Steinbach 061205 Original Owner's Manual

Poolrunner battery basic
Hide thumbs Also See for 061205:
Table of Contents

Advertisement

Quick Links

Download this manual
Originalbetriebsanleitung / Original owner's manual / Notice originale / Istruzioni originali / Manual original / Původní
návod k používání / Eredeti használati utasítás / Izvirna navodila / Pôvodný návod na použitie / Instrukcja oryginalna /
Instrucțiuni originale / Originalne upute / Оригинална инструкция / Orijinal kullanım talimatları
Schwimmbadreiniger
Poolrunner Battery Basic
Schwimmbadreiniger......................................... 4
de
Nettoyeur de piscine........................................49
fr
Limpiafondos de piscina.................................. 95
es
Úszómedence tisztító..................................... 140
hu
Čistič bazénu.................................................. 185
sk
Dispozitiv de curățare a piscinei.................. 230
ro
Уред за почистване на басейни................ 275
bg
Pool cleaner......................................................27
en
Pulitore per piscina...........................................72
it
Čistič bazénů................................................... 1 18
cs
Čistilnik bazena..............................................163
sl
Odkurzacz basenowy...................................207
pl
Čistač bazena................................................253
hr
Yüzme havuzu temizleyicisi.......................... 298
tr

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 061205 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Steinbach 061205

Summary of Contents for Steinbach 061205

  • Page 1 Originalbetriebsanleitung / Original owner's manual / Notice originale / Istruzioni originali / Manual original / Původní návod k používání / Eredeti használati utasítás / Izvirna navodila / Pôvodný návod na použitie / Instrukcja oryginalna / Instrucțiuni originale / Originalne upute / Оригинална инструкция / Orijinal kullanım talimatları Schwimmbadreiniger Poolrunner Battery Basic Schwimmbadreiniger.........
  • Page 3 Lieferumfang/Geräteteile Oberteil Wasserauslassdüse Filtereinheit Unterteil Schmutzklappe Segel Verschlussclip Schwimmgriff inkl. Nylonschnur Schalter ON/OFF Haken Ladebuchse Ladegerät Reinigungslippe Betriebsanleitung (ohne Abbildung) Griff...

  • Page 4: Package Contents/Components

    Package contents/components Top part Water discharge nozzle Filter unit Wheel Bottom part Dirt slot Sail Clip Floating handle incl. nylon cord ON/OFF switch Hook Charging socket Charger Cleaning strip Operating instructions (without Handle illustration)

  • Page 5: Table Of Contents

    Contents Overview........................2 Package contents/components..................26 General Information....................28 Explanation of Symbols....................28 Safety.......................... 29 Unpacking and checking the package contents............33 Description........................33 Description of the pool cleaner..................33 Basic settings.......................34 Charging the rechargeable battery................34 Attaching the floating handle..................34 Attaching the sail......................

  • Page 6: General Information

    General Information Read and keep the operating instructions These operating instructions are part of the Pool Runner Battery Basic pool cleaner (in the following also called "device"). It contains important information about startup and operation. Read the operating instructions and especially the safety instructions carefully before using the device.

  • Page 7: Safety

    Lithium ion batteries in equipment or lithium ion batteries packaged with equipment. UN 3481 Weight of the packaging unit. Dimensions of the packaging unit. Only use the charger indoors This symbol identifies devices that belong to the protection class II. Safety The following signal words are used in this user manual.
  • Page 8 - Only connect the power cable to an easily accessible socket so that you can quickly disconnect it in the case of a fault. - Only connect the power cable to a grounded socket. - Only operate the device on a grounded socket secured with at least 16A.
  • Page 9 - Only use spare parts and accessory parts supplied or recommended by the manufacturer. All warranty claims will be void when using third-party components. - Do not operate the device with an external timer or a separate remote system. NOTICE! - Never let the device run outside of the water as this can cause damage even after a short time.
  • Page 10 WARNING! Risk of injury through insufficient qualification! Insufficient experience or skills for handling the required tools and insufficient knowledge of regional or normative regulations for the required work can lead to severe injuries or material damage. - Assign all work whose risks you cannot estimate due to insufficient personal experience to a qualified expert.

  • Page 11: Unpacking And Checking The Package Contents

    Unpacking and checking the package contents NOTICE! Careless opening of the packaging, especially with the help of sharp or pointed objects, may cause damage to the device. - Open the packaging very carefully. - Do not penetrate the packaging with sharp or pointed objects. WARNING! Packaging materials pose a risk of suffocation! Catching your head in the packaging foil or swallowing other...

  • Page 12: Basic Settings

    The sail lets the pool cleaner turn automatically as soon as it touches the pool wall. The positions of the wheels influence the travel path of the pool cleaner. The removable filter unit filters the water and collects deposits in the pool. The optional cleaning strips can improve the cleaning result depending on the degree of soiling.

  • Page 13: Attaching The Sail

    1. Guide the end of the nylon cord of the floating handle through the eyelet on the handle 2. Shorten the nylon cord to a length that roughly corresponds to the depth of your pool and tie it in a knot. The floating handle is attached.

  • Page 14: Attaching The Cleaning Strips

    (Setting for large pools) (Setting for small pools) 1. Press the retaining lugs away from the half axle and pull off the wheel. 2. Insert in the wheel with the catch so that it snaps into place at the respective letter for the selected setting.

  • Page 15: Detaching The Cleaning Strips

    Detaching the cleaning strips 1. Pull on the frames of the cleaning strips and take them out of the bottom part The cleaning strips are detached. Operation Check the following before each use: - Is there visible damage on the device? - Is there visible damage on the control elements? - Do all individual parts function? - Are the accessories in perfect condition?
  • Page 16 Inserting the filter unit 1. Make sure that the dirt slots closed before inserting the filter unit. 2. Insert the filter unit into the bottom part in the correct position with the guide lugs pointing upwards. 3. Place the top part in the correct position on the bottom part .

  • Page 17: Switching Off The Device

    1. Hold the device by the handle and lower it slowly into the water until all the air has escaped. The device should run at a right angle to the pool wall. 2. Press the ON/OFF switch on the bottom until it snaps into place. The device beeps if it is switched on outside of the water.

  • Page 18: Cleaning

    Lifting the device out of the pool NOTICE! The pump of the device can be damaged if it is switched on or off outside of the water. - Only switch the device on or off when it is located below the water surface.

  • Page 19: Storage

    1. Open all clips 2. Take the top part off. 3. Remove the filter unit 4. Thoroughly rinse the filter unit with plain tap water. 5. Rinse the device after each use with plain tap water inside and out. The device is clean. Storage 1.

  • Page 20: Troubleshooting

    Troubleshooting Fault description Cause Remedy The device cannot be switched The rechargeable battery is Charge the rechargeable drained. battery. The rechargeable battery is Contact customer service. defective. It takes about 15 seconds after Wait approximately 15 seconds the ON/OFF switch is pressed until the device starts.
  • Page 21 Fault description Cause Remedy The rechargeable battery The water circulation of the Switch off the filter system of runtime is shorter than pool is switched on. the pool. expected. The water temperature is too Only use the device under the low.

  • Page 22: Technical Data

    Technical data Model 061205 Type of rechargeable battery Lithium ion Rechargeable battery capacity 2600 mAh Charging time 3 to 4 hours Battery runtime up to 60 min Safety class IPX8 Ambient temperature 10 °C to 40 °C Operating temperature (water) 10 °C to 35 °C...

  • Page 23: Spare Parts

    Spare parts...
  • Page 24 061280 - sail 061281 - water discharge nozzle 061282 - top part 061283 - washer 061284 - screw, 3.9 x 25 061285 - motor unit 061286 - screw, 3.9 x 16 061293 - filter insert 061294 - dirt slot 061287 - bottom part 061296 - clip 061288 - cleaning strip 061289 - wheel socket...

  • Page 25: Declaration Of Conformity

    Declaration of Conformity Steinbach International GmbH hereby declares that the device meets the following directives: - 2014/35/EU (EN 60335‑1:2012+A11:2014+A13:2017; EN 60335‑2‑41:2003+A1:2004+A2:2010) - 2014/30/EU (EN 55014‑1:2017; EN 55014‑2:2015; EN 61000‑3‑2:2014; EN 61000‑3‑3:2013) You can request the complete text of the EU Declaration of Conformity from the address stated at the end of this instruction manual.
