Pure Fun 9003MTH Product Manual page 9

ASSEMBLY INSTRUCTIONS
5
4
MODEL# 9003MTH
3
5
4
5
5
4
STEP 3:
Parts:
Part 2 (x1) - Frame Pad
L
ocate the frame pad (2) and attach it to the
frame like diagram shown. With the leg
screws of the Mat facing up, insert the
Frame Pad so all 6 openings meet the leg
screws and the Frame Pad is installed
properly.
Note: Some models may not have holes for
all legs on the frame pad. If they do not, just
attach the frame pad securely around the
frame with at least 2 holes where handlebar
will go.
STEP 4:
5
Parts:
Part 3 (x6) - Leg
4 Screw on all Legs (3) into their respective
places on the frame. You will have 6 total
5
legs once complete.
4
4
9
