Model Numbers:
ENF656-USB-MOTO
Specifications:
Data Transfer Rates
Data Mode
Data Compression
Error Correction
Fax Mode
Media Connector
Interface
Power Consumption
Dimensions (app.)
Net Weight (app.)
Operating Temperature
Humidity
Storage Temperature
Supported OS
Regulations
V.92/56K USB Modem
1
Up to 56 Kbps download and 48
Kbps upload
ITU-T V.92, V.90, V.34, V.32 bis,
and fallbacks
ITU-T V.44, V.42, V.42 bis / MNP
class 5
ITU-T V.42 / MNP 2-4
Up to 14.4 Kbps send and receive
ITU-T V.17, V.29, V.27 ter, V.21
Channel 2, ITU-T T.31 class 1
RJ-11 x 1, USB x 1
USB Type-A connector
0.1W max.
76mm (length) x 31mm (width) x
20mm (height)
50g
0°C ~ 70°C
5 % ~ 95 % (non-condensing)
-20°C ~ 70°C
Windows® 98SE, ME, 2000, XP
32/64bit, Windows Vista™ 32/64bit
WHQL certificated
FCC part 15, part 68, CE, CTR21
Advertisement
Table of Contents
Related Manuals for Encore ENF656-USB-MOTO
Summary of Contents for Encore ENF656-USB-MOTO
- Page 1 V.92/56K USB Modem Model Numbers: ENF656-USB-MOTO Specifications: Data Transfer Rates Data Mode Data Compression Error Correction Fax Mode Media Connector Interface Power Consumption Dimensions (app.) Net Weight (app.) Operating Temperature Humidity Storage Temperature Supported OS Regulations Up to 56 Kbps download and 48 Kbps upload ITU-T V.92, V.90, V.34, V.32 bis,...
- Page 2 Features: USB specifications v1.1/2.0 compliant USB bus powered design. Needs no additional power adapter Plug and play compatible for easy installation and configuration Data transfer rate up to 56 Kbps download and up to 48 Kbps upload Supports video conferencing Friendly GUI configuration and management software Supports fax function with transfer rate up to 14.4 Kbps Supports telephone answering machine (TAM) function and telephony...
