- Page 1 KL-3WT Media Station Quick Installation Guide ENGLISH AREC Inc.© All Rights Reserved 2019. l www.arec.com All information contained in this document is Proprietary...
- Page 2 Notice: Any changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. Hereby, AREC Inc., declares that this Media Station is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU.
- Page 3 KL-3WT Quick Installation Guide CAUTION Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. – the ventilation should not be impeded by covering the ventilation openings with items, such as newspapers,table-cloths, curtains, etc.: –...
-
Page 4: Specifications
KL-3WT Quick Installation Guide Introduction Featuring a compact and stand-alone design, AREC KL-3WT Media Station consists of diverse features and functionality, including multi-signals capturing, recording synchronously, codec, streaming online, live broadcasting, and web-based monitor page, providing complete presentation or lecture capture solution. -
Page 5: Product Appearance
KL-3WT Quick Installation Guide Product Appearance Top View Back View 9 10 Name Brief introduction 10.1” LCD Display Preview mixed recording Record function keys Control the Record, Pause, Stop function Power Power on/off the device Front USB port 1.For external USB storage device* 2.Firmware update through USB disk... - Page 6 KL-3WT Quick Installation Guide Connection AREC Wireless AREC Wireless Setting PC Full HD Camera Full HD Camera AREC Wireless Microphone projector Video output VGA / HDMI AREC Speaker Network Camera Audio output Power RS-232 Line audio input Mic audio input...
- Page 7 KL-3WT Quick Installation Guide Accessing the Administrator pages Connect PC to the setting port of Media Station with standard network cable.Open up the browser, and input 192.168.11.254 in the broswer page. Log in Administrator with username admin and password admin, then entering System Administration webpages.
- Page 8 KL-3WT Quick Installation Guide Setup Step 1: Set up video input name, signal type,video source, PTZ control in [ Video inputs ] of Media I/O ]. The Capture source can be the video port [ ] and [ ] with option VGA or HDMI.
- Page 9 KL-3WT Quick Installation Guide Step 2: Set up audio volume in [ Audio ] of [ Media I/O Step 3: Set up date and time of host machine in [ System settings ] of [ System Getting start a recording...
- Page 10 KL-3WT Quick Installation Guide Start a recording via the Online director Entering the Online director webpage via [System Administration] by clicking the [ ] button and opening a new tab; or log in Online director from the initial login page with default username director and password director.
- Page 11 KL-3WT Quick Installation Guide CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS Important Security Policy Precautions 1.Please open the product package carefully; we commend you keep this packaging for future transport, storage or maintenance use.
- Page 12 AREC Inc.© All Rights Reserved 2019. l www.arec.com All information contained in this document is Proprietary Made in Taiwan Date : 2019.4.1 Version : 2.6...
