TABLE OF CONTENTS
1 Safety Precautions----------------------------------------------- 3
2 Specifications ----------------------------------------------------- 5
3 Features ------------------------------------------------------------- 7
4 Location of Controls and Components ------------------- 8
4.1. Indoor Unit--------------------------------------------------- 8
4.2. Outdoor Unit ------------------------------------------------ 8
4.3. Remote Control -------------------------------------------- 8
5 Dimensions--------------------------------------------------------- 9
5.1. Indoor Unit & Remote Control -------------------------- 9
5.2. Outdoor Unit -----------------------------------------------10
6 Refrigeration Cycle Diagram --------------------------------12
6.1. CS-PC30JKF CU-PC30JKF ---------------------------12
6.2. CS-PC36JKF CU-PC36JKF ---------------------------13
7 Block Diagram----------------------------------------------------14
Indoor Unit
CS-PC30JKF CU-PC30JKF
CS-PC36JKF CU-PC36JKF
P
A
G
E
8 Wiring Connection Diagram--------------------------------- 15
8.1. Indoor Unit ------------------------------------------------- 15
8.2. Outdoor Unit----------------------------------------------- 16
9 Electronic Circuit Diagram----------------------------------- 18
9.1. Indoor Unit ------------------------------------------------- 18
9.2. Outdoor Unit----------------------------------------------- 19
10 Printed Circuit Board ------------------------------------------ 21
10.1. Indoor Unit ------------------------------------------------- 21
10.2. Outdoor Unit----------------------------------------------- 23
11 Installation Instruction ---------------------------------------- 25
11.1. Select The Best Location ------------------------------ 25
11.2. Indoor/Outdoor UnitInstallation Diagram ----------- 25
11.3. Indoor Unit ------------------------------------------------- 26
11.4. Outdoor Unit----------------------------------------------- 30
© Panasonic HA Air-Conditioning (M) Sdn. Bhd. 2008.
Unauthorized copying and distribution is a violation of law.
Order No. PHAAM0812044C3
Air Conditioner
Outdoor Unit
P
A
G
E
Advertisement
Table of Contents
Related Manuals for Panasonic CU-PC30JKF
Summary of Contents for Panasonic CU-PC30JKF
-
Page 1: Table Of Contents
6.1. CS-PC30JKF CU-PC30JKF ---------------------------12 11.2. Indoor/Outdoor UnitInstallation Diagram ----------- 25 6.2. CS-PC36JKF CU-PC36JKF ---------------------------13 11.3. Indoor Unit ------------------------------------------------- 26 7 Block Diagram----------------------------------------------------14 11.4. Outdoor Unit----------------------------------------------- 30 © Panasonic HA Air-Conditioning (M) Sdn. Bhd. 2008. Unauthorized copying and distribution is a violation of law. - Page 2 12 Operation Control----------------------------------------------- 35 12.1. Cooling Operation---------------------------------------- 35 12.2. Soft Dry Operation --------------------------------------- 35 12.3. Auto Operation-------------------------------------------- 35 12.4. Thermostat Control -------------------------------------- 36 12.5. Indoor Fan Control --------------------------------------- 36 12.6. Outdoor Fan Operation --------------------------------- 36 12.7. Odour Cut Control---------------------------------------- 37 12.8.
-
Page 3: Safety Precautions
1. Safety Precautions • Read the following “SAFETY PRECAUTIONS” carefully before perform any servicing. • Electrical work must be installed or serviced by a licensed electrician. Be sure to use the correct rating of the power plug and main circuit for the model installed. •... - Page 4 WARNING 20. After completion of installation or service, confirm there is no leakage or refrigerant gas. It may generate toxic gas when the refrigerant contacts with fire. 21. Ventilate if there is refrigerant gas leakage during operation. It may cause toxic gas when refrigerant contacts with fire. 22.
-
Page 5: Specifications
2 Specifications MODEL INDOOR CS-PC30JKF CS-PC36JKF OUTDOOR CU-PC30JKF CU-PC36JKF Performance Test Condition NEW JIS NEW JIS Phase, Hz Single, 50 Single, 50 Power Supply 8.79 8.79 10.55 10.55 Capacity BTU/h 30000 30000 36000 36000 kJ/h 31640 31640 37980 37980 Running Current 14.2... - Page 6 MODEL INDOOR CS-PC30JKF CS-PC36JKF OUTDOOR CU-PC30JKF CU-PC36JKF Inner Diameter Drain Hose Length Fin Material Aluminium (Pre Coat) Aluminium (Pre Coat) Fin Type Slit Fin Corrugated Fin Indoor Heat Row u Stage u 2 u 14 u 18 2 u 14 u 17...
-
Page 7: Features
3 Features • Long Installation Piping - Long piping up to 30 meter. • Easy to use remote control • Quality Improvement - Random auto restart after power failure for safety restart operation. - Gas leakage detection. - Prevent compressor reverse cycle. - Inner protector to protect compressor. -
Page 8: Location Of Controls And Components
4 Location of Controls and Components 4.1. Indoor Unit 4.2. Outdoor Unit • Outdoor unit shown is CU-PC36JK. 4.3. Remote Control... -
Page 9: Dimensions
5 Dimensions 5.1. Indoor Unit & Remote Control... -
Page 10: Outdoor Unit
5.2. Outdoor Unit 5.2.1. CU-PC30JKF... - Page 11 5.2.2. CU-PC36JKF...
-
Page 12: Refrigeration Cycle Diagram
6 Refrigeration Cycle Diagram 6.1. CS-PC30JKF CU-PC30JKF... -
Page 13: Cs-Pc36Jkf Cu-Pc36Jkf
6.2. CS-PC36JKF CU-PC36JKF... -
Page 14: Block Diagram
7 Block Diagram... -
Page 15: Wiring Connection Diagram
8 Wiring Connection Diagram 8.1. Indoor Unit 8.1.1. CS-PC30JKF CS-PC36JKF... -
Page 16: Outdoor Unit
8.2. Outdoor Unit 8.2.1. CU-PC30JKF Resistance of Compressor Windings Resistance of Outdoor Fan Motor Windings MODEL CU-PC30JKF MODEL CS-PC30JKF CONNECTION 2JD514D5AA03 CONNECTION CWA951658 0.675 : 73.6 : C - R BLUE - YELLOW 2.279 : 94.8 : C - S YELLOW - RED Note: Resistance at 20qC of ambient temperature. - Page 17 8.2.2. CU-PC36JKF Resistance of Compressor Windings Resistance of Outdoor Fan Motor Windings MODEL CU-PC36JKF MODEL CS-PC36JKF CONNECTION ZR47K3-PFJ-512 CONNECTION CWA951366J / CWA951403J 1.67 : 73.5 : C - R BLUE - YELLOW 0.59 : 102.0 : C - S YELLOW - RED Note: Resistance at 25qC of ambient temperature.
-
Page 18: Electronic Circuit Diagram
9 Electronic Circuit Diagram 9.1. Indoor Unit... -
Page 19: Outdoor Unit
9.2. Outdoor Unit 9.2.1. CU-PC30JKF... - Page 20 9.2.2. CU-PC36JKF...
-
Page 21: Printed Circuit Board
10 Printed Circuit Board 10.1. Indoor Unit 10.1.1. Main Printed Circuit Board... - Page 22 10.1.2. Power Printed Circuit Board 10.1.3. Indicator Printed Circuit Board...
-
Page 23: Outdoor Unit
10.2. Outdoor Unit 10.2.1. Main Printed Circuit Board 10.2.1.1. CU-PC30JKF... - Page 24 10.2.1.2. CU-PC36JKF...
-
Page 25: Installation Instruction
11 Installation Instruction 11.1. Select The Best Location 11.2. Indoor/Outdoor Unit Installation Diagram 11.1.1. Indoor Unit • Do not install the unit in excessive oil fume area such as kitchen, workshop and etc. • There should not be any heat source or steam near the unit. •... -
Page 26: Indoor Unit
11.3. Indoor Unit 11.3.1. How To Fix Installation Plate 11.3.2. To Drill A Hole In The Wall And Install A Sleeve Of Piping The mounting wall is strong and solid enough to prevent it from the vibration. 1. Insert the piping sleeve to the hole. 2. - Page 27 11.3.3.3. For the embedded piping Install accessory of tube ass’y 1. Remove chassis back particular piece.
- Page 28 7. Close back the chassis back piece. 2. Connect tube ass’y to gas side piping. Liquid side piping need to pull out to joint tube ass’y. 3. Set the piping direction. (For bottom piping, need to perform cutting and flaring process.) (This can be used for left rear piping and left bottom piping also.)
- Page 29 11.3.4. Connect The Cable To The Indoor Unit 1. The indoor and outdoor connecting cable can be connected without removing the front grille. 2. Connecting cable between indoor unit and outdoor unit shall be approved polychloroprene sheathed 4 u 2.5 mm flexible cord, type designation 245 IEC 57 or heavier cord.
-
Page 30: Outdoor Unit
11.4. Outdoor Unit 11.4.1. Install The Outdoor Unit • After selecting the best location, start installation according to Indoor/Outdoor Unit Installation Diagram. 1. If installing the unit to a concrete base or other solid base, use M10 or W3/8 bolts and nuts to secure the unit, and ensure that the unit is fully upright and level. - Page 31 11.4.2.2. Connecting The Piping To Outdoor Unit Decide piping length and then cut by using pipe cutter. Remove burrs from cut edge. Make flare after inserting the flare nut (locate at valve) onto the copper pipe. Align center of piping to valves and then tighten with torque wrench to the specified torque as stated in the table.
- Page 32 11.4.3. Air Purging Of The Pipings And Indoor Unit 1) Checking a gas leakage 1. Remove the service port cap from 3-way valves. 2. Connect the Manifold gauge set to the service port of liquid side 3-way valve. 3. Connect the Charging Cylinder to the Manifold gauge set and open the valve of the Cylinder. 4.
- Page 33 11.4.4. Connect The Cable To The Outdoor Unit (FOR DETAIL REFER TO WIRING DIAGRAM AT UNIT) 1. Remove the control board cover from the unit by loosening the screw. 2. Connecting cable between indoor unit and outdoor unit shall be approved polychloroprene sheathed 4 x 2.5 mm flexible cord, type designation 245 IEC 57 or heavier cord.
- Page 34 11.4.6. Precautions with Regard to Test Operation • Use only insulation tool to switch on the microswitch on the electric circuit board (do not use finger or metallic tool). • Do not switch on power before all installation is completed. •...
-
Page 35: Operation Control
12 Operation Control 12.1. Cooling Operation • Cooling operation can be set using remote control. • This operation is applied to cool down the room temperature reaches the setting temperature set on the remote control. • Cooling Operation Time Diagram. 12.2. -
Page 36: Thermostat Control
12.4. Thermostat Control • Depending on differences between room temperature and setting temperature, compressor operation is decided and starts operation. • If temperature difference matches values shown below, thermostat switches off. Cooling Soft Dry -1.0qC 12.5. Indoor Fan Control 12.5.1. Manual Fan Speed •... -
Page 37: Odour Cut Control
12.7. Odour Cut Control • Odour cut operation removes the odour generated at indoor heat exchanger by using drain water come out from indoor heat exchanger. • Press “Odour” button at remote control to enable odour cut operation. • Odour cut operation starts when compressor or thermostat is on. Thermostat &... -
Page 38: Protection Control
13 Protection Control 13.1. Restart Control (Time Delay Safety Control) • When the thermo-off temperature (temperature which compressor stops to operate) is reached, the compressor stops for 3 minutes (minimum) before resume operation. • If the operation is stopped by the remote control, the compressor will not turn on within 3 minutes from the moment operation stop, although the unit is on again within the period. -
Page 39: Outdoor Fan Residual Heat Removal Control
• Dew prevention control will be cancel when: - Any one of the condition above does not comply. 13.4. Outdoor Fan Residual Heat Removal Control • When the compressor stops to operate, the outdoor fan motor continue to operate for 60 seconds before stops operation. •... -
Page 40: Servicing Mode
14 Servicing Mode 14.1. Auto OFF/ON Button 1. AUTO OPERATION MODE The Auto operation will be activated immediately once the AUTO OFF/ON button is pressed. This operation can be used to operate air conditioner with limited function if remote control is misplaced or malfunction. 2. -
Page 41: Remote Control Button
After AUTO OFF/ON button is pressed, the 20 seconds counter for Remote Control Receiving Sound OFF/ON mode is restarted. 14.2. Remote Control Button 14.2.1. SET • To change the type of remote control transmission signal (there are totally four types of transmission codes). - Modify the jumper (back of PCB) &... -
Page 42: Troubleshooting Guide
15 Troubleshooting Guide 15.1. Refrigeration Cycle System In order to diagnose malfunctions, make sure that there are no electrical problems before inspecting the refrigeration cycle. Such problems include insufficient insulation, problem with the power source, malfunction of a compressor and a fan. The normal outlet air temperature and pressure of the refrigeration cycle depends on various conditions, the standard values for them are shown in the table on the right. -
Page 43: Relationship Between The Condition Of The Air Conditioner And Pressure And Electric Current
15.2. Relationship Between The Condition Of The Air Conditioner And Pressure And Electric Current Cooling Mode Condition of the air conditoner Low Pressure High Pressure Electric current during operation Insufficient refrigerant (gas leakage) Clogged capillary tube or Strainer Short circuit in the indoor unit Heat radiation deficiency of the outdoor unit Inefficient compression... -
Page 44: Error Code Table
15.4. Error Code Table 15.4.1. Self-diagnosis function 1. The self-diagnosis LEDs (red) on the outdoor unit printed circuit board can be used to indicate where the location of a problem Refer to the table below to remove the cause of the problem and then re-start the air conditioner system. 2. -
Page 45: Test Run (Forced Cooling Control)
15.5. Test Run (Forced Cooling Control) • Test Run can be enable using the switch at the outdoor unit's PCB according to procedure below: - Set the DS1 to (Cooling Test Run) mode - Press SW1 for 1 second to test run. - Be sure to select cooling mode first, and run the unit in this mode for 5 minutes or more. -
Page 46: Disassembly And Assembly Instructions
16 Disassembly and Assembly Instructions WARNING High Voltage are generated in the electrical parts area by the capacitor. Ensure that the capacitor has discharged sufficiently before proceeding with repair work. Failure to heed this caution may result in electric shocks. 16.1. - Page 47 16.1.3. To remove discharge grille...
- Page 48 16.1.4. To remove control board 16.1.5. To remove cross flow fan and indoor fan motor...
-
Page 50: Technical Data
17 Technical Data 17.1. Thermostat Characteristics Cooling Soft Dry... -
Page 51: Operation Characteristics
17.2. Operation Characteristics 17.2.1. CS-PC30JKF CU-PC30JKF... - Page 53 17.2.2. CS-PC36JKF CU-PC36JKF...
-
Page 55: Discharge And Suction Pressure
17.3. Discharge and Suction Pressure 17.3.1. CS-PC30JKF CU-PC30JKF Power source : 220V & 240V, 50Hz, 1 phase OUTDOOR AMBIENT TEMPERATURE 10qC 20qC 30qC 40qC 50qC 55qC Indoor Wet Saturate Saturate Saturate Saturate Saturate Saturate Bulb Discharge Discharge Discharge Discharge Discharge... -
Page 56: Fan Performance
17.4. Fan Performance 17.4.1. CS-PC30JKF CU-PC30JKF INDOOR OUTDOOR Item / Model CS-PC30JKF CU-PC30JKF Mode Hi (220/240) Me (220/240) Lo (220/240) Hi (220/240) 19.70 17.50 15.30 51.00/56.00 Air Volume /min Running Current 0.49/0.52 0.40/0.41 0.31/0.33 0.66/0.68 Power Consumption 0.06/0.06 0.04/0.04 0.03/0.03 0.14/0.16... -
Page 57: Sound Data
17.5. Sound Data 17.5.1. CS-PC30JKF CU-PC30JKF 17.5.2. CS-PC36JKF CU-PC36JKF... -
Page 58: Cooling Capacity Performance Data
17.6. Cooling Capacity Performance Data 17.6.1. CS-PC30JKF CU-PC30JKF Power source : 220V & 240V, 50Hz, 1 phase Air Temperature Entering Condenser C (D.B) Indoor Ambient 25qC 30qC 35qC 40qC 45qC 55qC Temp. D.B. W.B. 9.1551 5.5513 2.5074 8.7900 5.6282 2.7218 8.2761... - Page 59 17.6.2. CS-PC36JKF CU-PC36JKF Power source : 220V & 240V, 50Hz, 1 phase Air Temperature Entering Condenser qC (D.B) Indoor Ambient 25qC 30qC 35qC 40qC 45qC 52qC Temp. D.B. W.B. 17 10.9882 6.6786 2.7064 10.5500 6.7712 2.9376 9.9332 6.5552 3.1960 9.1866 6.2776 3.5088 8.6348...
-
Page 60: Exploded View And Replacement Parts List
18 Exploded View and Replacement Parts List 18.1. Indoor Unit Note: The above exploded view is for the purpose of parts disassembly and replacement. The non-numbered parts are not kept as standard service parts. - Page 61 REF. NO. PART NAME & DESCRIPTION QTY. CS-PC30JKF CS-PC36JKF REMARKS CHASSY COMPLETE CWD50C1477 FAN MOTOR DC 60W 3PH ARW42A8P60AC CROSS FLOW FAN COMPLETE CWH02C1044 SCREW - CROSS FLOW FAN CWH551146 BEARING ASS’Y CWH64K007 EVAPORATOR COMPLETE CWB30C2984 CWB30C2533 TUBE ASS'Y COM (EVA) CWT01C3689 CWT01C3637 FLARE NUT (3/8”)
-
Page 62: Outdoor Unit
18.2. Outdoor Unit 18.2.1. CU-PC30JKF... - Page 63 Note: The above exploded view is for the purpose of parts disassembly and replacement. The non-numbered parts are not kept as standard service parts.
- Page 64 <Model: CU-PC30JKF> REF. NO. PART NAME & DESCRIPTION QTY. CU-PC30JKF REMARKS BASE PAN ASS’Y CWD52K1102 COMPRESSOR 2JD514D5AA03 ANTI - VIBRATION BUSHING CWH50055 NUT FOR COMP. MOUNT. CWH561049 PACKING CWB811017 CONDENSER COMPLETE CWB32C1778 OIL SEPARATER CWB16000 TUBE ASS’Y (EXP. VALVE STRAINER) CWT01C3691 TUBE ASS’Y (CAPILLARY TUBE)
- Page 65 18.2.2. CU-PC36JKF...
- Page 67 Note: The above exploded view is for the purpose of parts disassembly and replacement. The non-numbered parts are not kept as standard service parts.
- Page 68 <Model: CU-PC36JKF> REF. NO. PART NAME & DESCRIPTION QTY. CU-PC36JKF REMARKS BASE PAN ASS’Y CWD52K1157 COMPRESSOR ZR47K3PFJ512 ANTI - VIBRATION BUSHING CWH501020 GASKET FOR TERMINAL COVER CWB811017 NUT FOR COMP. MOUNT. CWH561049 CONDENSER COMPLETE CWB32C1773 TUBE ASS’Y (EXP. VALVE + STRAINER) CWT01C3770 3-WAYS VALVE (GAS) CWB011295...
