- Page 1 802.11g/b Wireless Print Server with 2-USB2.0 and 1-Parallel Port Quick Installation Guide V1.2...
-
Page 2: Before You Start, You Should Prepare The Following Items
Before you start, you should prepare the following items: Windows-based computer with print server setup CD Printer Printer cable One 802.11b/g Access Point (optional) Wired Network with Print Server: Print Server Printer Wireless Network with Print Server: Infrastructure mode (Access Point): Print Server Printer Laptop... -
Page 3: Hardware Installation
Ad-Hoc mode (Peer to Peer): Hardware Installation: Turn off the printer’s power. Connect the print server to your printer with the supplied printer cable. Turn the printer’s power on. Plug the AC power adapter into the power connector on the print server. Wait 10 seconds as part of the print server’s Power On Self Test (POST). - Page 4 Click Next, the wizard will automatically discover the print server. From the Select A Print Server screen, select the print server port that you want to...
-
Page 5: Rear Panel
configure and click Next. Note: Rear Panel USB1 USB2 PARALLEL PARALLEL is Port 1(PID1) USB1 is Port 2(PID2) USB2 is Port 3(PID3) - Page 6 On the Change Settings screen, select No or Yes: Click No if you want the print server to keep using the default IP address and keep the default Infrastructure settings: Infrastructure mode SSID: <ANY> Encryption: none DHCP client: Off IP address: 192.168.0.10 Subnet Mask: 255.255.255.0 Click Yes if you want change wireless settings or assign a static IP address to the print server:...
- Page 7 Enter the proper SSID of your wireless network. Channel: optional Data Transmit Rates: select Auto or others Transmit Mode: select Auto or others On the Wireless Security screen, enable or disable WEP/WPA encryption, configure according to your wireless network and click Next. On the TCP/IP Settings screen, specify a fixed or dynamic IP address for the print server, a fixed IP address is highly recommended.
- Page 8 Click Add New Printer to launch Windows Add Printer Wizard. Click Next and select Local Printer, make sure the Automatically detect and install my Plug and Play printer check box is NOT checked. Then click Next.
- Page 9 10. Make sure the Use the following port radio-button is clicked and select LPT1: (Recommended Printer Port) from the pull-down list. Then click Next. 11. Select Manufacturer and Printer from the lists of printer’s driver. Then click Next.
- Page 10 12. If you already have the printer’s driver installed, you will be asked whether to keep it or to replace it. Click Next. Supply a name for the printer and choose whether you want to make it your default printer. Then click Next. 13.
- Page 11 15. From Windows system, go to start -> Printers and Faxes and highlight your newly installed printer. 16. Right-click, select Properties -> Ports and verify that the print server’s port appears.
- Page 12 17. Go to General; click Print Test Page to verify the configuration. 18. Done. Note: If you wish to install more print servers, start setup wizard from your Windows Start menu: start -> All Programs -> Network Print Server -> PSWzard and repeat the installation procedure.
