14 Heat Slinger 150-367 150-367 Motor Mount 150-368 150-368 Shaft Seal, Bushing 71500-13 71500-15 Blower Wheel 71500-03 71500-05a Inlet Ring 150-1381...
  • Page 35 Parts Item Description LRO-1__ LRO-2__ 150-138 150-138 Clip, Teflon 150-137 150-137 Clip, SS 30301-02 30301-02 Microswitch 30308-05 30308-05 Air Switch 70104-01 70104-01 Hose 71700-03 71700-03 Hose Clamp 50803-004 50803-004 Lifter Pin 150-130-1 150-130-1 Bracket 150-179-2 150-179-2 Switch Bracket 150-720 160-720 Lift Rotation Base 150-719-2 150-719-2...
  • Page 36 Florescent Light / Lumière fluorescente Luz fluorescente Item Parts - LRO Description 31600-13 Bulb, 4’ Florescent 31602-07-A Florescent Lamp Fixture 71301-20 Window, Light Rack Oven 150-1397 Fan Assembly Copyright 2016-2019 LBC Bakery Equipment Inc. Marysville WA USA P a g e | 36...
  • Page 37 Item Description Parts - LRO 150-1226 Lid, Vent 70403-04-1 Solenoid Act. 150-1259 Solenoid Mount 150-1260 Vent Shuttle 150-1275 Hinge, Lid Chamber Vent / Vent Chambre / Cámara de Ventilación Parts Item Description LRO-1__ LRO-2__ 160-1355 160-1355 Exhaust Duct 30200-87 30200-87 Draft Blower 150-1356 160-1356...
  • Page 38 Hood / Capuchon / Cubierta Standard Hood Parts Item Description LRO-1__ LRO-2__ 150-780C 160-780C Hood Assembly 150-1222 150-1222 Hood End Cover 150-1457 160-1221 Hood Face 150-1206-5 160-1206-5 Louver Hood 160-1218b 160-1218b Filter Box Assembly 72606-11 72606-11 Grease Filter 150-1451-1 160-1451-1 Body Vent Cover 150-1451-2 160-1451-1...
  • Page 39 Loading Door / Porte de chargement/ Puerta de carga Parts Item Description LRO-1__ LRO-2__ 150-1323 150-1323 Escape Handle 72609-18 72609-181 Floor Sweep Assembly 160-1312 160-705B-30 Front Window Assembly 71301-29 71301-25 Glass for item 3 71301-26 71301-24C Glass, Main Door 50800-103 50800-103 Latch 150-1307E...
  • Page 40 Door Hinges / Chargement Charnières / Cargando Bisagras All LRO Ovens Item Parts Description 70601-25-3 Washer, Spacer 150-786 Female Hinge Bottom 150-787 Male Hinge Bottom Female Hinge, Top 150-786-1 150-787-1 Male Hinge, Top Screws M6 x 8 Flat Head SS Internal Hex Drive Copyright 2016-2019 LBC Bakery Equipment Inc.
  • Page 41 Electrical Box / Compartiment Électrique / Compartimiento Eeléctrical All LRO Ovens Item Parts Description 31800-12 15A Circuit Breaker, 3 Pole 31800-13 15A Circuit Breaker 73601-04 Mount for item 4 30707-06 Over-limit 30701-05 Relay 30707-03 Overload Relay (208-240 blower Motor) 30707-02 Overload Relay (480V Blower Motor) 30707-05 Overload Relay (1-ph Blower Motor)
  • Page 42 Burner Assembly / Assemblage du Brûleur / Unidad del Quemador Parts Item Description LRO-1G__ LRO-2G__ Manifold with Orifices 150-1334 160-1334 80400-45 80400-45 Gas Orifices * 80400-52 80400-55 80300-18 80300-18 Gas Module 80505-14 80505-14 Gas Valve 80302-12 80302-12 Hot Surface Ignitor 150-1332 160-1332 Complete Burner...
  • Page 43 Element Assembly / Assemblage d'élément chauffant/ Conjunto de elementos de calefacción Parts Item Description LRO-1E_ LRO-2E 11091-07 11091-07 Heating Element, 240 Volt, 4333 W 150-1331-26 160-1331-26 Clamp, Heating Element 150-1331-28 160-1331-28 Side Channel, Air Panel 150-1331-27 160-1331-27 Element Support 150-1331-29 160-1331-29 Air Panel 160-1331-30...
  • Page 44 Electric Oven Components / Composants de four électrique / Componentes eléctricos del horno Parts Description Item Connector Box LRO-1E_ LRO-2E 150-1454-1 150-1454-1 Body, Connection Box 160-1454-2 160-1454-2 Conduit Adaptor Plate 30500-07 30500-07-1 Terminal Block 31200-08 31200-08 Ground Lug, two position 30500-03 30500-03 Terminal Strip, 6 Position...

  • Page 45: Schematics

    Schematics Copyright 2016-2019 LBC Bakery Equipment Inc. Marysville WA USA P a g e | 45...
  • Page 46 Copyright 2016-2019 LBC Bakery Equipment Inc. Marysville WA USA P a g e | 46...
  • Page 47 Copyright 2016-2019 LBC Bakery Equipment Inc. Marysville WA USA P a g e | 47...
  • Page 48 Copyright 2016-2019 LBC Bakery Equipment Inc. Marysville WA USA P a g e | 48...
  • Page 49 Copyright 2016-2019 LBC Bakery Equipment Inc. Marysville WA USA P a g e | 49...
  • Page 50 Copyright 2016-2019 LBC Bakery Equipment Inc. Marysville WA USA P a g e | 50...

  • Page 51: Limited Warranty

    Limited Warranty LBC Bakery Equipment (“LBC Equipment”) has been skillfully manufactured, carefully inspected and packaged to meet rigid standards of excellence. LBC Bakery Equipment, Inc. (LBC) warrants products produced and sold by LBC and its duly authorized agents, against defects in materials and workmanship within the following limitations: What is Provided: Conditions (cont): •...
