en Appliance door
Push down on the intermediate pane in the area of
4.
, and carefully lift the retainer
to pull it out.
5. Lift the first and second intermediate panes from be-
low and remove them in the direction of the arrow
⁠ .
Remove the spacers
6.
required.
7.
WARNING ‒ Risk of injury!
Scratched glass in the appliance door may develop
into a crack.
Do not use glass scrapers, sharp or abrasive
▶
cleaning aids, or harsh cleaning products.
Clean the door panes on both sides with glass
cleaner and a soft cloth.
Dry the door panes and refit them.
8.
→ "Fitting the door panes", Page 26
18.4 Fitting the door panes
WARNING ‒ Risk of injury!
If a door pane or appliance door has not been installed
correctly, this is dangerous.
Make sure that all of the door panes and the appli-
▶
ance door have been correctly fitted before you
switch the appliance back on again.
26
until you are able
and seals for cleaning, if
Tip: When fitting the door panes, make sure that
1.
they are in the original order.
Insert the intermediate pane so that the
the right-hand side is pointing upwards.
Check the fit of the four spacers and two seals.
2.
Place the spacers on the centre of the lines
‒
Secure the seals at the corners
‒
Insert the intermediate pane with spacers and seals
3.
in the direction of the arrow
The arrow on the intermediate pane must line up
with the arrow on the frame
Insert the second intermediate pane without the
4.
spacers and seals, and slide it in the direction of the
arrow until it is inserted in the frame
The arrow on the intermediate pane must line up
with the arrow on the frame
arrow on
⁠ ⁠ .
⁠ .
⁠ .
⁠ .
⁠ .
⁠ .
