YEALINK T23P
THE T23G IS A COST EFFECTIVE IP BUSINESS PHONE FEATURING AN
INTUITIVE USER INTERFACE WITH SECURE PROVISIONING AND HD
AUDIO FOR EXCELLENT VOICE QUALITY. THIS PHONE IS IDEAL FOR THOSE WORKING IN SMALL
AND LARGE OFFICE ENVIRONMENTS REQUIRING GIGABIT ETHERNET AND ACCESS TO A VARIETY
OF ENHANCED
FEATURES.
HANDSET COMPONENT
ITEM
1
LCD Screen
2
Power
LED
www.vanillaip.com
DESCRIPTION
Shows information about calls, messages, soft keys, time, date
and other relevant data:
• Call information — caller ID, call duration
• Icons
• Missed call text or second incoming caller information
• Prompt text (for example, "Saving config file!")
• Time and date
Indicator
Indicates phone power status and phone status
1

Advertisement

loading

Related Manuals for Yealink T23P

Summary of Contents for Yealink T23P

  • Page 1 YEALINK T23P THE T23G IS A COST EFFECTIVE IP BUSINESS PHONE FEATURING AN INTUITIVE USER INTERFACE WITH SECURE PROVISIONING AND HD AUDIO FOR EXCELLENT VOICE QUALITY. THIS PHONE IS IDEAL FOR THOSE WORKING IN SMALL AND LARGE OFFICE ENVIRONMENTS REQUIRING GIGABIT ETHERNET AND ACCESS TO A VARIETY OF ENHANCED FEATURES.
  • Page 2 Line Keys Use these keys to activate up to three accounts and assign various features. Soft Keys Label automatically to identify their context-sensitive features. Scroll through the displayed information. Confirms actions or answers an incoming call. Cancels actions, rejects incoming calls, mutes or un-mutes calls. MESSAGE key Indicates and accesses voice mails HEADSET key...

  • Page 3: Making A Call

    Alphanumeric input mode Numeric input mode Multi-lingual uppercase and lowercase letters input mode Voice Mail Text Message Auto Answer Do Not Disturb Call Forwarded/Forwarded Calls Call Hold Call Mute Ringer volume is 0 Keypad Lock Received Calls Placed Calls Missed Calls Recording box is full A call cannot be recorded Recording starts successfully...
  • Page 4 Re-dial: Dial the RD Button to dial out the last called number directly  ANSWERING A CALL Answering an incoming call in the following ways: If you are on another call, press the Hold key to answer it If you are not on another call, just lift the handset to answer it You can also press the Mute button to deny the incoming call ...
  • Page 5 POWER INDICATOR LED LED STATUS DESCRIPTION Solid red The phone is initializing. Fast flashing red (300ms) The phone is ringing. Slow flashing red The phone receives a text message or voice mail. The phone is powered off The phone is idle The phone is busy The call is muted The call is placed on hold or held...
