This Owner's Manual is provided and hosted by Appliance Factory Parts.
White Mountain Hearth
DVLL41FP92N-3
Owner's Manual
Shop genuine replacement parts for White Mountain
Hearth DVLL41FP92N-3
Find Your White Mountain Hearth Fireplace Parts - Select From 539 Models
-------- Manual continues below --------
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Empire Comfort Systems Boulevard CONTEMPORARY DVLL41FP92-3
Summary of Contents for Empire Comfort Systems Boulevard CONTEMPORARY DVLL41FP92-3
- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. White Mountain Hearth DVLL41FP92N-3 Owner's Manual Shop genuine replacement parts for White Mountain Hearth DVLL41FP92N-3 Find Your White Mountain Hearth Fireplace Parts - Select From 539 Models -------- Manual continues below --------...
- Page 2 INSTALLATION INSTRUCTIONS OWNER’S MANUAL INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference. LUXURY DIRECT VENT ZERO CLEARANCE WARNING: If not installed, operated and maintained in accordance with the manufacturer’s instructions, GAS FIREPLACE HEATER this product could expose you to substances in fuel or from fuel combustion which can cause death or CONTEMPORARY serious illness.
-
Page 3: Table Of Contents
TABLE OF CONTENTS SECTION PAGE IMPORTANT SAFETY INFORMATION ..................3 SAFETY INFORMATION FOR USERS OF LP GAS ..............4 REQUIREMENTS FOR MASSACHUSETTS ................5 INTRODUCTION ........................... 6 SPECIFICATIONS ......................... 7 FIREPLACE DIMENSIONS ......................7 CLEARANCES ..........................8 LOCATING FIREPLACE ........................ 9 GAS SUPPLY .......................... -
Page 4: Important Safety Information
IMPORTANT SAFETY INFORMATION Before enclosing the vent pipe assembly, operate the appliance to ensure it is venting properly. DO NOT OPERATE THIS APPLIANCE WITHOUT GLASS FRONT PANEL INSTALLED • If this appliance is installed directly on carpeting, • Under no circumstances should any solid fuels tile or other combustible material other than wood (wood, coal, paper or cardboard etc.) be used in this flooring the appliance shall be installed on a metal... -
Page 5: Safety Information For Users Of Lp Gas
SAFETY INFORMATION FOR USERS OF LP GAS Propane (LP-Gas) is a flammable gas which can cause fires with the members of your household. Someday when there and explosions. In its natural state, propane is odorless and may not be a minute to lose, everyone’s safety will depend colorless. -
Page 6: Requirements For Massachusetts
REQUIREMENTS FOR MASSACHUSETTS For all side wall horizontally vented gas fueled equipment installed 3. SIGNAGE. A metal or plastic identification plate shall be in every dwelling, building or structure used in whole or in part for permanently mounted to the exterior of the building at a residential purposes, including those owned or operated by the minimum height of eight (8) feet above grade directly in line Commonwealth and where the side wall exhaust vent termination with the exhaust vent terminal for the horizontally vented is less than seven (7) feet above finished grade in the area of gas fueled heating appliance or equipment. The sign shall the venting, including but not limited to decks and porches, the... -
Page 7: Introduction
INTRODUCTION Instructions to Installer High Altitude 1. Installer must leave instruction manual with owner after When installing this unit at an elevation above 2000 feet (in the installation. United States) it may be necessary to decrease the input rating by 2. Installer must have owner fill out and mail warranty card supplied changing the existing burner orifice to a smaller size. Generally, with the fireplace. -
Page 8: Specifications
SPECIFICATIONS DVLL NAT DVLL LP DVTL NAT DVTL LP Input Btu/hr Maximum 34,500 31,500 34,500 31,500 Btu/hr Minimum 18,000 20,500 17,000 16,700 KWH (Maximum) 10.1 10.1 (Minimum) Orifice #32, P211 #51, P210 #32, P211 #51, P210 Min. Rate Screw Air Shutter Opening - Front 9/16 in. FULL OPEN 9/16 FULL OPEN Height without standoff 24-1/4 in. (616 mm) 24-1/4 in. (616 mm) -
Page 9: Clearances
CLEARANCES Mantel Chart Clearance to Combustibles - Shown in inches (metric) Back 1-1/4 (32mm) Side 3-1/8 (79mm) Floor 0 (0mm) Top Stand-off 12 (305mm) Top Framing Edge 12 (305mm) Minimum Height from Top of Fireplace 46-3/4 (1.17m) Opening To Ceiling 20" (508mm) 17-1/2" (444mm) 21-1/2" (546mm) 17" (431mm) 13-1/2" (343mm) 16-1/2" (419mm) 12" (305mm) 16" (406mm) 20-1/2" (521mm) 15-1/2" (394mm) 19-1/2" (495mm) 15" (381mm) 19" (482mm) 14-1/2" (368mm) 18-1/2" (469mm) 14" (356mm) Figure 2 18" (457mm) 13" (330mm) -
Page 10: Locating Fireplace
LOCATING FIREPLACE Note: Island and Room Divider installation is possible as long as the horizontal portion of the vent system does not exceed 20 feet (609.6cm) with a minimum vertical run of 8 feet (243.8cm). See details in Venting Section. See Figure 6. CABINET INSTALLATION CORNER INSTALLATION FLUSH WALL ISLAND INSTALLATION INSTALLATION ANGLED CORNER INSTALLATION ROOM DIVIDER INSTALLATION Figure 6 33598-10-0616 Page 9... -
Page 11: Gas Supply
GAS SUPPLY The gas pipeline can be brought in through the left side of the Installing a New Main Gas Cock appliance. Consult the current National Fuel Gas Code, A NSI Z223.1 Each appliance should have its own manual gas cock. CAN/CGA-B149 (.1 or .2) installation code. A manual main gas cock should be located in the vicinity of the unit. Recommended Gas Pipe Diameter Where none exists, or where its size or location is not adequate, Pipe Length Schedule 40 Pipe Tubing, Type L contact your local authorized installer for installation or relocation. -
Page 12: Special Vent Systems
SPECIAL VENT SYSTEMS The following vent systems are acceptable for use with DV(TL,LL)41FP series fireplaces: Simpson Duravent® GS 4" - 6 5/8" Selkirk Direct-Temp® 4" - 6 5/8" Security Secure Vent® 4" - 6 5/8" Empire Flexvent Kit DVVK-4F, refer to page 30. INSTALLATION Vent Pipe Clearance Note: Maintain one inch (1 in.) of clearance around vertical vent pipe. See Figure 9. For horizontal vent, maintain a minimum 1 in. clearance to the bottom, two inches to the sides of the vent, and 3 TOP OF VENT PIPE in. clearance to combustibles above the vent pipe. See Figure 10. VENT PIPE 4”... - Page 13 INSTALLATION Framing and Finishing Flush Mount Mantel Installation The fireplace must extend 3/4 in. (19mm) beyond finished NOTE: You must use the standoffs that are supplied with the wall surface when using a flush mount mantel. Refer to Figure fireplace. The standoffs are shipped in a flat-state on top 12 to locate nailing flanges on fireplace sides. Mark and drill of the fireplace.
- Page 14 INSTALLATION Framing Finishing Fireplace framing can be built before or after the fireplace is set Finish the walls with the material of your choice. Figure 4 on page 8 in place. Framing should be positioned to accommodate wall shows the minimum vertical and corresponding maximum horizontal covering and fireplace facing material. The fireplace framing dimensions of mantels or other combustible projections above the should be constructed of 2 x 4 lumber or heavier. The framing top front edge of the fireplace. Only non-combustible materials may headers may rest on the fireplace standoffs. Refer to Figure 13 be used to cover the metal fireplace face. for minimum framing dimensions. CAUTION: MEASURE FIREPLACE DIMENSIONS AND VERIFY Flush Wall Installation FRAMING METHODS, AND WALL COVERING DETAILS BEFORE FRAMING CONSTRUCTION BEGINS. HEADER: A DOUBLE HEADER OR PLACING THE HEADER VERTICALLY IS RECOMMENDED STANDOFF 12”...
-
Page 15: Venting Fireplace
VENTING FIREPLACE Vertical, 90° Elbow To Attention: Cold climate installation recommendation: Horizontal Out The Wall When installing this unit against a non-insulated exterior wall, it is recommended that the outer walls be insulated to conform to applicable insulation codes. Vent Runs In planning the installation for the fireplace, it is necessary to install certain components before the appliance is completely positioned 90°... - Page 16 VENTING FIREPLACE Maximum Horizontal Run For A Minimum Vertical Rise Corner Installation Vertical, 90° Elbow To Horizontal Out The Wall 20” (50.8 cm) MAXIMUM ► 24” (609.6mm) MINIMUM VENT ► PIPE LENGTH ▼ VENT CAP THIMBLE WALL FIRESTOP NOTE: YOU MUST USE A 2’ (609.6mm) VERTICAL VENT PIPE AS YOUR FIRST SECTION BEFORE INSTALLING THE ELBOW.
- Page 17 VENTING FIREPLACE To Use the Vent Graph EXAMPLE A: 1. Determine the height of the center of the horizontal vent pipe. If the vertical dimension from the top of the unit is 35 ft. (10.67 m), the Using this dimension on the Sidewall Vent Graph, locate the horizontal run to the outer wall flange must not exceed 5 ft (1.52 m). point it intersects with the slanted graph line. EXAMPLE B: 2. From the point of this intersection, draw a vertical line to the If the vertical dimension from the top of the unit is 5 ft. (1.52 m), the bottom of the graph. horizontal run to the outer wall flange must not exceed 11 ft. (3.35 m). 3. Select the indicated dimension, and position the unit in accordance Special Note: For each 45 degree elbow installed in the horizontal with same. run, the length of the horizontal run MUST be reduced by 18" (45cm). This does not apply if the 45 degree elbows are installed on the vertical part of the vent system. Reduce 3 ft. (91.4 cm) for every 90° elbow.
- Page 18 VENTING FIREPLACE Below Grade Installation Example Of Possible Venting System Using One 90° Elbow When it is not possible to meet the required vent terminal clearances 8 ft. (2.44 m) is listed as minimum vertical vent run with 20 ft. of 12 in. (305mm) above grade level, a snorkel kit is recommended. (6.10 m) of maximum horizontal vent run. Vertical dimensions are It allows installation depth down to 7 in. (178mm) below grade level. based on centerline to centerline of pipe. Horizontal dimensions are The 7 in. (178mm) is measured from the center of the horizontal based on centerline of pipe to exterior of wall. vent pipe as it penetrates through the wall. Ensure the sidewall venting clearances are observed. If venting system is installed below ground, we recommend a window well with adequate and proper drainage to be installed around the termination area.
- Page 19 VENTING FIREPLACE Example Of Possible Venting System Using Two (2) 90° Elbows Examples of possible venting systems using two (2) 90° elbows. V is listed as minimum vertical dimensions and H1 + H2 is listed as total of maximum horizontal dimensions. The maximum vertical and horizontal distances for two (2) 90° elbows as shown in Figure 25 is 37 ft. (11.28 m). FIRE STOP AT CEILING LEVEL SEE GRAPH (Figure 21) FOR PERMISSIBLE "H" AND "V" DIMENSION NOTE: H1 AND H2 MUST BE ADDED TOGETHER TO USE GRAPH THEN SUBTRACT 3' (91.4 cm) FOR THE SECOND 90°...
- Page 20 VENTING FIREPLACE 10” (254mm) CENTER 12” OF ELBOW (305mm) VENT CAP CENTER OF FRAMING (MINIMUM VENT) 9” (229 mm) MINIMUM TO SIDE WALL Figure 27 Figure 26 MINIMUM HOLE LOCATION DIMENSIONS FOR THROUGH THE WALL HORIZONTAL INSTALLATIONS WITH 90 DEGREE ELBOW OFF TOP OF FIREPLACE Positioning the Fireplace FIREPLACE...
-
Page 21: Examples - Top Vent Run
EXAMPLES - TOP VENT RUN 24” (61 cm) MINIMUM CLEARANCE TO COMBUSTIBLES If total horizontal needs to be 10' (3.05 m), then the minimum required vertical is 7' (2.13 m). If total horizontal needs to be 8' (2.44 m), then the minimum H=10' (90° + 90°) = 16' (equivalent horizontal) required vertical is 5' (1.52 m). H= 3.05 m (90° + 90°) = 4.88 m (equivalent horizontal) H=8' (+90°) = 11' (equivalent horizontal) From the graph the required vertical is 7' (2.13 m). H=2.44 m (+90°) = 2.44 m (equivalent horizontal) Figure 29 From the graph the required vertical is 5' (1.52 m). Figure 28 Page 20 33598-10-0616... - Page 22 EXAMPLES - TOP VENT RUN If total vertical is to be 9' (2.74 m), then the maximum allowed horizontal run can be 20' (6.10 m). H=20' H=6.10 m From the graph the allowed vertical is 20' (6.10 m). Figure 30 33598-10-0616 Page 21...
-
Page 23: Termination Clearances
TERMINATION CLEARANCES Termination clearance for buildings with combustible and noncombustible exteriors. Figure 31 Vertical Sidewall Installations Important! Minimum clearance between vent pipes and combustible materials is three (3 in.) (76mm) on top, and (1 in.) (25mm) on bottom and sides. Important! When vent termination exits through foundation less than 20 in. (508 mm) below siding outcrop, the vent pipe must extend outward so that the horizontal vent terminal is located flush to, or beyond the outcrop siding. Information on Various Venting Routes and Components Important: It is always best to locate the fireplace in such a way that minimizes the number of offsets and horizontal vent length. Since it is very important that the venting system maintain its balance between the combustion air intake and the flue gas exhaust, certain limitations as to vent configurations apply and must be strictly adhered to. The graph showing the relationship between vertical and horizontal side wall venting will help to determine the various vent lengths allowable. -
Page 24: Vent Clearances
VENT CLEARANCES AREA WHERE TERMINAL IS NOT PERMITTED VENT TERMINAL AIR SUPPLY INLET Figure 32 A = *Clearance above grade, veranda, porch, deck or balcony J = clearance to non-mechanical air supply inlet to building or [*12 inches (30cm) minimum] the combustion air inlet to any other appliance [*12 inches (30cm) minimum for appliances ≤ 100,000 Btuh (30 kW) B = clearance to window or door that may be opened [*12 inches (30cm) minimum for appliances < 100,000 Btuh (30kW) 36 inches (90cm) minimum for appliances > 100,000 Btuh (30kW)] C = clearance to permanently closed window [minimum 12 inches (30cm) recommended to prevent condensation on window] K = clearance to a mechanical air supply inlet [* 6 feet (1.8m) minimum] D = vertical clearance to ventilated soffit located above the terminal within a horizontal distance of 24 inches (60cm) from the L = †clearance above paved sidewalk or a paved driveway located center of the terminal [18 Inches (46cm) minimum... -
Page 25: Vent System Identification
VENT SYSTEM IDENTIFICATION Installing Vent Components Begin the vent system installation by installing the first Duravent component to the starting collar, 24 inch (60.10 cm) minimum straight pipe on the top of the appliance, then the remaining pipe length and the horizontal or vertical termination kit. NOTE: All outer connection joints must be sealed with aluminum tape, screws or silicone sealant rated above 300°F/149°C. The inner flue joints do not require any sealant. Duravent vent system components lock into place by sliding the concentric pipe section with four (4) equally spaced interior beads onto the appliance collar or previously installed component end with four (4) equally spaced indented sections. When the internal beads of each starting outer pipe line up, rotate pipe section clockwise 90° (approximately 3 inches). The vent pipe is now locked together. Continue adding components per the pre-planned vent system configuration. Be certain that each succeeding vent component is securely fitted and locked into the preceding component in the vent system. Special Venting Components (Duravent) See Empire Comfort Systems Retail Price List for 4 x 6-5/8 inch Duravent part numbers and pricing. -
Page 26: Venting Framing And Finishing
VENTING FRAMING AND FINISHING Installing Support Brackets A horizontal pipe support MUST BE used for each 3 feet of horizontal run. The pipe supports should be placed around the pipe and nailed in place to framing members. There MUST BE a 3 inch clearance to combustibles above flue pipe and elbows and 1 inch clearance on both sides and bottom of the flue pipe to combustibles on all horizontal pipe sections and elbows. Vertical runs of this vent systems must be supported every 4 feet ▲ above the appliance flue outlet by wall brackets attached to the vent pipe and secured with nails or screws to structural framing members. - Page 27 VENTING FRAMING AND FINISHING If the area above the ceiling is NOT an attic, position and secure NAILS, 4 REQUIRED the ceiling firestop on the ceiling side of the previously cut and CEILING FIRESTOP framed hole. See Figure 37. If the area above the ceiling is an attic, position and secure the firestop on top of the previously framed hole. See Figure 38. NOTE: Remove insulation from the framed area in the attic before installing the firestop and/or vent pipes.
-
Page 28: Horizontal Termination
HORIZONTAL TERMINATION NOTE: Termination cap should pass through the wall firestop from the exterior of the building. Adjust the termination cap to its final exterior position on the building. Warning: Termination cap must be positioned so that arrow is pointing up. Attach the termination cap with the four wood screws provided. Before attachment of the termination, run a bead of silicone sealant rated above 250°F on its outside edge too, so as to make a seal to the exterior wall. NOTE: Wood screws can and should be replaced with appropriate fasteners for use on stucco, brick, concrete or other types of siding. CAUTION: If exterior walls are finished with vinyl siding, (or materials that could become discolored or warp) it is necessary to install a vinyl siding standoff. The vinyl siding standoff will be installed between the vent termination and the exterior wall. See Figure 39. This horizontal vent termination bolts onto the flat portion of the vinyl siding standoff, so an air space will exist between the wall and the termination cap. CUT VINYL SIDING AWAY TO FIT STANDOFF (4 REQUIRED) WOOD SCREWS (4 REQUIRED) VENT TERMINATION... -
Page 29: Vertical Termination
VERTICAL TERMINATION Locate and mark the center point of the venting pipe. Using a nail on the underside of the roof and drive this nail through this center point. Make the outline of the roof hole around this center point. NOTE: Size of the roof hole dimensions depend on the pitch of the roof. There must be a 1 inch clearance (25mm) to the 24” MIN. vertical pipe sections. This clearance is to all combustible (609.6mm) material. Cover the opening of the vent pipe and cut and frame the roof hole. ▲ Use framing lumber the same size as the roof rafters and install the 12” MIN. 24” MIN. (304.8mm) frame securely. Flashing anchored to frame must withstand high ► ◄ (609.6mm) ▼ winds. The storm collar is placed over this joint to make a water-tight seal. Non-hardening sealant should be used to completely seal this flashing installation. Determining Minimum Vent Height Above the Roof. WARNING: Major U.S. building codes specify minimum chimney and/or vent height above the roof top. - Page 30 VERTICAL TERMINATION Installing the Vent System in a Chase Vertical Through the Roof Applications A chase is a vertical box-like structure built to enclose the gas Your Gas Fireplace has been approved for: appliance and/or its vent system. Vertical vent runs on the outside of a) Vertical installations up to 40 ft. (12.19 m) in height. a building may be, but are not required to be installed inside a chase. b) Two sets of 45 degree elbow offsets within these vertical installations. From 0 to a maximum of 8 ft. a vent pipe can be CAUTION: Treatment of firestop spacers and construction of used between elbows. See Figure 43.
-
Page 31: Dvvk-4F Flex Vent Instructions
DVVK-4F FLEX VENT INSTRUCTIONS The DVVK-4F FLEX VENT KIT includes the following components: • (1) Horizontal Termination Cap • (1) 7" diameter outer vent adapter collar • (1) 4-foot section of Flex vent with spacers (4" flue/7" outer • (1) Wall Firestop/Thimble Assembly pipe) • Hardware pack that includes band clamps and screws • (1) 4" diameter flue adapter collar NOTE: If installing the DVVK-4F Flex Vent Kit, an SD46DVA-FCFX7 Flex Adaptor Collar Assembly must also be used (purchased separately). -
Page 32: Finishing The Wall
FINISHING THE WALL Finishing The Wall For DF414BL DF41W Series & Finishing The Wall for DF414BL, DF41W Series, & DF41EHPBL DF41EHPBL Decorative Front Decorative Front With Finishing Materials Greater Than 1 in. A minimum of 5/8 in. (15.8mm) is required from the bottom of the (25.4mm) Thick fireplace to the top of the hearth extension material. For finishing materials over 1 in. (25.4mm) thick, center the unit side A minimum of 1/8 in. (3mm) is required from the side of the unit to side in a 26 in. x 53-34 in. (660mm x 136.5cm) opening. The front to combustible material. will fit inside the finishing material. - Page 33 FINISHING THE WALL Finishing The Wall for DF412BL Decorative Front With Inside Fit The inside fit front allows for finishing over the face of the fireplace and right up to the removable front. After installing the fireplace, install the front kit. Locate the two side stone stops. Loosen the top and bottom screws on the inside opening of the fireplace but do not remove them. See Figure 51. Slip the side stone stop under the two screws and tighten. Repeat for the other side. Locate the steel hood stone stop. Loosen the 7 screws under the top edge of the fireplace - do not remove. Slip the hood stone stop under the 7 screws and tighten while holding back tightly against the top face of the fireplace. Secure front face of the hood stone stop to upper fireplace face with three screws. Hang the decorative front on the four rectangle cut-outs on the face of the fireplace. Finish around the fireplace, you must use only non-combustible material to cover the steel face and non-combustible board on the fireplace. All non-combustible finishing materials must stop at the side and hood stone stops. Finishing material must not go past the stone stops or the front will not fit. Stop the finishing material at the bottom of the valve opening so the valve and fans are clear for service. 55-1/2” x 13-1/2” (141cm x 343mm) NON-COMBUSTIBLE BOARD HOOD STONE STOPS SIDE SIDE STONE STOPS STONE STOPS NON COMBUSTIBLE NON COMBUSTIBLE...
-
Page 34: Dvtl Log & Ember Placement
DVTL LOG PLACEMENT The DVTL41BP Series fireplaces are shipped without a Log set, however a log set must be installed for proper operation. Optional Log sets are available and must be ordered separately. Contact your dealer for available options. Follow the installation instructions supplied with the Log sets for proper handling, positioning, and care. When installing the logs into the fireplace, always wear gloves to prevent skin irritation from ceramic fibers. After handling logs, wash your hands gently with soap and water to remove any traces of fiber. Use extra care in the handling of the logs to avoid accidental breakage. Long slender logs and branches are susceptible to breakage if not handled properly. The positioning of logs is critical to safe and clean operation of this fireplace. Sooting and other problems may result if the logs are not properly and firmly positioned in the fireplace. Please refer to Figure 53 and corresponding WARNING, when completing the Ember and Log placement steps. Embers should be dime-sized pieces that are fluffed up prior to placement onto the burner. A single layer of embers is sufficient: do not over-apply. -
Page 35: Dvll Decorative Media Installation
DVLL DECORATIVE MEDIA INSTALLATION Proper installation of the decorative media is critical to safe 1. Remove the front and the glass frame assembly. and clean operation of the fireplace. 2. Place the long thin glass piece (media retainer) into the groove in front of the media tray in the firebox opening. This will keep the decorative media from falling out. WARNING 3. Place dime-sized pieces of ember across the burner surface. Failure to position the parts in accordance with the dia- A single layer, is sufficient; do not over-apply. See Figure 54 grams and instructions below or failure to use only parts inset. -
Page 36: Multifunction Remote Lighting Instructions
MULTIFUNCTION REMOTE LIGHTING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY, OR LOSS OF LIFE. A. This appliance has a pilot which must be lighted by hand. knob. -
Page 37: Operating Instructions
OPERATING INSTRUCTIONS RF VALVE OPERATION SPECIAL FEATURES ON THE CONTROL MODULE (AF-4044 Electronic Gas Valve system only) The Control Module has two special pilot mode features built into the system. NOTE: THE FIREPLACE WILL ONLY OPERATE WITH THE CONTINUOUS PILOT FEATURE: This allows the user to change HAND HELD REMOTE TRANSMITTER. THE TRANSMITTER from a spark to pilot system to a standing pilot system. CONTROLS ALL FUNCTIONS OF THE FIREPLACE. 1. There is a switch located on the right side of the Control Module (#4) that reads CONTINUOUS PILOT ON/OFF. This Please refer to the separate instructions for detailed operation and... -
Page 38: Maintenance Instructions
OPERATING INSTRUCTIONS REMOTE CONTROL FEATURE: The Control Module has a built POWER SUPPLY SYSTEM in remote control receiver which allows the user to program the The Gas Control system is powered by a standard 110 volt AC hand held remote transmitter. through a 6.0 volt DC adaptor. The AC adaptor is connected to the 1. There is a switch located on the right side of the Control Mod- Control Module with two 1/4 in. (6.35 mm) female terminals. ule that reads REMOTE/OFF. This control system also includes a Battery Back-up pack that al- 2. When the remote/off switch is in the OFF position the appli- lows the Gas Control system only to operate in the event of a ance will operate from an appliance mounted rocker switch or power outage. -
Page 39: Wiring Diagram
MAINTENANCE INSTRUCTIONS TROUBLESHOOTING OPTIONAL GAS CONVERSION KITS IMPORTANT: All service and trouble-shooting procedures should Please contact your dealer or distributor for the proper Conversion be performed by an experienced qualified service technician. kit for these fireplace models. Conversion kits will include com- If the pilot will not stay lit: plete instructions, minimum rate screw, plus the pilot and main burner orifice for the gas type required. The AF-4044 Electronic 1. Confirm that the sensor wire (white) and the ignitor wire (or- Gas Control Valve is convertible to use either natural or propane ange) are properly connected to the Control Module “S” and gas by simply turning a small Rotary knob located at the front of... -
Page 40: Maintenance And Service
MAINTENANCE AND SERVICE Please Note It is normal for appliances fabricated of steel to give off WARNING: Do not use abrasive cleaners on glass. Do not some expansion and/or contraction noise during the start attempt to clean glass when glass is hot. up or cool down cycle. -
Page 41: Accessories
ACCESSORIES The following accessory parts can be obtained from your Empire Comfort Systems dealer. If you need additional information beyond what your dealer can furnish, contact Empire Comfort Systems Inc., Nine Eighteen Freeburg Ave., Belleville, Illinois 62220-2623. DECORATIVE ACCESSORIES DFQ412BL 2" (50.8 mm) Decorative Front DFQ414BL 4" (101.6 mm) Decorative Front DG41C Decorative Glass Panels (DVLL Only) DVP41LKR Liner, Black Reflective (DVTL Only) FBB9 Blower Kit DFQ41WBL Tide Water Decorative Front, Black DFQ41WHP Tide Water Decorative Front, Hammered Pewter OPTIONAL PORCELAIN PANELS (DVTL ONLY) NOTE: Install liner before positioning the logs in place. LEFT PANEL BACK PANEL RIGHT PANEL Figure 58 PLACING THE OPTIONAL PORCELAIN PANELS INTO THE DVTL41 FIREPLACE: Locate the left and right side porcelain pieces. -
Page 42: Optional Decorative Glass Panels (Dvll Only)
OPTIONAL DECORATIVE GLASS PANELS (DVLL ONLY) NOTE: THIS NEEDS TO BE DONE BEFORE INSTALLING THE 3. Place the two “A” panels through the small tabs and into the GLASS MEDIA BEADS. center rear slots in the media tray base. 4. Place the two “B” panels through the small tabs and into the PLACING THE OPTIONAL DECORATIVE GLASS PANELS outer rear slots in the media tray base. INTO THE DVLL FIREPLACE: 5. Place the three “C” front glass panels through the small tabs and into the front slots in the media tray base. Use the Glass Identification Chart as a dimensions guide for 6. Install the glass media beads around the media tray to hide the glass glass panel parts. -
Page 43: Dvll Parts List
DVLL PARTS LIST Index Part Index Part Description Description Number Number 28431 Flue Baffle 28452 Standoff Support P209 Orifice, Nat 28454 Standoff Support P211 Orifice, LP 28453 Upper Standoff (Qty. 2) R10928 Bulb, Halogen 30100BL Porcelain Firebox Liner - Left R11259 Lens, Red 30101BL Porcelain Firebox Liner - Back R10925 Glass Media 30576BL Porcelain Firebox Liner - Right R10423 Pilot, Nat 28465 Support Bracket (Qty. 2) R10424 Pilot, LP 28428 Vertical Vent Baffle (Qty. 2) -
Page 44: Dvll Exploded View
DVLL EXPLODED VIEW Use Only Manufacturer’s Replacement Parts. Use of Any Other Parts Could Cause Injury Or Death. 33598-10-0616 Page 43... -
Page 45: Dvtl Parts List
DVTL PARTS LIST Index Part Index Part Description Description Number Number 28452 Top Standoff Support 28431 Flue Baffle 28454 Top Standoff Support P211 Orifice, Nat 28453 Top Standoff (Qty. 2) P210 Orifice, LP R11443 Non-Combustible Board (Qty. 2) 29749 Log Set 28498 Pilot Shield R10423 Pilot, Nat R11441 Three-prong receptacle (Qty. 2) R10424 Pilot, LP R3490 Junction Box R11393 Minimum Rate Screw, Nat 28499 Extension Module Mount Plate R10428 Minimum Rate Screw, LP... -
Page 46: Dvtl Exploded View
DVTL EXPLODED VIEW Use Only Manufacturer’s Replacement Parts. Use of Any Other Parts Could Cause Injury Or Death. 33598-10-0616 Page 45... -
Page 47: Master Parts Distributor List
MASTER PARTS DISTRIBUTOR LIST To Order Parts Under Warranty, please contact your local Empire dealer. See the dealer locator at www.empirecomfort. com. To provide warranty service, your dealer will need your name and address, purchase date and serial number, and the nature of the problem with the unit. To Order Parts After the Warranty Period, please contact your dealer or one of the Master Parts Distributors listed below. This list changes from time to time. For the current list, please click on the Master Parts button at www.empirecomfort.com. Please note: Master Parts Distributors are independent businesses that stock the most commonly ordered Original Equipment repair parts for Heaters, Grills, and Fireplaces manufactured by Empire Comfort Systems Inc. Dey Distributing Victor Division of F. W. Webb Company 1401 Willow Lake Boulevard 200 Locust Street Vadnais Heights, MN 55101 Hartford, CT 06114 Phone: 651-490-9191 Phone: 860-722-2433 Toll Free: 800-397-1339 Toll Free: 800-243-9360... -
Page 48: Junction Box Wiring Installation Instructions
JUNCTION BOX WIRING INSTALLATION INSTRUCTIONS CAUTION: ALL WIRING SHOULD BE DONE BY A QUALIFIED ELECTRICIAN AND SHALL BE IN COMPLIANCE WITH ALL LOCAL, CITY AND STATE BUILDING CODES. BEFORE MAKING THE ELECTRICAL CONNECTION, MAKE SURE THAT MAIN POWER SUP- PLY IS DISCONNECTED. THE APPLIANCE, WHEN INSTALLED, MUST BE ELECTRICALLY GROUNDED IN ACCORDANCE WITH LOCAL CODES OR, IN THE ABSENCE OF LOCAL CODES, WITH THE NATIONAL ELECTRICAL CODE ANSI/NFPA 70 (LATEST EDITION). -
Page 49: Quick Reference Guide
Empire Comfort Systems Web Site www.empirecomfort.com EMPIRE EMPIRE 918 Freeburg Avenue Belleville, Illinois 62220-2623 Comfort Systems Direct Vent Zero Clearance Gas Fireplace Heater INTERMITTENT PILOT: MODERN - DVLLFP92(N,P)-3 TRADITIONAL - DVTL41BP90(N,P)-1 GAS-FIRED CLEARANCES TO COMBUSTIBLES 20” (508) 19” (482) IN THIS AREA 20 ½” (521) 18”... - Page 50 Empire Comfort Systems Web Site www.empirecomfort.com EMPIRE EMPIRE 918 Freeburg Avenue Belleville, Illinois 62220-2623 Comfort Systems Direct Vent Zero Clearance Gas Fireplace Heater INTERMITTENT PILOT: MODERN - DVLLFP92(N,P)-3 TRADITIONAL - DVTL41BP90(N,P)-1 GAS-FIRED DIMENSIONS FIREBOX DIMENSIONS in inches (metric) DVLL(DVTL) 51-1/16 12” (305mm) (129.7cm) 44-1/2 (113.0cm) 16-1/2 (419mm )
-
Page 51: Warranty
WARRANTY Empire Comfort Systems Inc. warranties this hearth product to be free from defects at the time of purchase and for the periods specified below. Hearth products must be installed by a qualified technician and must be maintained and oper- ated safely, in accordance with the instructions in the owner’s manual. Empire will not warranty any Château, Boulevard, or Mantis fireplace that is not installed by the selling dealer or that dealer’s direct contract agents. This warranty applies to the original purchaser only and is not transferable. All warranty repairs must be accomplished by a qualified gas appliance technician. Limited Lifetime Parts Warranty – Combustion Chamber, Heat Exchanger, and Factory-Installed Glass If the combustion chamber, heat exchanger (see parts list) or factory-installed glass fails because of defective workmanship or material, Empire will repair or replace at Empire’s option. Limited Three-Year Parts Warranty – All Other Components (Except Remote Controls, Thermostats, Accessories and Replacement Parts) Should any part fail because of defective workmanship or material within three years from the date of purchase, Empire will repair or replace at Empire’s option.. Limited One-Year Parts Warranty – Remote Controls, Thermostats, Accessories, and Parts Should any remote control, thermostat, accessory, or other part fail because of defective workmanship within one year from the date of purchase, Empire will repair or replace at Empire’s option. -
Page 52: Appliance Service History
APPLIANCE SERVICE HISTORY Date Dealer Name Service Technician Name Service Performed/Notes 33598-10-0616 Page 51... - Page 53 Empire Comfort Systems Inc. EMPIRE EMPIRE 918 Freeburg Ave. Belleville, IL 62220 If you have a general question about our products, please e-mail us at info@empirecomfort.com. If you have a service or repair question, please contact your dealer. Comfort Systems www.empirecomfort.com Page 52 33598-10-0616...
