Owner's Manual &
Safety Instructions
20i
Model
HE77
10" COMPACT JOBSITE TABLE SAW
RACK & PINION FENCE
WITH
WARNING: To prevent serious injury, user must read and
understand Owner's Manual. SAVE THIS MANUAL.
When unpacking, make sure that the product is intact and
undamaged. If any parts are missing or broken, please call
1-888-866-5797 as soon as possible. Reference 57673
Advertisement
Table of Contents
Related Manuals for Hercules HE77
Summary of Contents for Hercules HE77
- Page 1 Owner’s Manual & Safety Instructions Model HE77 10″ COMPACT JOBSITE TABLE SAW RACK & PINION FENCE WITH WARNING: To prevent serious injury, user must read and understand Owner’s Manual. SAVE THIS MANUAL. When unpacking, make sure that the product is intact and undamaged.
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION 3. Personal safety a. Stay alert, watch what you are doing and Read all safety warnings and all instructions. use common sense when operating a Failure to follow the warnings and instructions may result power tool. Do not use a power tool while in electric shock, fire and/or serious injury. - Page 3 m. People with pacemakers should consult their h. Keep handles and grasping surfaces physician(s) before use. Electromagnetic fields in dry, clean and free from oil and grease. close proximity to heart pacemaker could cause Slippery handles and grasping surfaces pacemaker interference or pacemaker failure. do not allow for safe handling and control In addition, people with pacemakers should: of the tool in unexpected situations.
- Page 4 f. Do not reach behind the fence with either o. Always use a clamp or a fixture designed hand closer than 100 mm from either to properly support round material such as side of the saw blade, to remove wood rods or tubing.
- Page 5 f. For the Riving Knife and anti-kickback h. Never reach around or over a rotating saw device to work, they must be engaged in the blade. Reaching for a workpiece may lead to workpiece. The Riving Knife and anti-kickback accidental contact with the moving saw blade. device are ineffective when cutting workpieces i.
-
Page 6: Grounded Tools: Tools With Three Prong Plugs
f. Use extra caution when making a g. Always use saw blades with correct size cut into blind areas of assembled and shape (diamond versus round) of workpieces. The protruding saw blade may arbor holes. Saw blades that do not match cut objects that can cause kickback. -
Page 7: Double Insulated Tools: Tools With Two Prong Plugs
3. The tool must be plugged into an appropriate outlet, TABLE A: RECOMMENDED MINIMUM WIRE properly installed and grounded in accordance with GAUGE FOR EXTENSION CORDS* (120/240 VOLT) all codes and ordinances. The plug and outlet should EXTENSION CORD NAMEPLATE look like those in the preceding illustration. -
Page 8: Setup - Before Use
SETUP - BEFORE USE TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION: Turn the Power Switch of the tool off and unplug the tool from its electrical outlet before performing any procedure in this section. Note: For additional information regarding the parts listed in the following pages, refer to the Assembly Diagram near the end of this manual. - Page 9 Assembly Removing the Table Insert Mounting Table Saw 1. Lower the blade by turning the Height Adjustment Knob counter-clockwise. 1. Select a workbench or mounting location that is able to support the weight of the Table Saw, plus any additional weight placed on it during use. 2.
-
Page 10: Adjusting Riving Knife
Adjusting Riving Knife Removing and Installing the Blade Note: Riving Knife has three mounting holes for three NOTICE: To work properly, the saw blade teeth positions. The uppermost position is for all through must point down toward the front of the saw. Failure cuts. -
Page 11: Installing The Blade Guard
WARNING! TO PREVENT SERIOUS INJURY: When WARNING! TO PREVENT SERIOUS INJURY: Use installing the saw blade, make sure that the saw extra caution when cutting wood with slippery surface blade teeth point down at the front side of blade. as the anti-kickback pawls may not always be effective. 6. -
Page 12: Operation
Installing the Miter Gauge OPERATION Note: The Miter Gauge can be installed in either Read the ENTIRE IMPORTANT miter gauge groove on either side of blade. SAFETY INFORMATION section at the Slide the Miter Gauge into one of the guide grooves. beginning of this manual including all text under subheadings therein Miter Gauge... -
Page 13: Rip Fence Operation
2. For work on a narrow workpiece, secure Extension Table to Rip Fence in the higher position. See below. Rip Fence High Bevel Lock Handle Position Height / Bevel Adjustment Handwheel 5. Make sure blade is at desired angle. Tighten Bevel Lock Handle clockwise. Extension Table Rip Fence Operation... -
Page 14: Workpiece And Work Area Set Up
3. When ripping, always use the Rip Fence. This improves the accuracy of the cut, and reduces the chance for saw blade binding. Crosscuts/Miter Cuts Blade Guard Saw Blade Scrap Wood Cut Line Lock Knob Miter Gauge Miter Clamp Gauge 3. -
Page 15: Maintenance And Servicing
Cleaning, Maintenance, MAINTENANCE AND SERVICING and Lubrication Procedures not specifically explained 1. BEFORE EACH USE, inspect the general in this manual must be performed condition of the tool. Check for: only by a qualified technician. • loose hardware • misalignment or binding of moving parts •... -
Page 16: Parts List And Diagram
PARTS LIST AND DIAGRAM Parts List Part Description Part Description Cross Head Tapping Screw Bracket Emergency Stop Panel Hex Thin Nut Out Flange Screw Saw Blade Handle Bolt Flat Washer Eccentric Handle Wheel Cam Plate Locknut Riving Knife Pan Head Screw Spring Bevel Scale Label Saddle Shape Washer... - Page 17 Parts List (cont’d) Part Description Part Description Ring Fence Clip A Knob Side Fence Flat Washer Miter Gauge Lock Handle HS Bolt Miter Gauge Fix Rail A Lock A Friction Rule A Pointer Fixed Seat Sliding Bar Sliding Plate Front Rail Cross Head Screw Pointer Carry Handle...
-
Page 18: Assembly Diagram
Assembly Diagram 130- 8 21-1 2 137- 1 136- 1 133- 1 131- 1 116- 5 130- 1 129- 1 120- 4 121- 2 37-1 4 37-1 3 21-2 4 116- 6 128- 1 122- 2 120- 3 122- 1 121- 1 134- 1 136- 2... -
Page 19: Limited 90-Day Warranty
LIMITED 90 DAY WARRANTY Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase. - Page 20 Visit our website at: http://www.harborfreight.com Email our technical support at: productsupport@harborfreight.com For technical questions, please call 1-888-866-5797 © ® Copyright 2020 by Harbor Freight Tools . All rights reserved. No portion of this manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools.
