Hitachi SF-P100XAV Operating & Installation Instructions Manual

Fully automatic washing machine
Hide thumbs
Table of Contents

Advertisement

Quick Links

Operating & Installation Instructions
EN
Fully Automatic Washing Machine
Model SF-P100XAV
Thank you for purchasing a Hitachi fully automatic washing machine.
■
Please read these operating & installation instructions carefully for proper
operation of the machine.
■
Please keep these operating & installation instructions for future reference.
Contents
2
3
5
6
8
9
15
22
22
24
25
26
30
30

Advertisement

Table of Contents
loading

Related Manuals for Hitachi SF-P100XAV

Summary of Contents for Hitachi SF-P100XAV

  • Page 1: Table Of Contents

    Troubleshooting Error Codes How to Install the Washing Machine Customer Service Specifi cations Thank you for purchasing a Hitachi fully automatic washing machine. ■ Please read these operating & installation instructions carefully for proper operation of the machine. ■ Please keep these operating & installation instructions for future reference.

  • Page 2: Environmentally Friendly Waste Disposal

    Environmentally Friendly Waste Disposal The shipping package has protected your new washing machine on its Disposing of the way to your home. All materials are ecologically harmless and recyclable. packaging Please contribute to a better environment by disposing of packaging materials in an environmentally conscious manner.

  • Page 3: Safety Instructions

    Safety Instructions This washing machine is designed for home use only. Before operating the washing machine, please read these safety instructions carefully. Warning Issues which could cause death or serious injury. ■ Do not dismantle, repair or modify the washing machine. General safety This could cause malfunction, fi...
  • Page 4 ■ Do not use water hotter than 50ºC. ■ SF-P100XAV Do not wash items together with coins, pins, or stones. This may damage clothes or the washing machine, or cause a water leak. Check inside pockets before washing.

  • Page 5: Parts And Accessories

    Parts and Accessories Softener Dispenser Liquid Load Balancer Detergent Dispenser Lint Filter (cassette type) Pulsator Detergent Dispenser Power Cord Powdered Detergent/ Powdered Bleach/ Liquid Detergent/ Liquid Bleach Lid Lock Adjustable Foot Control Panel Attachments Check that the followings are contained in the washer package. If not provided, please contact your retailer immediately.

  • Page 6: Control Panel And Display

    Control Panel and Display display * example of control panel Power button Press this button to switch power on and off. The washing machine automatically switches off when operations are fi nished. The washing machine also turns off automatically if it is not operated or no button is pressed for 10 minutes after the power has been turned on.
  • Page 7 Control Panel and Display LED Display Lights in the Delay Timer mode. Delay Timer indicator Locks the lid during the start. The lid cannot be opened while this Lid Lock indicator indicator is lit. To release the lock, press the Start/Pause button to pause operation.

  • Page 8: Before You Start Washing

    Before You Start Washing ■ Remove any foreign objects (coins, safety pins, etc.). Preparation of ■ Put delicate clothes (knits, lingerie, etc.) in a net. the laundry ■ Remove large lumps of lint, mud, sand, hair, and pet hair from laundry. ■...

  • Page 9: How To Use The Washing Machine

    Balancer (dotted line). Otherwise, laundry may jump out from the wash tub while spinning and it may cause damage. SF-P100XAV Press the Power button to turn on the power ■ If no program is selected within 10 minutes, the washing machine automatically switches itself off.
  • Page 10 How to Use the Washing Machine Put detergent into the Detergent Dispenser and close the Lid ■ Open the Detergent Dispenser, add the appropriate amount of detergent, and then close the Detergent Dispenser. ■ The amount of detergent is based on a single 35-gram scoop of powder detergent. Since the required amount of detergent varies depending on the type of detergent, follow the instructions on the package of detergent.
  • Page 11 How to Use the Washing Machine Program ends ■ The alarm sounds when a program ends. The alarm can be deactivated or the sound can be changed in 5 types if the Water Level button is pressed for at least 3 seconds. Melody 1 *initial Melody 2...
  • Page 12 How to Use the Washing Machine 1. Prepare the laundry. How to use ■ Fold large items, such as quilts or blankets, as follows. the Blanket They should not be taller than 30 cm after they are folded. program 30 cm About 30 cm If it exceeds 30 cm, use a laundry net, which is sold separately.
  • Page 13 How to Use the Washing Machine ■ How to use Use this program separately from other washing programs. (Do not put laundry into the tub.) the Tub Clean 1. Press the Power button to turn on the power. program 2. Select the Tub Clean program. ■...
  • Page 14 How to Use the Washing Machine Australian Water Effi ciency & Energy Effi ciency Labels are based upon the below wash settings: Normal Warm Wash Water Saving settings: Water Save, Wash Temp. Warm, Water Level 70, Wash 48mins, Rinse 2 (default), Spin 9min, Water Power +2, Detergent dissolved in 1 litre warm water.

  • Page 15: List Of Programs

    List of Programs : Default settings : Changeable settings (via corresponding button) Program Fuzzy Powerful Delicate Maximum P100XAV 10 kg 5 kg load 35 to 86 L (Automatically) 55 L Amount P100XAV of water 35 to 86 L 45 to 74 L 15 min 48 min 6 min...
  • Page 16 List of Programs : Default settings : Changeable settings (via corresponding button) Soak Program Speedy 1 hrs 3 hrs 5 hrs Maximum P100XAV 5 kg 10 kg load 50 L 35 to 86 L (Automatically) Amount P100XAV of water 35 to 60 L 35 to 86 L 3 min 60 min...
  • Page 17 List of Programs : Default settings : Changeable settings (via corresponding button) Program Water Save Energy save Blanket Maximum P100XAV 10 kg 10 kg 3 kg load 35 to 86 L (Automatically) 35 to 86 L (Automatically) 88 L Amount P100XAV of water 35 to 86 L...
  • Page 18 fl ow is adjusted at slower rate to maintain the performance of washer. ■ Amount of detergent is indicated according to following table as a guide. Load (guide) Water Level Detergent (guide) Amount of detergent (SF-P100XAV) 8~10 kg 74~86 L 1.4~1.7 cup 49~60 g 4~7 kg 55~70 L 1~1.3 cup...

  • Page 19: Partial Operations Using The Fuzzy Program

    Partial Operations Using the Fuzzy Program To not spin the To reuse the wash To customize laundry because you If you want... water and separate the wash program are worried about your laundry wrinkles Wash  Rinse  Spin Wash  Rinse Operations Wash only Setting method...
  • Page 20 Partial Operations Using the Fuzzy Program If you want... To rinse only To rinse and spin To drain and spin Rinse  Spin Drain  Spin Operations Rinse only Setting method Turn on the power. Select the Fuzzy program. Display show Set the amount of water.
  • Page 21 9 Min 65 L 35 L 3 Min (Auto) No rinsing No washing SF-P100XAV ■ ■ You can set the spin time each You can select type of water by time you press the Spin button pressing Water Temp button.

  • Page 22: In Case Of Power Outage

    In Case of Power Outage The washing machine is equipped with a restart function. If there is a If a power outage occurs while the washing machine is operating, the power outage cycle (i.e., wash, rinse, or spin) at that time is saved, and when the power is restored, automatically restart from the interrupted cycle.
  • Page 23 Care and Maintenance 1. Close the tap. Cleaning 2. Disconnect the water supply hose from the top of the washing the water machine. (Water in the hose may be drained when you disconnect supply inlet the hose.) 3. Use a brush or something to clean the water supply inlet of the washing machine.

  • Page 24: Troubleshooting

    Troubleshooting Problem Possible cause ● Does not operate The power plug is not inserted in the power outlet. ● There is a power outage. ● The Delay Timer has been set. ● It is wet, even though it is There may be moisture or water left in the tub or hoses from the the fi...

  • Page 25: Error Codes

    Error Codes Error Description Things to check Solution code ● Laundry Check if the laundry overloaded? Decrease the amount overload of laundry according to the instructions on page 15-17. ● Water is not Is the tap open? Check the tap, water ●...

  • Page 26: How To Install The Washing Machine

    How to Install the Washing Machine ■ Do not use a damaged power plug, doing so is dangerous. Contact a Safety repair center that is certifi ed by the manufacturer to replace the plug. precautions ■ If the outlet you are using is a 2-pin outlet, use an adapter to change from three pins to two pins.
  • Page 27 How to Install the Washing Machine ● Main unit Connecting the Screw the union nut to arrow direction to fi rmly attach the water supply water supply opening. hose Precautions Make sure that the union nut between water supply hose and main unit is tightly screwed.
  • Page 28 How to Install the Washing Machine ● Water supply hose Connecting to the tap ■ The optimum water pressure is 0.03 to 0.8 MPa. ■ Use a horizontal tap. Horizontal tap Extension tap Square tap Connect the water supply hose to the water supply inlet on the washing machine.
  • Page 29 How to Install the Washing Machine ■ Connect the washing machine correctly to a grounded AC power Connecting supply. the power ■ The voltage of the power supply must match the voltage rating of the washing machine. ■ Do not use extension cords or overload the power outlet by using power strips.

  • Page 30: Customer Service

    Specifi cations Model SF-P100XAV Power supply See the rating plate on the back of the washing machine. Standard water level 86 L (maximum water level)
  • Page 31 Memo...
  • Page 32 3WPL116171...
