Magtek ExpressCard 1000 Quick Installation Manual page 2

STEP TWO
Remove the cleaning roller assembly
by grasping the blue handle and
pulling the assembly upward.
by pulling on the indicated arrow.
STEP THREE
Load blank cards into the card hopper
right. Place the card weights on top of
the stack as shown above.
STEP FOUR
press the [Menu]
P/N 99875400 rev. 2.02 1/09
Install Cleaner Roller Assembly
Remove the cleaning roller hub by
gently pulling the hub supports apart
and removing the roller hub.
Reinstall the cleaning roller by placing
the assembly back into the printer.
Load Blank Cards + Connect
Connect the provided Ethernet cable.
Print
Select [Samples].
Insert the new cleaning roller hub.
Connect the power cable and turn on
the ExpressCard 1000 by pressing the
Select the a card sample image and
press print. If you are unable print a
sample card contact Technical Support.
