Related Manuals for Respirex BTRS Series
Summary of Contents for Respirex BTRS Series
- Page 1 Chemical Protective Trousers Instructions for use EN14605:2005+A1:2009 TYPE PB[3], TYPE PB[4] TYPE 3, TYPE 4 BS\002\C\2018...
-
Page 2: Table Of Contents
Contents General information ......................Limitations & warnings ....................Pre-checks ............................. Donning procedure ......................Wearing trousers with elasticated inner & outer legs ....Wearing trousers with velcro securing strips on outer legs 3 Recommended cleaning procedures ............Cleaning accessories ......................Servicing & maintenance ..................... -
Page 3: General Information
Always follow the instructions carefully otherwise there may be a drastic impact upon the protection off ered by the garment. BTRS series chemical protective trousers should only be worn in areas where there is a low risk of chemical spillage occurring. In areas of high risk Respirex can advise on alternative items of PPE that will provide the necessary level of protection. -
Page 4: Donning Procedure
Donning procedure Consult the body measurement chart (see page 7) and select the correct size garment. Suitable underclothing should be worn beneath the tousers. After carrying out the pre-checks as detailed in these instructions put the trousers on and make sure that any press stud openings or adjustments around the waist are closed securely . Where braces are tted make sure that the buckles are fully clipped together and that the braces are adjusted to a comfortable tension over the shoulders (see Fig. -
Page 5: Wearing Trousers With Velcro Securing Strips On Outer Legs
Wearing trousers with velcro securing strips on outer legs Step into the trousers as usual with foot through elastic stirrup (where tted), as previously described. If tted, fold the outer leg up approximately 20-23cms (8-9”). Step into protective safety boots. Fold down outer legs over exterior of boots. -
Page 6: Recommended Cleaning Procedures
Recommended cleaning procedures If trousers are contaminated by acid splash they should be drenched in a neutralising bath with a pH value of 9 for approximately 10 minutes. The recommended neutraliser is a solution of bicarbonate of soda and water (6% bicarbonate of soda W/V). -
Page 7: Cleaning Accessories
For cleaning garment outer surfaces use Citrikleen, Part No. F00938. For cleaning garment inner surfaces use Respirex Synodor Odor San, Part No.F00936. To order these accessories contact Respirex customer services on Tel: +44(0) 1737 778600 or Fax: +44(0) 1737 779441. Servicing & maintenance Trousers manufactured from polymer rubber materials, e.g. -
Page 8: Product Labelling
Product labelling Manufacturer of garment; Respirex International Ltd. Garment size Manufacturer’s Model number Manufacturer’s Order No. Customer Name Date of manufacture; Day/Month/Year Symbol denoting protection against liquid chemicals Warning: Special conditions required for full body protection, refer to user instructions. -
Page 9: Sizes
Sizes The following pictograms designate the range of height & waist sizes suitable for speci c sizes of chemical protective trousers, check your body measurements and select the correct size trousers. Body measurements in cm. Size Height Waist 164-170 72-80 170-176 80-88 176-182... -
Page 10: Whole Suit Performance Testing
Whole suit performance testing Performance requirement Test method Property value Result EN14605:2005+A1:2009 Resistance to penetration by a EN ISO 17491-3:2008 Pass* clause 4.3.4.3 jet of liquid (jet test) EN14605:2005+A1:2009 Resistance to penetration by a EN ISO 17491-4:2008 Pass* clause 4.3.4.2 spray of liquid (spray test) *As described under the “Limitations &... -
Page 11: Eu Declaration Of Conformity
Surrey RH1 4DP United Kingdom Declares that the PPE described hereafter: Respirex (logo) BTRS series Reusable Chemical Protective trousers Meets the minimum requirements specified by product standards; Types PB [3]* & PB[4]* (Reusable, partial body chemical protective clothing with liquid tight & spray tight connections) EN 14605:2005+A1:2009 *When worn as an ensemble with the manufacturer’s compatible BTRS... - Page 12 RESPIREX INTERNATIONAL LTD, Unit F Kingsfield Business Centre, Philanthropic Road, Redhill, Surrey, RH1 4DP ENGLAND TELEPHONE +44(0) 1737 778600 +44(0) 1737 779441 EMAIL info@respirex.co.uk SGS United Kingdom Ltd. Type Examination By: SGS FIMKO OY (Module B) Weston-super-Mare, P.O. Box 30 (Särkiniementie 3)
