Summary of Contents for Encore ENUTV-ADDT
- Page 1 ENUTV-ADDT USB Hybrid DVB-T / Analog TV Tuner Adapter (USB 2.0 / 1.1 PnP TV Capture Box) Users Guide...
- Page 2 ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY US. WE ASSUME NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT. Copyright© 2008 Encore Electronics Inc. All Rights Reserved.
-
Page 3: Table Of Contents
Chapter 1: Introduction ... 4 1.1 Package Contents ... 4 1.2 System Requirements... 4 Chapter 2: Getting Started ... 5 2.1 Connecting the ENUTV-ADDT... 5 2.2 Device Driver Installation... 5 2.3 Install the TotalMedia™ software... 7 2.4 Setting the TotalMedia™ software..9 2.4.1 Setting up Analog TV system ... -
Page 4: Chapter 1: Introduction
Chapter 1: Introduction 1.1 Package Contents ENUTV-ADDT Setup Disc Quick Installation Guide USB cable Portable Antenna PAL to NTSC connector Remote control (batteries included) 1.2 System Requirements IBM PC or compatible Intel Pentium 4 2.0GB MHz / One available USB 2.0 port. -
Page 5: Chapter 2: Getting Started
To install the ENUTV-ADDT into your computer, follow the steps below: 2.2 Device Driver Installation Place the Setup Disc that came with the ENUTV-ADDT in the CD-ROM drive, then follow the on-screen installation guide steps below. 1. Connect the TV antenna cable to the connector. - Page 6 Click “Install” button to continue. Click “Finish” button to restart your PC. Connect the ENUTV-ADDT TV Tuner to PC USB Port. Connect the ENUTV-ADDT TV Tuner to the PC USB port, then the system will detect new driver “UAD TV Box”.
-
Page 7: Install The Totalmedia™ Software
2.3 Install the TotalMedia™ software. 1. From the installation menu screen click the “Setup Utility” button. 2. Click “Next” button to continue. 3. Click “Yes” button to continue. - Page 8 4. Click “Next” button or choose setup folder for installation. 5. Click “Next” button. 6. Click “Finish” button to exit.
-
Page 9: Setting The Totalmedia™ Software
2.4 Setting up the TotalMedia™ software. 2.4.1 Setup to Analog TV System 1. Click the TotalMedia™ shortcut or click to select TotalMedia™ from the Start/Programs. 2. Use the remote control or mouse to select the “TV” function. 3. Click “Next” button to continue. 4. - Page 10 6. Select audio device and click “Next” button. 7. Find your TV service then select the TV signal and click “Next” button. (Your selection should be between Cable TV or Antenna TV only for your Analog TV viewing) 8. Click “Start” button to scan analog TV channels automatically.
-
Page 11: Setting Up Digital (Dvb-T) Tv System
2.4.2 Setting up the Digital (DVB-T) TV system 11. Click “Finish” button. 12. Watch and enjoy your high quality digital 1. Use the remote control or mouse to select the “TV” function. 2. Click the “Next” button to continue. 3. Select your region then click the “Next” button again. - Page 12 Notes: Set up two tuners. After setting up one tuner, if there is another tuner in your PC, you can repeat the steps for the second tuner. 4. Select “Trident USB DTV Tuner” and click “Next” 5. Click “Start” button to scan digital TV channels automatically.
-
Page 13: Chapter 3: Using The Totalmedia
Chapter 3: Using the TotalMedia™ 3.1 FLOATING TOOLBAR The floating toolbar appears for a few seconds whenever you move the mouse: The "Home" button (house icon) when clicked will take you to the program's startup screen. The arrow will take you to the previous screen. The toolbar at the bottom of the screen features standard audio/video playback controls (Play/Pause, Stop, Record,) plus Volume and Channel controls. -
Page 14: Tv Module
3.2 TV MODULE This section lets you view and edit the settings for TV recording. You may pause and rewind TV (while you’re watching) using both the remote control and the toolbar. Options include: Full Screen - Displays the video over the entire program display area-typically the entire screen. -
Page 15: Epg
Settings - View and edit the settings for the TV module. 3.3 EPG This section lets you view the channel program lists. If you are using a digital TV system, please select to access EPG or network EPG to view the program lists. -
Page 16: Recorded Tv
3.5 RECORDED TV This section displays your recorded TV shows. When you play back recorded TV, you can fast forward or rewind using either the controls on your remote control, keyboard, or on the floating toolbar. You can click the button next to the preview window to play it in Full Screen mode. -
Page 17: Schedule
Check the video files you want to burn to a disc. Click again to deselect (uncheck) a video file. To trim a video clip, or to choose the frame be used as the chapter button thumbnail, click the scissors icon to the right of the file name. Click the disc settings button, to select the proper disc drive, change video format and modify other disc options. -
Page 18: Teletext
History - Display a history of your recorded TV shows. The selected recorded program can be shown in the preview area. Click the Delete (trash can) icon to delete a file. Click the "Clear All" button to discard all the files. The "Frequency"... -
Page 19: Chapter 4: Using The Remote Control
Chapter 5: Technical Support: For toll free 24/7 Technical Support or Installation Hotline contact information please visit our web site at http://www.encore-usa.com Note: Toll free calls are within the 50 states of the United States only. Our international toll call (fee based) phone number, 24/7 technical support and installation hotline is also available. - Page 20 2007/06/28 Version 0.91...
