INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could
result in serious injury, death, or property
damage.
-Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
-What to do if you smell gas:
•
Do not try to light the appliance.
•
Do not touch any electrical switch; do not use
any phone in your building.
•
Leave the building immediately.
•
Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
•
If you cannot reach your gas supplier, call the
fire department.
-Installation and service must be performed by a
qualified installer, service agency, or the gas supplier.
A barrier designed to reduce the risk of burns from the hot
viewing glass is provided with this appliance and shall be installed
for the protection of children and other at-risk individuals.
INSTALLER GUIDE
HOT GLASS WILL CAUSE
BURNS.
DO NOT TOUCH GLASS UNTIL
COOLED.
NEVER ALLOW CHILDREN TO
TOUCH GLASS.
DIRECT VENT ZERO CLEARANCE
GAS FIREPLACE HEATER MODELS:
DVLXB55BP90N-1 / DVLXB55SP90N-1
This fireplace is design certified in accordance
with American National Standard/CSA Standard
ANSI Z21.88/CSA 2.33 and by Underwriters
Laboratories as a Direct Vent Gas Fireplace
Heater and shall be installed according to these
instructions.
This appliance may be installed in an
aftermarket, permanently located,
manufactured home (USA only) or
mobile home, where not prohibited by
local codes.
This appliance is only for use with the
type of gas indicated on the rating plate.
This appliance is not convertible for use
with other gases, unless a certified kit is
used.
www.nficertified.org
MH63830
We suggest that our gas hearth
products be installed and serviced
by professionals who are certified
in the U.S. by the National
Fireplace Institute (NFI) as NFI
Gas Specialists.
630537_1
