- Page 1 File Date Changes on previous version Me Easymix 120 plus_01.docx 06/09/2018 First version from Me Eps plus3.docx EasyMix120plus01.mot ELECTRONIC MANUAL...
-
Page 2: Abbreviation Legend
ABBREVIATION LEGEND For the sake of simplicity, this manual uses the following abbreviations: : Cooling solenoid valve EVF_SUP : Top part cooling solenoid valve EVGC : Hot Gas solenoid valve : Water Inlet solenoid valve : Beater motor : Compressor motor : Fan motor (air version) : Heating element Contactor TTR2... -
Page 3: Installation
INSTALLATION Connect the machine to the water supply mains with the water pipes (in the water cooled condenser version) and to the power supply line with the power cable. Power the machine. As soon as the machine is switched on, display reads "EASYMIX120PLUS" followed by a digit indicating the software version. -
Page 4: Display Screen
DISPLAY SCREEN The machine features an alphanumerical display showing a series of messages when the machine is switched on as well as during use. In STOP mode, the display reads: 15:38 10-08 EASYMIX 120 PLUS When activating a function, the parameters connected to the cycle are displayed. The top part (first line) usually shows the cycle name, whereas the bottom part (second line) usually shows the real temperature read by TEV probe at a specific moment (on the right) and the temperature to be reached (on the left). -
Page 5: Position Of Sensors
POSITION OF SENSORS EASYMIX 120 PLUS (right side view) RIGHT SIDE TER 2 TES 3 EASYMIX 120 PLUS (left side view) LEFT SIDE TES 1... -
Page 6: Functions
FUNCTIONS STOP In this function, the machine is not working and the relevant red LED is on. The display reads time, date and machine model. 15:38 10-08 EASYMIX 120 PLUS DISPLAY OF PASTEURIZATIONS, EVENTS, METERS, MA and MC HOUR COUNTER RESET Hold the Stop button pressed while the machine is in Stop mode to enable: reading the events relevant only to the pasteurization cycle phases by releasing the button after 3 seconds when the display reads “***Read pasto***”. -
Page 7: Increase / Decrease
INCREASE / DECREASE The button LED's turn on when a value can be edited from the display. Decrease button is used also to reset the alarms. The Increase button is used as well to skip a Pasteurization phase. To do so, hold it pressed after a cycle has started. -
Page 8: Automatic Functions
AUTOMATIC FUNCTIONS (AUTO) 4 cycles are available. To select one of them, place the asterisk on the side of the cycle using the Increase/Decrease buttons: - PASTO +85 - PASTO +90 - PASTO +65 - COOLING/AGING The first 3 cycles are Pasteurization cycles, whereas the last one is a Cooling/Aging cycle. * PASTO +85 PASTO +90 After pressing the AUTO button, the last selected cycle 85°, 90°, 65°... - Page 9 The display shows the cycle and the filling option on the first line, and on the second line from the left: set – ramp – TEV. PASTO+90 120-60 +90°C +68°C To change the speed press the Speed key and change it using the Increase/Decrease keys. In speed change mode the display shows: HEATING +090 05...
- Page 10 Full Filling Cycle (120-60) Heating Following elements are activated in the Full Filling cycle Heating: - Beating at speed = 5 - Heating elements (TTR and TTR2) - Hot Gas Solenoid valve (EVGC) + EVSUP - Compressor (MC) The heating plate (TER) temperature is checked. When TER reaches the value set in T24, heating is disabled (TTR OFF).
- Page 11 Cooling In the first Cooling stage, the MC disables for a minute, while the cool SVs remain on. After the first minute, the MC activates for another minute intermittently, 10” ON and 20” OFF. After these 2 minutes, the actual Cooling starts. Following elements are activated in the Full Filling cycle Cooling: - Beating at speed = 5 - Compressor (MC)
- Page 12 Storage / Aging The speed of the previous step is kept in Storage / Aging mode. This speed can be changed by pressing the Start key to access the speed display page: PASTO+90 120-60 Set +004 Then press the Speed key and change it using the Increase/Decrease keys.
- Page 13 - EVF Then the cycle is similar to the “Full Filling” cycle. Half Filling Cycle Plus (60-40 plus) Available only for pasteurization cycles. Half Filling cycle Plus is activated by placing the asterisk to the side of “60-40 Plus”. 120-60 full filling 60-40 half filling...
- Page 14 COOLING AGING (COOL/AGI) In the first Cooling stage, the MC disables for a minute, while the cool SVs remain on. After the first minute, the MC activates for another minute intermittently, 10” ON and 20” OFF. After these 2 minutes, the actual Cooling starts. PASTO +65 * COOLING/AGING Also in this case, as in the case of pasteurization, the mix filling in the hopper at the beginning of...
-
Page 15: Manual Functions
MANUAL FUNCTIONS (BEATING) If the Beating button is pressed the display will read: * BEATING HEATING Also in this case, the asterisk is used to select the relevant cycle among: - BEATING - HEATING - COOLING BEATING Beating is activated at speed 4. The display shows: BEATING 29:59 +20°... - Page 16 HEATING After selecting the cycle, enter the relevant filling value as in the automatic cycles: * 120-60 full filling 60-40 half filling Before starting the cycle the display will show the Mix Added confirmation request: Mix added? Press then the AUTO button to start the cycle. Beating at speed 5 + heating is activated as in the automatic cycles.
- Page 17 When the set is reached, the outputs are deactivated and the ramp is switched off. Only set temperature and TEV are enabled and an intermittent sound signal, signaling the end of the cycle, is activated. HEATING +85°C +86°C The mix is thermostat-controlled at the set temperature indefinitely with the same beating of the cycle carried out.
- Page 18 COOLING After selecting the cycle, enter the relevant filling value as in the automatic cycles: * 120-60 full filling 60-40 half filling Before starting the cycle the display will show the Mix Added confirmation request: Mix added? Press then the AUTO button to start the cycle. Beating at speed 5 + cooling is activated as in the automatic cycles.
-
Page 19: Shower
SHOWER Water inlet is activated. To stop it, 3 options are available: • press the same button again • press Stop • after 3 minutes This function is independent from the other functions. -
Page 20: Software Update
SOFTWARE UPDATE For a control unit software upgrade, use the special serial cable supplied by the manufacturer, connect it to the control unit through the Serial port (see electronic board layout) and to serial port RS232 of any Personal Computer (PC). The software Upgrade can be done by transferring the new software from the computer to the CPU using M16C Flasher. -
Page 21: Autosetup
AUTOSETUP If AUTOSETUP is necessary, it shall only be executed under the Manufacturer’s authorization. Following procedure sets all programmable values which are same as the ones indicated in the column of relevant model in programming table. To do that, it is necessary: •... -
Page 22: Process Autosetup
PROCESS AUTOSETUP Pressing the Decrease button in the Stop mode for about 10 seconds causes the autosetup of the automatic cycle values to start. Values such as temperature set, beating, pause times will be reset to their default values in all processes. The following message will be displayed: AUTOSETUP PROCESSES... -
Page 23: Events
EVENTS The machine has a large memory for saving the events (log). To read the events on the display, the machine has to be in Stop mode. It is possible either to read only the events relevant to the steps of pasteurization cycles or all the events. -
Page 24: Reading Events
Reading Events Press Stop and keep it pressed for about 6”. The display will show the following in sequence: **Read Pasto*** **Read Events*** 13:35 14-10 Skip Manual Step. The first line shows the date and time in which the event was logged, the second line shows the name of the event (the example shows the skipping of a stage). -
Page 25: Electronic Board Images
ELECTRONIC BOARD IMAGES The machine’s electronics consist of a control unit. electronic board part no.: IC573700148... -
Page 26: Connectors Ic573700148
Connectors IC573700148 MRS1 (230V outputs) MRS2 (24V outputs) MRS6 (power supply) MRS5 (NTC probes) MRS4 (PTC probes) MRS3 (inputs) Not Used LCD Keyboard Not Used Serial... -
Page 27: Alarms Displayed
ALARMS DISPLAYED The alarm is shown on the second line of the display. E.g.: TEV Alarm The message at the bottom starts blinking, showing that the alarm has been triggered and is active, whereas it is steady on after the alarm has been reset. To reset it, press the Decrease button Driver Alarm Beater Drive Fault... - Page 28 read “Lid Open” on the second line of the display. In case of cooling, beating stops immediately, while compressor and relevant solenoid valve remain on for further 10 seconds (if cooling was requested). Closing the lid within 10 seconds will cause only beating to restart, whereas after 10 seconds all the outputs will be re-activated.
-
Page 29: Blackout
BLACKOUT If there is a temporary power blackout in: Stop or Beating phases, the machine restarts in Stop mode once power is restored. Manual Heating phase, when power is restored, the machine is restarted and resumes Heating without displaying any message, however the machine will log the “Black Out” event. Manual cooling in the cooling phase, after restoring the power supply, the machine will resume the interrupted phase and check the TEV temperature as well as the duration of the... - Page 30 the user that the cycle is repeated as the mix may have been altered as a result of the blackout. TEV Temperature Time >50°C 30 minutes 49°C ⎟ 15°C 10 minutes 14°C ⎟ 10°C 20 minutes 9°C ⎟ 4°C 2 hours...
-
Page 31: Programming For The User
PROGRAMMING FOR THE USER Press Stop and Decrease buttons at the same time and release them immediately. The display will read: Easymix120Plus01 Manager Menu and after that the first programming step (time). If necessary, modify the time setting using buttons Press Stop to access the following steps. - Page 32 U01-U06 Setting time and date Language Language setting: Ita, Eng, Fra, Deu, Esp, Dut, Jap. Time ON Beat When intermittent beating is selected, the beater operates for a time which is programmable at this step and whose value is typically 15 seconds. Time OFF Beat When intermittent beating is selected, the beater operates for a time which is programmable at step U08 and stops for a time which is programmable at this step...
-
Page 33: Technician Programming
TECHNICIAN PROGRAMMING Press Stop and Decrease buttons at the same time and hold them pressed until the following is displayed: Easymix120Plus01 ******PROG****** and after that the first programming step (Heating Hysteresis). If necessary, modify the step setting using the buttons Press Stop to access the following steps. -
Page 34: Easymix 120 Plus Programming Table
EASYMIX 120 PLUS Programming Table Sw Version: EASYMIX120PLUS01.mot Step Display EN U.M. EASYMIX 120 test value PLUS Mod.3 Heating Hysteresis °C Cooling Hysteresis °C Water Supply Time Anti-freezing -030 °C -025 Anti-freezing Hyst. °C Discrimin.Temp. °C Set TGV °C Max TEMP Limit °C Hyst. -
Page 35: Programming Steps
PROGRAMMING STEPS Step Description Heating Hysteresis When the temperature of the in-hopper product detected by the TEV probe reaches the set value, the heating elements are deactivated while the beater keeps on running. If the hopper temperature, detected by the TEV probe falls by 2°C (value programmable at this step) below the set temperature, the heating elements are reactivated to bring the product back to heating temperature. - Page 36 Discrimin.Temp. Anti-freezing is active from TEV temperatures lower or equal to the temperatures programmed at this step. In any case, the anti-freezing is always active if TGV <= - 30°C, regardless of TEV value. During anti-freezing the beater speed is increased to 2 for 30” (fixed). Set TGV Value of TGV probe beyond which hot gas heating is disabled.
- Page 37 Offset TEV This is the correction of TEV probe. With this step it is possible to calibrate the real hopper mix temperature. Check temperature in the hopper using a precise thermometer. If the value measured does not correspond to the value shown by the display, press Increase/Decrease button until the temperature shown by the display corresponds to the one read by the thermometer.
- Page 38 Alarm TES It enables (YES) or disables (NO) Safety Thermostat alarm. Alarm PR It enables (YES) or disables (NO) the Pressure Switch alarm. Temp. Display It enables (Yes) or disables (No) display of TEV, TGV, TER and TER2 temperatures during automatic cycles for 24 hours. The step returns automatically to No. In case of blackout during 24h, it is necessary to set this step again to Yes to display the temperatures again.
-
Page 39: Easymix 120 Plus Processes
EASYMIX 120 PLUS PROCESSES High Pasteurization 85° Easymix120plus °C 85° 40° 4° Time step High Pasteurization 85° STEP 1 Heating up to 85°C. STEP 2 Cooling down to 4°C STEP 3 Maintaining at 4°C indefinitely (MA//MC). In this phase, beating is activated along with the compressor or for 10 seconds each 30 minutes. -
Page 40: High Pasteurization - 90
High Pasteurization 90° Easymix120plus °C 90° 40° 4° Time step High Pasteurization - 90° STEP 1 Heating up to 90°C. STEP 2 Cooling down to 4°C STEP 3 Maintaining at 4°C indefinitely (MA//MC). In this phase, beating is activated along with the compressor or for 10 seconds each 30 minutes. -
Page 41: Low Pasteurization - 65
Low Pasteurization 65° Easymix120plus °C 65° 40° 4° Time step Low Pasteurization - 65° STEP 1 Heating up to 65°C. STEP 2 Maintaining at 65° for 30’. At 65° pause is with beating on. STEP 3 Cooling down to 4°C STEP 4 Maintaining at 4°C indefinitely (MA//MC). -
Page 42: Cooling / Aging
Cooling / Aging Easymix120plus °C 2°⇐4°⇒6° Time step Cooling / Aging STEP 1 Cooling down to 4°C editable from 2 to 4°C. STEP 2 Maintaining at 4°C indefinitely (MA//MC). In this phase, beating is started along with the compressor or for 10 seconds each 30 minutes. Beating can be forced by pressing the Beating button. -
Page 43: Table Of Contents
CONTENTS ABBREVIATION LEGEND ............................2 INSTALLATION ..............................3 DISPLAY SCREEN ..............................4 POSITION OF SENSORS ............................5 FUNCTIONS ................................ 6 STOP ..................................6 DISPLAY OF PASTEURIZATIONS, EVENTS, METERS, MA and MC HOUR COUNTER RESET ..........6 RESET PROCESSING METER AND COOLING CYCLE METERS ..................6 INCREASE / DECREASE ............................
